- Page 1 Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2021...
-
Page 2: Table Of Contents
Dimming Delay LCD Backlight Settings System Reset DMX Values In-Depth 5. Appendix Keeping Your UVonix™ Blackstar As Good As New Returns (Gasp!) Shipping Issues Tech Specs! Dimensional Drawings Page 2 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 3: Getting Started
Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. You can download the latest version of this document from www.blizzardpro.com. -
Page 4: Safety Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www.blizzardpro.com/support. Page 4 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 5: Meet The Uvonix™ Blackstar
DMX Quick Reference (2-Channel Modes) What It Does Dimmer Dimmer (fine 16-bit) DMX Quick Reference (4-Channel Modes) What It Does Strobe Effects Dimmer Dimmer (fine 16-bit) 32-Bit Dimming Curves Page 5 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 6: Uvonix™ Blackstar Pin-Up Picture
Knobs Cooling Vents 4-Leaf Barndoor Assembly The Rear Connections Barndoor Lock & Release Safety Loop Control Menu Fuse Power Output DMX Outputs Power Input DMX Inputs Cooling Vents Page 6 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 7: Setup
• Maximum capacitance between conductors – 30 pF/ft. • Maximum capacitance between conductor & shield – 55 pF/ft. • Maximum resistance of 20 ohms / 1000 ft. • Nominal impedance 100 – 140 ohms Page 7 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 8: Cable Connectors
Place a DMX Next terminator on the output of the final fixture to Fixture in Chain ensure best communication. DMX IN DMX OUT Page 8 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 9: Fixture Linking (M/S Mode)
Overhead mounting requires extensive experience, which includes calculating working load limits, knowledge of the installation material being used, and periodic safety inspections. If you lack these qualifications, do not attempt the installation yourself. Page 9 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 10: Operating Adjustments
<ENTER> button to select the menu function currently displayed, or to enable a menu option. To return to the previous option or menu without changing the value, press the <MENU> button. Page 10 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 11: Control Panel Menu Structure
Yes (factory reset) Status Info Sys.Info Firmware version Firmware Sys.Info Total hours in use Op. Hours Sys.Info Led.Temp (xxxC) Temp Led.Temp (xxxF) Sys.Info Fan.Volt (xxxV) Fan.RPM (A:xxx) Fan.RPM (B:xxx) Page 11 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 12: Starting Dmx Address
S-Curve, and press <ENTER>. Linear Logarithmic Exponential S-Curve DMX% DMX% DMX% DMX% Note: Smoother (and slower) dimming capabilities can be achieved with use of the 4 available dimming curve settings. Page 12 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 13: Dimming Frequency
Fine dimmer (0% <--> 100%) Dimming Curves 000 <-> 005 No Function 006 <-> 063 Linear 064 <-> 127 Logarithmic 128 <-> 191 Exponential 192 <-> 255 S-Curve Page 13 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 14: Appendix
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 14 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... -
Page 15: Tech Specs
Other Operating Modes DMX-512, M/S, and Standalone 2-year limited warranty, does not cover malfunction Warranty caused by damage to LEDs. Dimensional Drawings 12.8" (325mm) 11.4" (293mm) 9.4" (238mm) Page 15 UVonix™ Blackstar Manual Rev. A © 2021 Blizzard Lighting, LLC... - Page 16 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
