D-Link DAP-1955 Quick Installation Manual

Quick Installation Guide
DAP-1955
AC1900 Mesh Wi-Fi Range Extender
INSTALLATION
OPTION 1
D-LINK WI-FI APP SETUP
1
Download the D-Link Wi-Fi app and launch it.
/
D-Link Wi-Fi
2 Tap Install New Device. Scan the QR code on the Quick
Installation Card. Follow the on-screen instructions to complete
/
the setup.
?
FREQUENTLY ASKED QUESTIONS
Why can't I connect to my wireless router or my wireless connection
drops?
1. Verify that your Range Extender is within range of your wireless router. Try
plugging it into a location closer to the router and verify the Status LED is
solid green.
2. Note that when extending a wireless signal from a router or access point,
devices connected to the Range Extender will not get the same speed/
throughput as when connected directly to the router.
Signal Strength Indicator
Very Weak (1 x Amber) Weak (1 x Green) Good (2 x Green)
How do I change the wireless settings on my Range Extender?
1. Open a web browser (e.g., Internet Explorer, Firefox, Chrome, or Safari) and
go to the URL found on the QIC or on the back of the Range Extender
(i.e., http://dlinkapXXXX.local./).
2. At the login screen, enter your Admin Password (If WPS Setup was used, the
password is "password" by default) and click Log in.
3. Go to Settings > Extender.
4. Enter a new Wi-Fi Network Name (SSID) and modify the security (Wi-Fi
password) settings as needed.
5. Click Save.
What is Mesh Smart Roaming?
With Mesh Smart Roaming, your Wi-Fi device (e.g. SmartPhone, Tablet)
will automatically roam to the strongest Wi-Fi signal, eliminating the
need to switch between your Router's and Range Extender's Wi-Fi
signal as you move around your home.
Mesh Smart Roaming Requirements:
1. The Wi-Fi device (e.g. SmartPhone, Tablet) must support the 802.11k/v
standard.
2. The Wireless Name (SSID) & Wireless Password must be the same
on both the Mesh Wi-Fi Range Extender and your Wireless Router.
What if I forgot my Range Extender's Admin password
or want to reset my Range Extender?
1. If you forgot your Admin password or want to reset your
Range Extender back to the factory default settings, press
and hold the reset button on the bottom of the extender
using a paper clip and release after the Status light turns red.
Note: This process will erase all your settings.
2. Setup your Range Extender using your preferred method.
D-Link Wi-Fi
Model Name: DEVICE
Wi-Fi Name: dlink-XXXX
SETUP QR CODE
Password: XXXXXXXX
S/N: 123456789
Strong (3 x Green)
Reset
Button
PACKAGE CONTENTS
• DAP-1955 || AC1900 Mesh Wi-Fi Range Extender
• Quick Installation Guide
• Quick Installation Card
OPTION 2
QUICK WPS SETUP
1
Plug your Range Extender into an available outlet near your wireless
router and wait until the Status LED is blinking amber (this may take
/
up to 3 minutes). You can move it to a more suitable location after it
is set up. If the status LED does not light up, ensure the power toggle
switch underneath is in the "on" position.
2
Press the WPS (Wi-Fi Protected Setup) button on your wireless
/ router for 3 seconds. An LED should start blinking on your router. If
it does not blink, see the important note below.
3
Once confirmed that the WPS light is
/ blinking on your router, within one minute,
press the WPS button on your Range
Extender for 2-3 seconds. The Status LED
should start to blink green.
4
When the Status LED turns solid green (may take up to 3 minutes),
/ this indicates that your Range Extender is securely connected to
your wireless router.
Your setup is complete! You can now unplug and move your Range Extender to
a location between your Wireless Router and the area where you want wireless
coverage. By default, your Range Extender will share the same Wi-Fi name and
password as your Router.
If after moving your Range Extender, the signal strength indicator is showing one
single amber bar or if your Range Extender LED does not turn solid green within 3
minutes, move your Range Extender to a wall outlet closer to your wireless router.
IMPORTANT
WPS may be disabled on some Routers or Modems. If the WPS Status LED on your Router or
Modem does not start blinking when you have pressed the WPS button, try again and hold
it a little longer. If it still does not blink, STOP, and configure your Range Extender using
Option 1: D-Link Wi-Fi App Setup.
TECHNICAL SUPPORT
Having trouble installing your new product? D-Link's website
contains the latest user documentation and software updates for
D-Link products.
Canada
1-800-361-5265
http://support.dlink.ca
D-LINK WI-FI MESH
You easily can pair your AC1900 Mesh Wi-Fi Range Extender (DAP-1955)
with any D-Link Wi-Fi Mesh-enabled Router to create a seamless mesh
network that covers every corner of your home.
GPL CODE STATEMENT
i
This D-Link product includes software code de-
veloped by third parties, including software code
subject to the GNU General Public License ("GPL")
or GNU Lesser General Public License ("LGPL"). As
applicable, the terms of the GPL and LGPL, and
information on obtaining access to the GPL code
and LGPL code used in this product, are available
to view the full GPL Code Statement at:
https://tsd.dlink.com.tw/GPL
The GPL code and LGPL code used in this product
is distributed WITHOUT ANY WARRANTY and is
subject to the copyrights of one or more authors.
For details, see the GPL code and the LGPL code
for this product and the terms of the GPL and
LGPL.
WPS
Button
Written Offer for GPL and LGPL Source Code
Where such specific license terms entitle you
to the source code of such software, D-Link will
provide upon written request via email and/or
traditional paper mail the applicable GPL and LG-
PLsource code files via CD-ROM for a nominal cost
to cover shipping and media charges as allowed
under the GPL and LGPL.
Please direct all inquiries to:
Snail Mail: Email:
Attn: GPLSOURCE REQUEST GPLCODE@dlink.com
D-Link Systems, Inc.
17595 Mt. Herrmann Street
Fountain Valley, CA 92708
