Summary of Contents for Hisense 50A7G
- Page 1 Bar code...
- Page 2 50A7G 55A7G 65A7G 75A7G QUICK SETUP GUIDE Before using the TV, please read this guide thoroughly and retain it for future reference. For more detailed instructions, please see the User Manual or the E-Manual. English ES-A210802-1...
- Page 3 Important Safety Precautions This symbol alerts user about the ATTENTION presence of a dangerous voltage not isolated inside the product which can RISK OF SHOCK ELECTRIC be sufficiently powerful to constitute a risk of electrocution. Do not open the back cover. This symbol alerts user about the In no case the user is allowed to operate presence of important operating...
-
Page 4: Table Of Contents
Contents Figures and illustrations in this manual are provided for reference only and may differ from actual product appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand ......................2 Installing the Wall Mount Bracket ...................4 TV Front..........................5 TV Rear ..........................6 Making Connections .......................7... -
Page 5: Installing The Stand
Installing the Stand or Wall Mount Bracket CAUTION Be sure to disconnect the AC power cord before removing a base stand or installing wall mount brackets. The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure. - Page 6 Installing the Stand or Wall Mount Bracket For 65"/75" Attention: According to the size of the TV supporting surface, you can select one of the base stand installation patterns, as shown in the figure. Screws： M5×16(65") M5×12(75") Base Stand Screws： M5×16(65") Base Stand M5×12(75")
-
Page 7: Installing The Wall Mount Bracket
Installing the Stand or Wall Mount Bracket Installing the Wall Mount Bracket Before mounting the TV, remove the TV stand if you have already attached it, and make sure the wall mount bracket supports the weight of your TV. CAUTION When mounting the TV on a wall, follow instructions provided with the wall mount bracket. -
Page 8: Tv Front
TV Front TV Front Remote sensor/Power indicator/Single button (Standby/Source) Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is red in standby mode. Press the button to turn the TV on. -
Page 9: Tv Rear
TV Rear TV Rear AC INPUT DIGITAL AUDIO OUT NOTES Check the jacks for position and type before making any connections. Loose connections can result in image or color problems. Make sure that all connections are tight and secure. The TV may not be compatible with all external devices. To check compatibility, please refer to the user manual of external device. -
Page 10: Making Connections
Making Connections Connect an outdoor VHF/UHF antenna or cable. Outdoor Antenna TV JACK Cable ANT OUT (not included) Antenna Cable (75Ω) VHF/UHF Antenna HDMI / AV Connect a HDMI / AV cable from an external AV equipment. No sound connection is needed for HDMI to HDMI connection. - Page 11 Making Connections HEADPHONE Connect Headphone for audio out of the TV. TV JACK ATTENTION Excessive sound pressure from earphones and headphones can cause hearing loss. Headphone (not included) NOTE Please make sure that the headphone you plug in is without microphone function, or it may not be supported.
- Page 12 Making Connections Connect the USB1.1 and USB2.0 devices such as hard drives, USB sticks and digital cameras for browsing photos, listening music and watching movies. TV JACK DC 5V 0.5A(MAX) DC 5V 1A(MAX) NOTES When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply.
- Page 13 Making Connections Wireless setup Connect your TV to your wireless network, you need a wireless router or modem. See the illustration below. · The TV’s built-in Wireless LAN Adapter supports the IEEE 802.11 a/b/g/n/ac communication protocols. Wireless router with DHCP Wireless LAN Adapter LAN Cable built-in TV set...
-
Page 14: Remote Control
Remote Control Select input sources Power on/ Standby Select a channel or input numbers Display the Channel Display the Electronic List on the screen Program Guide (DTV mode) Special function buttons Quick setup Playpad keys OK / Display the on-screen Navigation buttons keyboard (Up/Down/Left/Right) - Page 15 Remote Control Installing Batteries in the Remote Control NOTE: Check information according to the actual remote control in the accessory bag. 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
- Page 16 Remote Control Remote Control Operation Range 1. The remote control can work at a distance of up to 8 meters in front of the TV set. 2. The remote control angle: taking the remote sensor as an apex, 6 meters away, its controlled horizontal angle is within ±30°, while the vertical angle is within ±15°.
-
Page 17: Turning The Tv On For The First Time
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. 3. -
Page 18: Specifications
Specifications Features, appearance and specifications are subject to change without notice. If you encountered difficulty when setting up your TV, we suggest you refer to the troubleshooting tips in the User Manual or the E-Manual. 50" 55" Item Without Stand 1117 ×... - Page 19 Specifications 65" 75" Item Without Stand 1449 × 835 × 78 1675 × 960 × 78 (W × H × D) Dimension (mm) With Stand 1449 × 906 × 306 1675 × 1046 × 366 (W × H × D) Without Stand 18.5 27.9...
-
Page 20: Other Information
Other Information The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation.
