Summary of Contents for Puricom GuTZZI FT
- Page 1 Ficha técnica Libro de servicio Data sheet Service book 2 | 4...
- Page 3 INDEX 1. MAIN SPECIFICATIONS 2. TECHNICAL SPECIFICATIONS 3. HOW THE EQUIPMENT WORKS 4. INTERFACE. SYSTEM STATUS 5. GUARANTEE 6. BOOK OF SERVICE, START-UP AND MAINTENANCE OF THE SYSTEM 7. SERVICE BOOK. USER...
- Page 4 1. MAIN SPECIFICATIONS CS FILTERS Exclusive filters. Maximum hygiene and safety. DIRECT ACCESS Easy access and maintenance REMINERALIZER pH-regulating post-filter ENCAPSULATED MEMBRANE Maximum hygiene. Easy intallation. CLICK Quick connectors and maximum safety SOLENOID VALVE Immediate control. Built-in safety mesh PRESSURE CONTROL Protection against pressure drops in the supply network ELECTRONIC ADAPTER...
- Page 5 FILTER CONTROL Automatic maintenance warning QUALITY CONTROL Conductivity control of water produced SOUND WARNINGS Acoustic warnings BLOQUEO DE SEGURIDAD Proper maintenance guarantees water quality COMPACT PRESSURE PUMP High efficiency. Compact design. AUTO-DIAGNOSIS Individualized verification for easier components maintenance...
- Page 6 2. TECHNICAL CHARACTERISTICS Application Water treatment • Reverse osmosis • Improves the drinking water’s characteristics (meeting all European Directive on Water for Human Consumption 98/83 requirements and its national transpositions in the various EU member states). Modifications due to reduction or contribution • Water treatment via reverse osmosis is able to greatly reduce salt and other concentrations. • Minimum reduction* of specific compounds and parameters: Sodium – 90 % Calcium – 90% Sulphates – 90% Chloride – 90% Total Hardness – 90% Conductivity – 90% (*) Depending on the characteristics of the water to be treated (in the membrane outlet).
- Page 7 Technical Information PUMP Membrane 1812 x 75 GPD GREEN FILTER IN: Stem 3/8” OUT / R OUT: Stem 1/4” IN / INLET OUT: Stem 1/4” OUT / RO Post-filter 1 FPA x REMINERALIZER OUT / OUTLET IN: STEM 3/8” OUT: RM 1/4” IN / INLET Power supply 24 Vdc 1.1 A Electrical adaptor 100-240 Vac 50/60 Hz: 24 Vdc Tap type Klein 1 way Production 0.25 lpm. Without counter pressure. Water to be treated 15 ºHF. 200 ppm, 20 ºC, 2 bar**** Control and management PJK - 266B + PJK 049 electronic system Membrane cleaning system Hydraulic diagram REST...
- Page 8 ***Maximum accumulation may vary depending on the model. **** Flows can vary by up to 20% in function of the temperature, pressure and specific composition of the water to be treated. ***** Possible variations depending on the model chosen. MANUFACTURED BY: PURICOM INDUSTRIAL WATER CORPORATION (Taiwan) DISTRIBUTED BY: IONFILTER. PURICOM EUROPE. PURICOM AMÉRICA Pol. Ind. L’Ametlla Park. C. Aiguafreda, 8.
- Page 9 • The unit with a pump (PUMP) have a built-in low pressure • When the system’s tap is turned on, the water sto- switch to protect the pump against pressure drops from the red in the tank flows through a post-filtering stage (R) network (LPS). whose aim is the elimination of possible odours and taste, as well as pH level adjustment (depending on the • Electronic system for leakage detection (L). When the sys- model), which the water may retain before being dis- tem detects this condition, it blocks the system and emits pensed. an acoustic signal and a light signal to inform about the situation. The unit will remain blocked until the leakage • Depending on the model, the appliances may have di- sensor is dry.
- Page 10 (date and signature) breakdown, poor working or any associated consequences caused by the water’s characteristics. * IF/PEU/PAM = IONFILTER/PURICOM EUROPE/ PURICOM AMÉRICA NOTES FOR THE COMPANY/AUTHORISED TECHNICIAN/INSTALLER: IDENTIFICATION OF THE SYSTEM: Information marked with an (*) should be filled in by the installation technician.
- Page 11 6. EQUIPMENT INSTALLATION AND INITIAL OPERATION REGISTRATION SHEET. TECHNICIAN COMMENTS NOTES FOR TECHNICIAN/INSTALLER: Please read this manual carefully. In the event of any queries please contact your distributor’s Technical *Installation and initial operation results: Assistance Service (S.A.T.). and copied to the WARRANTY SHEET. CORRECT (equipment installed and working This document should be retained by the installer/distributor as it may be requested by IF/PEU/PAM, with the aim of improving customer and after sales...
- Page 12 6. EQUIPMENT INSTALLATION AND INITIAL OPERATION REGISTRATION SHEET. TECHNICIAN DATE TYPE OF SERVICE NAME, SIGNATURE AND STAMP OF AUTHORISED TECHNICIAN INITIAL OPERATION TECHNICIAN ORDINARY MAINTENANCE COMPLETE STAMP REPAIR EXTRAORDINARY SANITATION WARRANTY OTHERS MAINTENANCE COMPLETE ORDINARY TECHNICIAN STAMP REPAIR EXTRAORDINARY SANITATION WARRANTY OTHERS MAINTENANCE COMPLETE...
- Page 13 7. SERVICE BOOK. USER DATE TYPE OF SERVICE NAME, SIGNATURE AND STAMP OF AUTHORISED TECHNICIAN INITIAL OPERATION TECHNICIAN ORDINARY MAINTENANCE COMPLETE STAMP REPAIR EXTRAORDINARY SANITATION WARRANTY OTHERS MAINTENANCE COMPLETE ORDINARY TECHNICIAN STAMP REPAIR EXTRAORDINARY SANITATION WARRANTY OTHERS MAINTENANCE COMPLETE ORDINARY TECHNICIAN REPAIR STAMP...
- Page 14 FTGUTZZI2016...
