Technical Specifications - Nemtek Fence Meter Manual

1 Introduction
The NEMTEK Fence Meter measures the electrical condition of an electric fence.
By holding the meter against the fence wire the meter will turn on automatically
when it detects a fence voltage. The fence voltage, current and the direction of
a possible fence fault will be displayed on the LCD. The meter will automatically
turn off after a few seconds when not in use.

2 Technical Specifications

Parameter
Voltage Display Range
Current Display Range
Automatic Turn-On Voltage
Battery Type
Battery Life
Operating Temperature
*Measured at a pulse length of 100ms and direct earthing
Value
-14kV to 14kV
1A to 85A
<-150V or >150V*
2 x 1.5V AAA
~150 hours
-10°C to 50°C
