Bogen C10 Technical Specifications

Classic Series
Public Address
Amplifiers
Models C10, C20
C10MOH & C20MOH
The Bogen Classic Series Models C10, C20,
C10MOH, and C20MOH offer dependable perform-
ance and flexibility.
Description
The C10 and C10MOH are rated at 10 watts. The
C20 and C20MOH are rated at 20 watts. All models
are UL and CSA listed.
The MOH models provide a music-on-hold output
from the Aux input source.This output is unaffected
• C10(MOH) & C20(MOH) have 10W and 20W
output power, respectively
Features
• Transformer isolated 4Ω, 8Ω, 16Ω, 25V and 70V
output taps
• Rear panel auxiliary receptacle
• One dedicated MIC 1 input — Lo-Z balanced
• One switchable MIC 2/Aux 1 input
• Contact muting of Aux input
• Transformer-isolated 600Ω telephone paging
input
• Separate rear panel-mounted TEL volume con-
trol
by paging. Screw terminal connections are provided
for 600Ω @ 1 volt and 8Ω at 1 watt. A level control
is also provided on the rear panel.
The Classic Series is designed with discreet comple-
mentary transistor circuitry to assure maximum reli-
ability of power output stages.
• Voice activated muting of Aux input by Tel input
• Variable trigger threshold for voice activation
•MOH models provide 1W @ 8Ω and 1V @ 600Ω
outputs of Aux input (only for telephone music-
on-hold inputs)
• Optional wall mount kit
• Optional impedance matching transformer
10k/600Ω
• UL and CSA listed
Specifications subject to change without notice.
© 1997 Bogen Communications, Inc.
Part No. 54-7852-03R2 Printed in U.S.A. 0203
