Bogen UTI1 Specifications

Universal
Telephone
Interface
Model UTI1
The UTI1 Universal Telephone Interface provides single-zone paging for one-way applications such as
Description
self-amplified speaker systems. It is compatible with all standard analog port types and includes two audio
outputs with level controls, each of which can provide audio for 150 Bogen self-amplified speakers.
A 24V DC @ 1A internal power supply is available to power external equipment.
Features • Single-zone paging
• Telephone interfaces: loop start trunk, ground start
trunk, station access (analog ring-up), page port
contact closure activation, page port voice
activation
• Simple 2-switch interface setup
• Override paging (using loop start trunk or page
port contact closure activation)
• Programmable activation of AUX contacts
• C-form contact
• Two audio outputs (Page Only and Page with
Background Music) both with level controls
• Each output can provide audio drive for 150 self-
amplified speakers
• High impedance transformer-isolated background
music input with volume control
• Variable music mute
• Night Ringer (contact closure activation)
• Tone Trigger (tone and duration selectable, closure-
activated)
• Tone burst (2 to 7 sec), chime, and slow whoop
tone selections
• Pre-Announce/Confirmation Tone
• Adjustable output limiter with threshold control
and active indicator
• Programmable timers control page duration
(station and trunk)
• DTMF programming
• DTMF Block to help suppress DTMF tones over
paging system
• Non-volatile memory for setup data (no backup
battery required)
• Setup Tone to assist in volume setting
• Pluggable terminal strips
• Microcontroller-based operation
• Wall mounting flanges
• Rack panel kit with security cover available
(RPKUTI1 sold separately)
• Two-Year Warranty
RPKUTI1
Specifications subject to change without notice.
© 2005 Bogen Communications, Inc.
Part No. 54-8017-01A Printed in U.S.A. 0501
