RHINO RFCEC001 Safety & Operating Instructions Manual

Ultra ec controller with thermal probe.

Advertisement

Nutriculture UK Ltd
3–5 Paddock Road
West Pimbo
Skelmersdale
WN8 9PL
www.nutriculture.co.uk
Made in PRC
Rhino Ultra EC Controller
with Thermal Probe
Safety & Operating Instructions
Model: RFCEC001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFCEC001 and is the answer not in the manual?

Questions and answers

Summary of Contents for RHINO RFCEC001

  • Page 1 Rhino Ultra EC Controller with Thermal Probe Safety & Operating Instructions Model: RFCEC001 Nutriculture UK Ltd 3–5 Paddock Road West Pimbo Skelmersdale WN8 9PL www.nutriculture.co.uk Made in PRC...
  • Page 2 THERMAL PROBE GENERAL INFORMATION This Rhino Ultra EC fan controller is a smart controller as it plugs directly into your Rhino Ultra EC fan. It has been designed with the latest technological intelligence enabling it to react to changes in temperature and adjust the fans accordingly.
  • Page 3 Thermal Probe Model: RFCEC001 Model: RFCEC001 SCREEN ICONS AND BUTTONS KEY FEATURES CONNECT UP TO 4 FANS This controller can connect and manage up to four Rhino Ultra EC fans. FAN SPEED AUTO MODE ICON ICON FAN 4 FAN 2...
  • Page 4 Model: RFCEC001 WALL INSTALLATION CONNECTION AND SET-UP STEP 1 Operation with one Rhino Ultra EC fan Disconnect the fan mounting bracket from Connect thermal probe to NTC port. Connect fan to port the back wall of the smart controller. Using OUT1 using the 3.5mm jack wire included with your fan.
  • Page 5 Rhino Ultra EC Controller Rhino Ultra EC Controller with Thermal Probe with Thermal Probe Model: RFCEC001 Model: RFCEC001 FAN CONTROLLER FUNCTIONALITY Powering The Controller Lock Controller Buttons • This speed controller receives power through its • To prevent any changes to your settings, you connection to the fan may lock the controller.
  • Page 6 Rhino Ultra EC Controller Rhino Ultra EC Controller with Thermal Probe with Thermal Probe Model: RFCEC001 Model: RFCEC001 MANUAL MODE AUTO MODE BASELINE SPEED • MANUAL MODE allows you to keep your fan at a constant speed level, • BASELINE (DEFAULT) speed level is the speed level maintained by the...
  • Page 7 Rhino Ultra EC Controller Rhino Ultra EC Controller with Thermal Probe with Thermal Probe Model: RFCEC001 Model: RFCEC001 TEMPERATURE ALARM FAN FAILURE DETECTION AND ERROR MESSAGES • TEMPERATURE ALARM feature allows the • EC fans send frequent tachometer signals to...
  • Page 8 Rhino Ultra EC Controller Rhino Ultra EC Controller with Thermal Probe with Thermal Probe Model: RFCEC001 Model: RFCEC001 • If your controller is connected to four EC fans and the fan connected to OUT CONFORMITY WITH DIRECTIVES 1 port becomes disabled, the controller will beep and display error message All models are CE marked to denote conformity with Directives 2014/35/EU ‘E1’...
