4Ddoors 4DR2 Installation Instructions And User Manual

Roller door operator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4DR2
Installation Instruction and User Guide
WARNING:
• Please read the manual carefully before installation and use.
• The installation of your new door opener must be carried out by technically
qualified or licensed person.
• Attempting to install or repair the door opener without suitable technical
qualification may result in severe personal injury, death and /or property damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4DR2 and is the answer not in the manual?

Questions and answers

Related Manuals for 4Ddoors 4DR2

Summary of Contents for 4Ddoors 4DR2

  • Page 1 4DR2 Installation Instruction and User Guide WARNING: • Please read the manual carefully before installation and use. • The installation of your new door opener must be carried out by technically qualified or licensed person. • Attempting to install or repair the door opener without suitable technical...

  • Page 3: Table Of Contents

    CONTENTS IMPORTANT SAFETY RECOMMENDATIONS................1 1.PACKAGE CONTENTS....................... 2 2.TOOLS REQUIRED........................3 3.DOOR REQUIREMENTS......................3 4.PRE-INSTALLATION RECOMMENDATIONS................. 4 5.ATTACHING THE WEIGHT BAR....................4 6.CURTAIN FIXING(IF REQUIRED)..................... 5 7.THE RELEASE HANDLE & CORD....................5 8.OPERATING THE MANUAL RELEASE..................6 9.LEFT/RIGHT SIDE INSTALLATION...................7 10.ATTACHING EXTENSION BAR (IF REQUIRED)..............7 11.INSTALLATION PROCEDURE....................7 12.CONTROL PANEL INSTALLATION MANUAL...............8 13.FUNCTIONAL SPECIFICATIONS..................

  • Page 4: Important Safety Recommendations

    Installation Instruction and User Guide IMPORTANT SAFETY RECOMMENDATIONS WARNING · FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS MAY RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR PROPERTY DAMAGE. · PLEASE READ CAREFULLY AND ADHERE TO ALL SAFETY AND INSTALLATION RECOMMENDATIONS.

  • Page 5: Package Contents

    Installation Instruction and User Guide 1.PACKAGE CONTENTS 1. Instruction manual 2. Clamp bracket,plates,washers (2) and nuts (2) 3. Weight bar 4. Transmitter (2) 5. Weight bar screws(2) and nuts(2) 6. Warning label 7. Self-tapping screw（2）（Used for fixing door curtain） 8. Release handle 9.

  • Page 6: Tools Required

    Installation Instruction and User Guide 2.TOOLS REQUIRED 1. Marker pen 2. Adjustable wrench for U-bolts already installed on the door（2） 3. Philips-head screwdriver 4. Rope 5. Drill and 6.5mm drill bit 6. Ladder 7. 8mm, 10mm, 13mm sleeve 300mm extension sleeve (for narrow side mounting) and socket wrench 3.DOOR REQUIREMENTS 1、...

  • Page 7: Pre-Installation Recommendations

    Installation Instruction and User Guide Note: Main Opener body thickness: 88mm (Not including wheel drum). Motor Opener body thickness after lithium battery installed: 93mm (Not including wheel drum). 4.PRE-INSTALLATION RECOMMENDATIONS Please complete the following test under no other force than the torsion force of the door spring to ensure good balance of the door：...

  • Page 8: Curtain Fixing(If Required)

    Installation Instruction and User Guide 6.CURTAIN FIXING(IF REQUIRED) Note：To make sure whether the curtain and drum wheel fixed by two screws or more, if not, in order to there is no balloon, insert the supplied self tapping metal screws into where the curtain leaves the roll.Secure these through the curtain into the drum wheel at each end of the roll.

  • Page 9: Operating The Manual Release

    Installation Instruction and User Guide 8.OPERATING THE MANUAL RELEASE Note：Be careful when operating the clutch, because if the torsion spring fails in the door, the door will momentarily close when the clutch is released, which may cause personal injury and property damage;...

  • Page 10: Left/Right Side Installation

    Installation Instruction and User Guide 9.LEFT/RIGHT SIDE INSTALLATION LEFT To install in this direction, （ RIGHT need switch （ Factory default setting installation direction before installation direction, setting function. need to adjust） switching steps refer section 12, 2-6 installation mode Settings of left/right）...

  • Page 11: Control Panel Installation Manual

    Installation Instruction and User Guide opener sungear assembly as far as possible (without disturbing the roller door) and ensure that one of the reel spokes is completely between the sungear assembly axle or extension poles of the opener. • Install the bracket to replace the roller door axle to the position marked by the wall bracket for locking and fixing.
  • Page 12 Installation Instruction and User Guide AUTO Closing：auto closing setting（LED lights up to indicate mean the auto closing function is opening）. Force Margin：automatic reveres setting. Quick function operation instruction  1、Open/close control (control panel)：Click UP button（open/stop）、click DOWN button （open/stop）； 2、Menu Settings：Long press the SET button； 3、Remote control code：Standby status click the CODE digital tube to display Enter the code checking state, press the same button of the remote control continuously for two or...

  • Page 13: Functional Specifications

    Installation Instruction and User Guide 13.FUNCTIONAL SPECIFICATIONS Note: before setting the stroke, please release the clutch and manually lift the door to the middle position. Once again confirm whether the left/right side of the motor is installed correctly, then lock the clutch, so as to prevent the door body from being damaged in the process of setting the stroke due to the wrong installation setting of the left/right side of the motor or the door body being in the upper/lower limit position.
  • Page 14 Installation Instruction and User Guide ►Motor slow stop function （Reduce the impact of sudden stop on the door body during normal operation） Long press the SET button to enter the menu interface1.- Slow stop function during motor operation Note: this function is for the motor to ...
  • Page 15 Installation Instruction and User Guide Click the SET button to return to the standby screen  means after receiving the stop command, the motor first slows down to 20% speed and then stops. d.Press the SET button to confirm speed selection return standby...
  • Page 16 Installation Instruction and User Guide ►Automatic closing time and condition setting Long press SET button and enter menu interface 1.- Automatic closing function time NOTE ： AUTO closing function switch is set by AUTO Closing a,Long press SET button till the display board Click UP/DOWN button to switch to 3.- function menu show , then press UP or DOWN to choose,...
  • Page 17 Installation Instruction and User Guide Example: using UP or DOWN to switch to 3.2 means 3.The closing condition is set on automatic closing at any location standard in factory. 4.LED light flashes while the door is going to close. 5.If the door controlled by remote or panel during the closing process, the door will no longer close automatically.
  • Page 18 Installation Instruction and User Guide Partial open/height setting a.Long press SET button till the display board ►Partial open/height setting Long press SET button and enter menu interface 1.- show ，hen press UP/DOWN to choose, till display board show PARTIAL （ OPEN/HEIGHT SETTING）...
  • Page 19 Installation Instruction and User Guide ►Photo cell on/off setting Photo cell on/off setting Press and hold SET Button until 1.- appears on the display NOTE ： Our roller door opener need to use the normally closed status NC photo cell device，and need to be connected to PE of opener （Make sure the photo cell has been correctly installed and used Normally closed contacts to the accessory...

  • Page 20: Safety Reverse Test

    Installation Instruction and User Guide 14.SAFETY REVERSE TEST 1、Safety reverse test system steps: Place an obstacle of about 40mm between the floor and the garage door and close the door downward. The door must be inverted when the obstacle is in contact with the rolling door. If the door is stopped on the obstacle, the safety rebound system is not qualified.

  • Page 21: Specification

    Installation Instruction and User Guide 16.SPECIFICATION Input voltage AC220~240V/50-60Hz Max. tension 800N @∅ 300MM Max. door size 20 ㎡ Max. door load 130Kg Max. door height 5.0M Model 24V DC Working frequency 433.92MHz/868.35MHz Optional Working temperature -20℃~50℃ Rated load 45N.M Maximum chuck speed 8.5r/min Code compatibility format...

  • Page 22: Common Faults & Solutions

    Installation Instruction and User Guide 18.COMMON FAULTS & SOLUTIONS Fault appearance Fault cause Solutions No any working for 1. Power supply failure 1. Check whether the opener socket is openers LED 2. Plug wire is loosing energized. screen is not 2.

  • Page 23: Parts List

    Installation Instruction and User Guide 19.PARTS LIST Item Description Item Description Item Description Sungear assembly Transformer Power cable Extend arm Trolley release cord Upper housing （Optional） Chassis sub-assembly Control board Fuse Drive board 24V power socket Front lower housing Decorative cover assembly Operation panel （...

  • Page 24: Maintenance

    Installation Instruction and User Guide 20.MAINTENANCE Daily maintenance： No particular maintenance is required for the logic circuit board. Check the door at least twice a year if it is properly balanced,and all working parts are in good working condition or not. Check the reversing sensitivity at least twice a year,and adjust if it is necessary.
