HORIZONTAL FILTER DUST COLLECTORS
HORIZONTAL FILTER DUST COLLECTORS
For models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24C
For models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24C
SUPER IOR PERFO RM A NCE
And Quality In Blast Cleaning Equipment
www.modublast.com
OPERATION & MAINTENANCE MANUAL
OPERATION & MAINTENANCE MANUAL
Ph: (780) 425-5510
!
WARNING
Read Manual
Failure to read, understand &
follow all safety and operation
procedures in this manual can
cause injury or death. Manuals
that are lost, incomplete, or
damaged, must be replaced
immediately.
Manual #RPDC1810
Fax: (780) 425-5540
Copyright© 2018 Mod-U-Blast®, All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Mod-U-Blast M2000-4C
Summary of Contents for Mod-U-Blast M2000-4C
- Page 1 HORIZONTAL FILTER DUST COLLECTORS HORIZONTAL FILTER DUST COLLECTORS OPERATION & MAINTENANCE MANUAL OPERATION & MAINTENANCE MANUAL For models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24C For models M2000-4C, M3000-6C, M6000-12C, M9000-18C, M12000-24C SUPER IOR PERFO RM A NCE And Quality In Blast Cleaning Equipment...
-
Page 2: Table Of Contents
Warranty Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 3: Important Notice
Mod-U-Blast Inc. provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient users, operators and contractors in this industry will continue to use our products in a safe and knowledgeable manner. -
Page 4: Warnings
WARNING Mod-U-Blast Dust Collection Systems are not designed for filtration/extraction of combustible or explosive materials. If you are unsure of your dust particulate, please contact a Mod-U-Blast representative for more information. Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 5: Horizontal Filter Dust Collector Models
Horizontal Filter Dust Collector Owner’s Manual Horizontal Filter Models M3000-6C M2000-4C M6000-12C M3000-6C M9000-18C M12000-24C With Silencer Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 6: Operational Diagram
Copyright© 2018 Mod-U-Blast®, All Rights Reserved... - Page 7 Copyright© 2018 Mod-U-Blast®, All Rights Reserved ctor control panel is sent to open the goyen v alves allowing a rush of air to...
-
Page 8: Important Safety Items
• Working air pressure of the dust collector pulse system must not exceed 80 P.S.I. 1.5 Maintenance • Disconnect the power and air supply from the dust collector before servicing. • Keep all components in good repair. Use Mod-U-Blast parts only and do not substitute or modify. For Service Call: 1-800-661-3842... -
Page 9: Dust Collector Start-Up And Operation
NOTE: AFTER THE FILTERS ARE SEASONED THE AUTO PULSE CAN BE TURNED ON AND STAY ON. THE FILTERS CLEAN BETTER WHEN PULSED WHILE THE BLOWER FAN IS OFF. See the Magnehelic Gauge printout with this manual for maintenance instructions and trouble shooting. For Service Call: 1-800-661-3842 Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 10: Dust Disposal
• Check for leaks in dust hoses NOTE: The auto pulse control panel uses a Zelio timer internally. Should the pulse time between filter banks need to be adjusted for any reason please contact the Mod-U-Blast service departments for directions. Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 11: Filter Removal And Installation
Do not operate the dust collector with missing or damaged filters. Remove the knob by turning counter clockwise While removing the knob hold the filter lid in place until fully unscrewed and remove the lid. Copyright© 2018 Mod-U-Blast®, All Rights Reserved... - Page 12 When replacing the filters note that the end with the foam rubber seal ALWAYS goes in first whether it’s a single or double filter configuration. Filter Installation Reverse the above procedures when installing new filters Copyright© 2018 Mod-U-Blast®, All Rights Reserved...
-
Page 13: Replacement Filters & Parts List
Electric Coil for Goyen Valve SP-RCAC25 Goyen Valve Repair Kit Replacement Auto Pulse Control Box Complete DC MODEL STOCK NUMBER M2000 16997 M3000 16995 M6000 16998 M9000 16996 M12000 16994 For Supplies and Parts Call - 1-800-661-3842 Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 14: Dust Collector Troubleshooting
Check the dust collector regulator is set to 80 psi and for any air leaks and pulsing repair Pulse valves not working Check to see if the auto pulse box is plugged into a 110 volt receptacle and that the switch is turned to the ON position. Copyright© 2018 Mod-U-Blast®, All Rights Reserved... -
Page 15: Warranty Coverage
Horizontal Filter Dust Collector Owner’s Manual Warranty Coverage Mod-U-Blast equipment is covered by a one (1) year warranty against defects in material and workmanship starting from the purchase date. This covers the equipment as well as all major components. This warranty does not apply to abnormal use of the equipment or parts. Parts considered consumables are not covered by warranty.
