- Page 1 START KIT DMC/DKS-012-016 GEBRUIKSAANWIJZING DMC/DKS-012-016 START KIT 12 x www.domestia.be...
- Page 2 FIGURE A - Motherboard DMC-012-016 Contact *(1) LEFT RIGHT DMC-012-002 Center DOWN *(2) To identi cation B GND modules 1 00- 240 VAC / 50 – 60 H RS485 to (See Figure B) Max 2A other card(s) (See Figure C)
-
Page 3: Installation
FIGURE C - Linking DMC-012-016 cards - Example of 4 card connection Card con gured as master with 3 slaves Card con gured as slave with address 2 *(1) *(1) Left Right Left Right DMC-012-002 DMC-012-002 Center Down Center Down... -
Page 4: Timer Mode
3. ASSOCIATION OF SEVERAL CARDS If an installation has more than 12 outputs (i.e. more than one DMC-012-016 card), you will have to inter- connect the cards as described in Figure C. The factory default configuration of the DMC card is for it to operate alone, without slave(s). You must change the functions of the cards in order to use several DMC cards. - Page 5 III. Using the RIGHT and LEFT buttons and LEDS 1 to 4, select the number of outputs you have on the installation (in this example 4 cards). Lit LEDs - DMC-012-016 Number of outputs from 1 to 12 1, 2...
- Page 6 4. PROGRAMMING The programming mode(s) are initiated using the buttons on the master card. Once the mode is established, the slave card buttons are then activated. Press once on the DOWN button in order to start programming the outputs and identification modules. Led 1 (1st relay) is blinking.
- Page 7 127 minutes and 30 seconds. Use the RIGHT and LEFT buttons to change the time. The following table sets out the time value of the LEDs. The times are cumulative. Lit LEDs - DMC-012-016 Times 30 seconds 1 minute...
-
Page 8: Group Programming
4.3.2. SELECT MODE Starting from the Switch All On mode (see above), press once on the DOWN button when all the outputs are activated. At that time, LEDs A, B, C, D and E are lit, together with all the LEDs from the previous configuration (by default: all). -
Page 9: Technical Details
5. TECHNICAL DETAILS 5.1. DMC-012-016 • Power supply: 100-240VAC/50-60Hz. • Number of outputs per card: 12 unipolar contacts of 16A free of potential and removable. • Identification module bus: 10 VDC on 2 non-polarised wires. • Communication bus: RS485. •... -
Page 10: Warranty Condition
• The DMC-012-016 kit is designed to be placed in an electrical box with a DIN rail. • Make sure you place the electrical box containing the kit so that it is not in direct sunlight. Do not place the box above a heat source (e.g.: radiator). Make sure that there is natural ventilation for the DMC-012-016 card. - Page 11 8.2.2. LIGNES AC 230V • EN 61000-4-4 2kV burst in criteria B. • EN 61000-4-5 2kV shock wave between phase and earth, 1kV between phases, all in criteria B. • EN 61000-4-6 induced signals due to RF 150kHz-80MHz 3V fields in criteria A or 10V in criteria B. •...
