Remote Volume Control Panel
Model RVCP
General
The RVCP fits in a standard single gang electrical box and may be installed using the
included hardware. Be sure to make all electrical connections prior to installing the
RVCP into an electrical box.
Electrical Connections
Minimum 24-gauge, 3 conductor wire is recommended. Maximum wire length run of
2,000 feet.
Connect similarly labeled terminals on the Bogen amplifier or control unit and RVCP
together. UP to UP, Common (C) to Common (C), and down (DN) to down (DN).
DAISY-CHAINING
Multiple RVCP's can be daisy-chained from control panel to control panel for multi-
ple locations. Parallel like labeled terminals on each RVCP together.
Orientation
Make certain that the RVCP is in the proper orientation when it is installed.The arrow
on the back should be pointing up towards the ceiling.
Specifications subject to change without notice.
© 2002 Bogen Communications, Inc.
Part No. 54-2075-01R1 Printed in Korea. 0206
50 Spring Street, Ramsey, NJ 07446, U.S.A.
Tel. 201-934-8500, Fax: 201-934-9832, www.bogen.com
