ABR BLASTROOM & PNEUMATIC RECOVERY SYSTEM
ABR BLASTROOM & PNEUMATIC RECOVERY SYSTEM
SUPER IOR PERFO RM A NCE
And Quality In Blast Cleaning Equipment
www.modublast.com
OPERATION & MAINTENANCE MANUAL
OPERATION & MAINTENANCE MANUAL
Ph: (780) 425-5510
B L A S T
!
WARNING
Read Manual
Failure to read, understand &
follow all safety and operation
procedures in this manual can
cause injury or death. Manuals
that are lost, incomplete, or
damaged, must be replaced
immediately.
Manual # ABRP1711
R O O M
LAB-1
Fax: (780) 425-5540
Copyright© 2017 Mod-U-Blast®, All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABR and is the answer not in the manual?

Questions and answers

Related Manuals for Mod-U-Blast ABR

Summary of Contents for Mod-U-Blast ABR

  • Page 1 ABR BLASTROOM & PNEUMATIC RECOVERY SYSTEM ABR BLASTROOM & PNEUMATIC RECOVERY SYSTEM OPERATION & MAINTENANCE MANUAL OPERATION & MAINTENANCE MANUAL B L A S T R O O M LAB-1 SUPER IOR PERFO RM A NCE And Quality In Blast Cleaning Equipment...

  • Page 2: Table Of Contents

    ABR Pneumatic Blastroom Owner’s Manual Table of Contents Important Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

  • Page 3: Important Notice

    Mod-U-Blast Inc. provides a variety of excellent products to the surface preparation industry, and we are confident that all proficient users, operators and contractors in this industry will continue to use our products in a safe and knowledgeable manner.

  • Page 4: Warnings

    ABR Pneumatic Blastroom Owner’s Manual Warnings WARNING: Over time, exposure to any dust could result in lung medical issues or death. Use a reverse pulse dust collector with HEPA filters if lead or other toxic materials are removed from items during the blasting process.

  • Page 5: Important Safety Items

    • Keep the blast nozzle controlled and aimed at the work always. 1.5 Maintenance • Disconnect the power and air supply from all components before servicing. • Keep all components in good repair. Use Mod-U-Blast parts only and do not substitute or modify. For Service Call: 1-800-661-3842...

  • Page 6: Pneumatic Reclaim Components Description

    ABR Pneumatic Blastroom Owner’s Manual Pneumatic Reclaim Components Description SWEEP-IN SECTION • The sweep-in section is 8 feet in length with a transition elbow on the outside of the blastroom and a raised air inlet at the other end inside the unit.

  • Page 7: Pneumatic Blastroom Maintenance

    ABR Pneumatic Blastroom Owner’s Manual Pneumatic Reclaim Components Description cont’d RESPIRATORY SYSTEM • Contaminants in the air supplied to workers can cause serious injury and/or death. Ensure you breathing air system is complete and functioning correctly. • The air supplied respirator consists of a helmet with inner and outer protective lenses, an internal air delivery system and a protective cape.

  • Page 8: Pneumatic Reclaim Components

    ABR Pneumatic Blastroom Owner’s Manual Pneumatic Reclaim Components Reclaimer outlet 12” elbow with damper 6” Rubber lined pick-up hose 1600 CFM Reclaimer 20 Cu. Ft. Hopper Sweep-In transition elbow Screen and Sweep-In Sweep-In transition Sweep-In Air Inlet elbow 2 part...

  • Page 9: Basic Principles

    3.1 Location Before setting up your Blastroom and components remember the following points: • The Mod-U-Blast Blastroom components require a compressed air supply. NOTE: The compressed air supply to this unit needs to be dry. • The Blastroom control panel requires a power supply of ______volts 3 phase •...

  • Page 10: Control Panel Operation

    ABR Pneumatic Blastroom Owner’s Manual 3. Set-Up Requirements cont’d 3.2 Initial Adjustments cont’d • The regulator a the top of the air tank on the back of the dust collector has been pre-set to 80 psi and is to remain at that pressure.

  • Page 11: Blasting Preparation

    ABR Pneumatic Blastroom Owner’s Manual 5. Blasting Preparation 5.1 Initial Loading the Media To initially charge the system with media: • Turn on the main power at the control panel. • Turn on the Blastroom lights. • Ensure that the damper in the elbow of the reclaimer is only 1/2 open. See section 3.2 on page 9 for clarification.

  • Page 12: Pneumatic Recovery System Troubleshooting

    DC waste Warranty Coverage Mod-U-Blast equipment is covered by a one (1) year warranty against defects in material and workmanship starting from the purchase date. This covers the equipment as well as all major components. This warranty does not apply to abnormal use of the equipment or parts. Parts considered consumables are not covered by warranty.
