PRYME PRYMEBLU BTH-700-IC Quick Start Manual

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements, please
avoid direct contact to the transmitting antenna during transmitting.
Version 2.00-IC MARCH 2021

Controls and Connections

HEADBAND / HELMET MOUNTING CLIPS
Depending on the model, the headset
may be furnished with mounting clips
for attaching to a hard hat (SPM-700-IC),
an over-the-head band (SPM-800-IC)
or a behind-the-head band (SPM-900-IC).
PUSH-TO-TALK BUTTON
This button is used to
activate the push-to-talk
feature of the ICOM radio
The PTT button on the
BTH-900-IC is different
than the BTH-700-IC
and BTH-800-IC
VOLUME UP/DOWN BUTTONS
These button are used to adjust
the volume level of received calls
heard through the Headset.
MUFF EARPHONES
Received calls are heard
through these Headset
speakers.
USB CHARGE JACK
This micro-USB jack is used to connect
the supplied charge cable to the Headset
in order to recharge the device's internal
lithium-ion battery pack.
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: 714.257.0600
TOLL FREE: 800.666.2654
WWW.PRYME.COM
BTH-700-IC BTH-800-IC
POWER BUTTON / STATUS LED
Pressing this button for one second
turns the PRYMEBLU Muff Headset
on or off. This button is also used to
place the Headset in pairing mode
so that it can be connected
wirelessly to an ICOM two-way radio.
The status LED behind the button
flashes messages that let the user
know the current status of the
device. For a complete list of LED
messages, see pg 6.
AUX PTT BUTTON
This button can also be used as a
Push-to-Talk button to activate the
PTT feature of the ICOM 2-way radio.
ADJUSTABLE BOOM MICROPHONE
The Muff Headset boom microphone
picks up the user's voice audio to send
over-the-air.
3
PRYMEBLU
Wireless Dual Muff Headsets
The BTH-700-IC/800-IC/900-IC are BT Muff Headsets designed for
use with ICOM BT enabled IC-F3400D and IC-F5400D two-way radios.
CAUTION: This product does not have dual/multi pairing capability, and is not designed to work with a cellular
phone/handset. The PRYMEBLU Headset is designed to work only with ICOM BT-enabled 2-way radios.
PRYMEBLU BTH-700-IC
PRYMEBLU BTH-800-IC
PRYMEBLU BTH-900-IC
Made in Taiwan
PRYME® and PRYMEBLU® are trademarks owned by PRYME Radio Products, Brea CA.
All other product or service names are the property of their respective owners.
© 2021 PRYME Radio Products, Brea CA. All Rights Reserved

CHARGING THE HEADSET

The PRYMEBLU Muff Headset has an internal Lithium Ion rechargeable battery pack which must
be charged prior to operation. A fully charged battery will provide approximately 10 hours (or
more) of operation before needing to be recharged. However, operating time can vary
depending on usage and the condition of the battery pack. Recharge the battery regularly.
To charge the PRYMEBLU Headset:
BTH-900-IC
1. Ensure the PRYMEBLU Headset is turned off using the Power Button.
2. Plug the supplied wall charger into a standard 120 volt AC outlet.
3. Plug the charge cable into the AC wall charger and then into the charge jack on the Headset.
You will need to remove the protective rubber cover that is inserted into the charge jack. (To
prevent dust and moisture from damaging your Headset, always ensure this cover is in place
when you are not charging the Headset.)
4. Once the charging process has begun, the LED indicator on the Headset will show a
continuous red light. When the battery is done charging, the LED light will turn off.
5. Typical charge time is approximately 4 hours. Actual charge time will vary depending on
several factors including the battery's charge state, condition, and age.
6. Disconnect the charger from the lapel mic when charging is completed.
Charging Cautions:
- Use only the wall charger supplied by the
manufacturer. Do not use any other charger.
- Do not use a wall charger that appears
to be damaged. (Example: frayed wires,
melted plastic, etc.) Contact PRYME to
get a new manufacturer-approved
replacement charger.
- Do not tamper with or modify the
Headset or charger.
- Always turn the power switch to the off position
when charging the Headset.
P-CBL-USB-MICRO charger cable and P-CHA-BT-USB
wall charger included with the Headset.
BTH-700-IC/800-IC/900-IC
®
2
4
BTH-800-IC
SHOWN
