Think safety think Steelmate
Steelmate Co., Ltd. All rights reserved.
The right to change the design and specifications reserved.
The trademark, patent and copyright are owned by
Steelmate Co., Ltd.
STEELMATE CO., LTD.
Steelmate Industrial Park, Heping Street, Dongfu Road, Dongfeng Town,
Zhongshan City, Guangdong, P.R. China 528425
Front & Rear Parking Assist System
Manual
PRI0886R/A
PTS810 V10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Steelmate PTS810 V10
Summary of Contents for Steelmate PTS810 V10
- Page 1 The right to change the design and specifications reserved. The trademark, patent and copyright are owned by Steelmate Co., Ltd. STEELMATE CO., LTD. Steelmate Industrial Park, Heping Street, Dongfu Road, Dongfeng Town, Zhongshan City, Guangdong, P.R. China 528425 Manual PRI0886R/A...
-
Page 2: Table Of Contents
Contents User Manual Installation Manual Important notice ---------------------------------------- Brief installation diagram ---------------------------- Disclaimer ----------------------------------------------- Includes -------------------------------------------------- About the product -------------------------------------- Installation tools ---------------------------------------- Key features -------------------------------------------- Sensor installation ------------------------------------- Specifications ------------------------------------------- Wire connection ---------------------------------------- LCD display --------------------------------------------- Functional test ------------------------------------------ Self-testing function ----------------------------------- Troubleshooting ---------------------------------------- Volume adjustment ------------------------------------... -
Page 3: Important Notice
Important notice About the product Key features LCD display Parking Assist System (PAS) helps to provide This PAS comes with 8-sensor and a display that Slim black display with digital showing Matrix obstacle position assistance when reversing and parking. Driving is an ultrasonic detects the area behind the vehicle Complete front &... -
Page 4: Self-Testing Function
Self-testing function Volume adjustment 1. When ACC ON, the system will test 4 front sensor (E,F,G,H) automatically. Once ACC ON and reverse gear is selected. press "SET" button to select the volume level, it will saved and exit after 1 second later. ("3" for Max, "2" for Middle, "1" for Min) 1) Normal 2) Damaged or defective sensor is detected Default setting: Max volume... -
Page 5: Learning Function For Cars With Tow-Bar Or Spare
Learning function for cars with tow-bar or spare wheel Dual intelligent function When this function is ON, the detected distance will increase 20cm between the sensor and obstacle which is designed for the tow-bar/ Spare wheel. Be------ 1" With the ignition "ON", change the gear from "N" to "R" for 10 times (Each gear change must be within 1 second) 0.3m After 10th times, leave the gear in "R"... -
Page 6: How Does The System Work
How does the system work Sensor sensitivity adjustment Driving forward (6 sensors) Be---Be--- Be------ Distance: >0.6m/2.0ft Distance: 0.4m/1.2ft Distance: (<0.30m/1.0ft) Jumper position: "55~65cm" Jumper position: "45~54cm" (Default setting) Normal sensor sensitivity Low sensor sensitivity Recommended for the sensor which is installed Recommended for the sensor which is installed between 55~65 cm from ground between 45~54 cm from ground... - Page 7 Driving forward (8 sensors) Reversing Be---Be--- Be------ Be------ Be---Be--- No Beep Distance: >1.0m/3.3ft Distance: 0.4m/1.2ft Distance: (<0.30m/1.0ft) Distance:<0.3m/1.0ft Distance:0.8m/2.6ft Distance:>1.5m/4.9ft +12V +12V +12V...
-
Page 8: Attention
Attention Sensor maintenance Zigzag reversing False detection may occur in the following situations: Do not wash the sensor with squirt gun or swab them forcibly. Please wash car with low-pressure water. Please melt the ice with water when the sensors are covered by ice. -
Page 9: Installation Manual
Installation Manual Includes Brief installation diagram The above graphics are for reference only. Installation tools Display 60' ~ 80'... -
Page 10: Sensor Installation
Sensor installation The sensor head angle can be changed to compensate for angled bumpers. Please see the instructions overleaf. H > 45cm/1.5ft H > 45cm/1.5ft H < 65cm/2.1ft H < 65cm/2.1ft < 45cm/1.5ft < 45cm/1.5ft < 45cm/1.5ft H < 45cm/1.5ft 1.0m/3.3ft 35cm/1.1ft<L1<45cm/1.5ft 45cm/1.5ft<L2<55cm/1.8ft... - Page 11 Change of sensor cover. (Built-in) Check the size of the hole saw packed in the product to be matching the diameter of the sensors before drilling any holes. Tips: Make sure the degree marking is on the top of sensor after plug in.
- Page 12 Hint: If a gap found between bumper and 10 sensor cover after installation, please adjust the angle of the hole shown as below. Bumper Angle...
-
Page 13: Wire Connection
Wire connection Display A B C D E F G H Pink ACC+ Reversing light White Footbrake light Black... -
Page 14: Functional Test
Functional test Troubleshooting 1. After installation, the buzzer/display doesn't Plug the certified sensors into the ECU and Functional testing is possible work. performing a functional test again. by holding a wooden board Make sure the wires connected properly. Please email us at sales@steel-mate.com (0.3 x1.0m/1x3.3ft) standing Make sure the vehicle is ACC ON.
