- Page 1 LAVINA LA2000-230 ® Air scrubber User Manual www.superabrasive.com / factory@superabrasive.com...
-
Page 2: Warranty And Returns
WARRANTY POLICY FOR THE LAVINA® LA2000-230 Superabrasive Ltd. guarantees that the original purchaser of the Lavina® machine will be covered against defects in material and workmanship for a period of 2 years from the date of delivery or 600 hours of use whichever comes first. -
Page 3: Table Of Contents
01/2019 4. CE-CERTIFICATION All LAVINA® dust collectors are designed to operate correctly in an electromagnetic atmosphere of industrial type, and are equipped with all of the mechanical and electrical safety protections in conformity with the following European CEE rules and regulations: LAVINA®... -
Page 4: General Information
Air and finer particles then pass through the filter system of the primary filter and the HEPA filter, where the dust is separated. WARNING! The Lavina® LA2000-230 machine is manufactured and fitted for the above-mentioned applications only! Every other use may possess risks to the persons involved. 6. MAIN COMPONENTS AND CONTROLS... -
Page 5: Technical Data
® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 7.TECHNICAL DATA LA2000-230 Voltage/Hz 1ph x 230V / 50Hz 510 W (full speed) Power 0.7 HP Speed 1380 rmp Amperage Amps 2.3 Amps , Max 7.5 Amps 0.64 m Pre Filter area 6.89 ft... -
Page 6: Safety Precautions
OPERATING THE MACHINE When operating the LAVINA® LA2000-230, be sure that no one else is PREPARATION FOR WORK Ensure that: within close proximity to the air cleaner. Never leave • You have closed the work area, so that no person the air cleaner unattended while working. - Page 7 ® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 • If toxic or harmful substances accidentally enter the SAFETY PRECAUTIONS, Continued • Superabrasive cannot predict possible air cleaner, the filters must be removed immediately circumstances that could present a potential hazard.
-
Page 8: Operation Of Air Cleaner
Figure 2 9.2 FILTER INDICATOR LA2000-230 has two filter indicators connected to a warning light which measures the pressure drop over the filter. If the pressure drop is too high, a yellow lamp (pos.1) light up, indicating that the pre-filter should be changed. -
Page 9: Pre-Filter Change
® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 9.3 PRE-FILTER CHANGE IMPORTANT: Before performing any work or maintenance on the air scrubber, be sure to wear the proper protective equipment. This may include clothing which covers any exposed skin, protective eyewear, a respirator, and/or protective gloves conforming to protection class FFP3. -
Page 10: Maintenance
® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 10. MAINTENANCE IMPORTANT: All of the following procedures must be performed with the air scrubber turned off and the power cable disconnected from the power source. Before performing any work or maintenance on the air scrubber, be sure to wear the proper protective equipment (clothing, eye protection, and/or gloves). -
Page 11: Troubleshooting
® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 12. TROUBLESHOOTING INDEX OF PROBLEMS AND SOLUTIONS DUST COLLECTOR ISSUE OR SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION NO POWER CONNECT THE MACHINE THE FAN DOES NOT START CABLE DEFECTIVE CHANGE SWITCH DEFECTIVE... -
Page 12: Lavina® La2000-230 General Parts
® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 13. LAVINA® LA2000-230 GENERAL PARTS... - Page 13 ® Owner’s Manual Original Language – Lavina Superabrasive LA2000-230 01/2019 13. LAVINA® LA2000-230 GENERAL PARTS Item No. Description Pcs. LA2000-115-00.00.02 Buckler 30323000218 Pre filter 24"x 24"x 1" LA2000-115-50.00.00 Front frame cover LA2000-115-FH-1 Hepa Filter H13 LA2000-115-20.00.00 Front fan cover assembly LA2000-230-10.00.00...
