- Page 1 Important: Read this whole manual before assembling Owner’s Manual for Engage Interact Satisfy Enviro Kiosk H32-260-100 OM-08/27/2019...
-
Page 2: Table Of Contents
ANUALS ................................. 17 ERIAL UMBERS ..............................18 OLVING ROBLEMS Troubleshooting Tips ............................18 WARRANTY ................................19 ..............................19 IMITED ARRANTY Returned Item ..............................19 Shipping ................................19 ............................... 19 ERMS AND ONDITIONS Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 3: Introduction
Introduction Product Description This state-of-the-art Outdoor Enviro Kiosk can take on any environment. With a 19" self- adjusting sunlight-readable monitor with cooling and heating options, the Enviro Kiosk will meet all your outdoor needs. With options such as a credit card reader, camera, receipt printer, external keyboard, bar code scanners, VoIP Handset, transducer speaker system, and computer upgrades, the Enviro kiosk can be customized to suit a wide range of needs. -
Page 4: Our Support
Our Support The Enviro Kiosk is a reasonably priced, high quality kiosk. We are happy to help you with any problems after you have read the manuals to learn about this product. Advanced Kiosks will support you in ownership as long as you own your kiosk, within reason. -
Page 5: Installation
Installation Installing the Kiosk Enclosure The Enviro Kiosk should be mounted to a solid surface using appropriate anchors for adhering objects to that surface. A specific anchor may work well for concrete but may not be appropriate for a wooden surface. It is advised to consult a professional and reference local building codes and regulations to determine the most appropriate or required anchor. - Page 6 Tighten the nut until finger tight, always turning clockwise. Using a wrench or socket, turn 2-4 times until you are sure it is snug. Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19...
-
Page 7: Dimensional Drawings
Dimensional Drawings Enclosure Dimensions 1 Base Dimensions 1 Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 8: Power Considerations
Earthquake Zones If the Enviro Kiosk is located in an area prone to earthquakes a professional engineer should consulted to recommend installation requirements to adhere with the building codes in your region. Also note the following. If needed, Advanced Kiosks can supply additional brackets specified per your professional engineer’s review. -
Page 9: Installing Equipment
Power to Kiosk The Enviro Kiosk has been shipped with all power connections and plugs attached within the power box, so that the kiosk can be tested and configured BEFORE permanently installing. -
Page 10: Computer
Wi-Fi The Enviro kiosk does not come with Wi-Fi. While there are two available USB ports that a USB Wi-Fi adapter may be plugged into. Advanced Kiosks does not recommend the option. We recommend an insulated cat... -
Page 11: Power Box
For anything to work the main power must be turned on, other components may be selected as desired, but it’s recommended all be left on. On First Power Up, Turn ALL Component Switches ON, Then Switch Power ON Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 12: Setup And Operation
In testing/configuration phase (before permanent installation) take care that the power cord is managed in such a way that it persons walking by will not trip or get caught on the cord. Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 13: Startup
12v (If the that’s fine, but if voltage isn’t exact there is anything outside of a 1.0v difference from 12v, shut the power Advanced Kiosk’s). off and contact Switches on in Position 1 Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 14: Back Up Your Information
Computers aren't perfect. Files become corrupt, motherboards malfunction, electrical storms strike and CPUs call it quits taking our precious data with them. Advanced Kiosks cannot recover your data. If a replacement, or repaired kiosk is required it will be shipped with our standard installation. -
Page 15: Specifications
Automatic Brightness Control Yes, 300 - 1100 nits Brightness 1100 nits Response Time 20msec Viewing Angle Horizontal: 140° total Vertical: 140° total Contrast ratio (Typical) Contrast 500:1 Power Supply 12VDC Power Consumption (Typical) Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 16: Kiosk Physical Specs
Voltage Input Range 100-240VAC Watts @ 110VAC 106.7 W Kiosk Shipping Specs Ships In/On Crate Weight (lbs.) 255 lbs. Dims (L x W x H) Inches 64"L x 28"W x 32"H Logistics Freight Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 17: Maintenance Of Kiosk
• DO NOT use pressure washers to clean kiosk. Water could potentially get through the seals. • DO NOT use leaf blowers near or on kiosk. For other questions, visit our knowledge base at https://advancedkiosks.com/knowledgebase/ Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 18: Equipment Manuals
Equipment Manuals With your Enviro Kiosks, all the documentation for all your components has been included. Please keep these in a safe place. It is recommended that all serial numbers are also written down. Serial Numbers Write all your equipment Serial Numbers here and keep this document in a safe place. The Enviro Kiosk, Serial Numbers are located: 1. -
Page 19: Solving Problems
Drivers can be accessed at our website by completely filling out the Technical Support Form. If more help is needed, fill out a support ticket at https://advancedkiosks.com/about-advanced- kiosks/technical-support/, and include your serial number, and we will try and get back to you as soon as possible. Enviro Kiosk Assembly and Operation Instructions www.advancedkiosks.com 8/27/19... -
Page 20: Warranty
Shipping When shipping the Enviro Kiosk, it must be well packaged, secured to a pallet, and insured. We highly recommend taking pictures of the packaged kiosk before shipping. Terms and Conditions Please visit our Terms and Conditions page for more detailed information: http://www.advancedkiosks.com/company-policies/terms-and-conditions.php...
