Summary of Contents for Alva eph62
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION As with all appliances, misuse of this appliance or failure to fully follow these instructions may cause fire, injury or death. Please read the Please read all the instructions before using your heater. instructions carefully If you have any doubt or concerns about this appliance’s before use. - Page 3 • Please take care to dispose of replaced heating element carefully. These can shatter and cause injury if not handled carefully. Keep away from children at all times. • Keep the heater a distance of at least 1 Meter from any combustible material, such as furniture, curtains, bedding, clothes or paper.
- Page 4 PARTS DIAGRAM INSTALLATION 5 - 6 Cautions and USING YOUR HEATER warnings. USING YOUR REMOTE 8 - 10 MAINTENANCE 11 - 12 TROUBLE SHOOTING Danger TECHNICAL DATA AFTER SALES SERVICE Contact an approved ALVA technician. Do It Yourself Instructional video available...
-
Page 5: Warranty
Alva heater. near the heater. If this product is not what you want or need, please help Alva and the environment by not damaging or destroying any part of the packaging, the manual or the Styrofoam inserts. -
Page 6: Parts List
PARTS LIST Mesh Always ensure that the Heater Element heater is unplugged when not in use, Reflector Board installing, cleaning and Side Reflector board replacing the emitter. Heating element fixed holder Small cover board Right cover Left cover Square Nuts Fixed holder Display cover Display cover protection... -
Page 7: Parts Diagram
PARTS DIAGRAM... -
Page 8: Installation
INSTALLATION Must be horizontallly positioned Please select the location carefully, allowing 1m clearance from any combustible surface. The distance of your appliance from the ceiling is a minimum of 0.7m. The appliance must be placed 1m away Please do not extend the power cord. from a person. - Page 9 Slide the 4 feet fully down into the groove of the bottom mount as shown. (Fig 1) Screw the collar into position to prevent 4 feet from coming out. (Fig 2) Risk of fire: Keep combustible Attach angle brackets to heater head as shown in (Fig 3) materials such as Do not tighten screws so the brackets can still slide on...
-
Page 10: Using The Heater
USING THE HEATER Before proceeding to • Place heater on level ground so it is stable & cannot use the heater, make fall over sure you understand the “IMPORTANT SAFETY • Adjust the height of your heater by loosening the adjuster INFORMATION”... -
Page 11: Using Your Remote
Press Power button once again, the digital screen shows for High heat set- ting (Figure G) Fig.G 6. Once you have selected your function the 1 - 24 hour shut down can be set. The digital screen showing indicates 1 hour and indicates 2 hours. - Page 12 Turn the power on, the unit will beep once. The digital screen and the indicator will now display. Once this happens press the On/Off button to enter standby mode. Press the function button to select your power level. The P.0 indicator will appear on the screen and will flash 3 times, indicat- ing that the appliance is in Standby mode.
- Page 13 Heating recommendations Set the heat level dependent on the area you wish to heat • It is recommended to set the heat to HIGH when installed in large rooms or open areas. Fig.J Direct the heater using the appropriate angle. (Figure J) Fig.K Prevent the loss of direct heat through windows.
-
Page 14: Maintenance
MAINTENANCE It is necessary to periodically wipe the heater and the reflector, depending on the placement and circumstances of its use. Cleaning the reflector: Disconnect the power supply cable from the socket. Remove the protective grid from the heater body. (Figure L) Wipe the reflector using a soft detergent treated cloth. -
Page 15: Troubleshooting
For replacement heating element Please contact ALVA SERVICE TROUBLESHOOTING CENTRE 086 100 ALVA (2582) SYMPTOM CAUSE SOLUTION Heater will not turn Not plugged in Plug in and switch on socket. -
Page 16: Technical Data
MANUFACTURED FOR AND DISTRIBUTED BY element sare Alva Marketing (Pty) Ltd avaliable from Alva. P.O. Box 30014 086 100 ALVA (2582) Tokai, 7966 Tel: 021 442 1540 E-mail: info@stingray.co.za www.alva.co.za @StingrayGroupSA www.facebook.com/AlvaGas TOLL FREE NUMBER 086 100 ALVA (2582)
