Panchromatic
Eumig S810 S810D S810D Lux
User Manual
The Place to find Antique, Vintage, Retro or just plain used, 8 mm Super 8 mm 9.5 mm, 16 mm Film
Projectors, Slide Transparency Projectors in Various Formats and also a selection of Camera &
Darkroom Equipment. Serviced, Refurbished & Reconditioned
Eumig S 810D
User Manual
Eumig Austria
www.Panchromatic.co.uk
Service@Panchromatic.co.uk
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eumig S 810D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panchromatic Eumig S 810D

  • Page 1 The Place to find Antique, Vintage, Retro or just plain used, 8 mm Super 8 mm 9.5 mm, 16 mm Film Projectors, Slide Transparency Projectors in Various Formats and also a selection of Camera & Darkroom Equipment. Serviced, Refurbished & Reconditioned Eumig S 810D User Manual Eumig Austria www.Panchromatic.co.uk...
  • Page 2 Panchromatic Eumig S810 S810D S810D Lux User Manual YOU have chosen a EUMIG sound movie projector because you are moving with the times and are no longer content with silent films. Your selection of an H.Q.S. unit (High Quality Sound top performance in magnetic sound films not only provides the features of simple and straightforward projection and sound recording, but also offers a supreme sound experience.
  • Page 3 Panchromatic Eumig S810 S810D S810D Lux User Manual Rear reel arm. Cover of sound unit. Securing screw of sound unit cover. Focusing control. Front reel arm. Locating halos for daylight viewer(accessory). Frame line adjustment. Elevation control. Mains supply lead. Supply voltage selector.
  • Page 4 Panchromatic Eumig S810 S810D S810D Lux User Manual Lens. Automatic threading key. Type “S” film pressure pad. Type “S” film guide. Large type “S” sprocket. Running speed adjustment. Lamp house cover. Film trimmer. Line output. Audio, radio and microphone input.
  • Page 5 Panchromatic Eumig S810 S810D S810D Lux User Manual Playback & Recording at a Glance Page Number The projector features Additional items Playback & Recording at a glance Accessories supplied with projector Before connecting to the mains supply Changing the film gauge...
  • Page 6 Panchromatic Eumig S810 S810D S810D Lux User Manual Accessories supplied with projector 1 x Film trimmer 790.0340/0 Strip off the protective foil and attach the trimmer by its self- adhesive base to the projector to have it conveniently at hand. Fit it in such a position that no film trimmings can drop into the projector.
  • Page 7 Panchromatic Eumig S810 S810D S810D Lux User Manual Before connecting to the mains supply The voltage and frequency of your projector must match those indicated on your mains supply meter. a) Voltage If the mains voltage does not match. unscrew the fixing screws A, remove the back, pull off the red plug B towards the left and attach it to the correct terminal, Some supply systems are liable to carry temporary overvoltage’s which can lead...
  • Page 8 Panchromatic Eumig S810 S810D S810D Lux User Manual For safety in transit, the motor is secured in its central position by two restraining screws E. Before you first connect the projector to the mains these must be removed (unless already removed by your projector supplier).
  • Page 9 Panchromatic Eumig S810 S810D S810D Lux User Manual Alternative parts for Super-B and Single-8 projection Grey  Large type "S” film sprocket, light front face 716.1171/0  Small type "S” film sprocket, light front face 703.1511/5 Consisting of:  Type "S" film pressure pad 718.1132/1...
  • Page 10 Panchromatic Eumig S810 S810D S810D Lux User Manual Automatic threading The film automatically threads itself through to the take-up reel core. An ingenious system automatically sets the correct the picture/sound separation (18 frames with Super-8 and Single-8, 56 frames with standard-8) A few points...
  • Page 11 Panchromatic Eumig S810 S810D S810D Lux User Manual If due to perforation damage or other causes the image appears unsteady on the screen or the projector rattles during running (or both), briefly depress the threading key during projection. If this does not help, briefly switch from forward to reverse projection (or vice versa).
  • Page 12 Panchromatic Eumig S810 S810D S810D Lux User Manual Once the film is threaded and the projector is running: Adjust the projected image size by turning the zooming ring. Focus the image sharply by turning the line focusing control. Adjust the frame line control if parts of two frames appear on the screen with a frame line between them.
  • Page 13 Panchromatic Eumig S810 S810D S810D Lux User Manual SOUND RECORDING Easy recording with striped film and automatic controls. Sound recording Is supremely easy with EUMIG projectors, because they are designed for magnetic sound films. Once your film has been striped (your photo dealer can get that done for you), you use your EUMIG sound projector virtually like a tape recorder.
  • Page 14 Panchromatic Eumig S810 S810D S810D Lux User Manual Recording through the microphone The amplifier incorporates a novel ACFC recording control system (automatic gain and frequency response control) so that the recording always conveys the correct oral impression whether the microphone is close to or further away from, the sound source.
  • Page 15 Panchromatic Eumig S810 S810D S810D Lux User Manual The procedure is simple Connect the tape recorder, record player etc. to the socket (1) Turn the mixing control fully to the right to engage (2) Press the red recording key (3) Turn main switch all the way to “forward projection”...
  • Page 16 Panchromatic Eumig S810 S810D S810D Lux User Manual Abrupt music cuts For transitions between greatly differing shots an abrupt music cut is more appropriate. Here the mixing control always remains fully turned to the right and engaged. 1 Terminate the first recording and wind the film back exactly to the point of the cut.
  • Page 17 Panchromatic Eumig S810 S810D S810D Lux User Manual Sound Mixing Often background music is all you need. But sometimes you may want to add a spoken commentary or special sound effects. This is easy with the mixing control. Once the music is recorded, re-thread the film end insert the micro- phone into the socket.
  • Page 18 Panchromatic Eumig S810 S810D S810D Lux User Manual When you have finished speaking, turn the mixing control back to the left, this ends the mixing sequence and the music regains its original level. This sequence of fading in and out is carried out for every speech passage.
  • Page 19 Panchromatic Eumig S810 S810D S810D Lux User Manual The mixing control, as we have seen, permits soft music dissolves and over recording of commentary or sound effects while attenuating an already recorded music background. In this sound recording mode the yellow mixing signal lamp lights up.
  • Page 20 Panchromatic Eumig S810 S810D S810D Lux User Manual Erasure of a previous sound recording takes place automatically during every new recording. The only exception is during mixing (page 12). But you can also erase a track without recording a new one, by switching the main switch to "forward projection without a...
  • Page 21 Panchromatic Eumig S810 S810D S810D Lux User Manual You can, also feed the projector output into an external amplifier. Plug this into the line output. Check that the connecting lead is correctly wired The EUMIG Universal Re-recording Lead Order No 790.260/2 Unfortunately, audio units do not have standardised output sockets, nor are connecting leads always wired the same way.
  • Page 22 Panchromatic Eumig S810 S810D S810D Lux User Manual Changing the lamp (disconnect the mains lead first) Lamp type: 12 volt/100 watt tungsten-halogen lamp with dichroic reflector. Order N0. 031.004/6. Not even the best lamp lasts for ever. If it falls you can easily change it yourself.
  • Page 23 Panchromatic Eumig S810 S810D S810D Lux User Manual through connection to the incorrect mains voltage Remove the back cover, the fuse is then visible at the left of the amplifier circuit board. Cartridge fuse 5 x 20 mm; 2 amps surge resisting Order No.
  • Page 24 Panchromatic Eumig S810 S810D S810D Lux User Manual Film care Various film preservatives are available from photo dealers; use them for periodic treatment of your films. The best way is to run the Mm through a soft cloth soaked with the cleaning agent Films to be striped should only be cleaned with a soft and fluff less linen cloth dampened with surgical spirit.
  • Page 25 Panchromatic Eumig S810 S810D S810D Lux User Manual Technical Data  Low ohm input (microphone): 0.3 —I50 mV. 22kOhrn  High ohm input (phono): 50mV-3V 1 MOhm  Automatic recording Level control: Compensates level fluctuations up to 5O db. Response time 10 milliseconds, hold time - depending on input level duration - up to 60 seconds.
  • Page 26 Panchromatic Eumig S810 S810D S810D Lux User Manual Page...
  • Page 27 Panchromatic Eumig S810 S810D S810D Lux User Manual Page...
