PRYME PRYMEBLU BT-PTT2-HY User Manual

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modi cations not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements, please
avoid direct contact to the transmitting antenna during transmitting.
RF Exposure Warning!
Please keep product 20cm away from your
body or bystander during the radio operation.
The typical handheld two-way radios were
certi ed under mobile usage condition
(i.e. keep 20cm away from the user body)
and use of such radio closer than 20cm may
exceed the US RF exposure limit
and shall be avoided.
version 1.0-HY August 2016

Controls and Connection

PTT Button
When paired with a PRYMEBLU
Adapter and wireless headset, this
button functions as a Push-to-Talk,
causing the two-way radio to transmit
when the switch is pressed.
LED Indicator
The LED ashes messages that let the
user know the current status of the
PRYMEBLU BT-PTT2-HY.
Dust Cover
Used to cover the USB
port when the BT-PTT2-HY
is not being recharged.
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: 714.257.0600
TOLL FREE: 800.666.2654
WWW.PRYME.COM
Power Button
Turns the PRYMEBLU
BT-PTT2-HY on and off.
USB Charge Port
This port is used to connect the
PRYMEBLU BT-PTT2-HY to any
powered USB connector for
recharging.
Clothing Clip
This 360° rotating clip can be
used to secure the BT-PTT2-HY
to the user's clothing or any
other convenient location.
3
PRYMEBLU BT-PTT2-HY PUSH-TO-TALK USER'S GUIDE
®
For use with Bluetooth enabled HYTERA two-way radios
The PRYMEBLU BT-PTT2-HY allows you to Push-to-Talk wirelessly over your HYTERA
Bluetooth enabled two-way radio when using a wireless Bluetooth headset.
This manual applies to the PRYMEBLU BT-PTT2-HY
Wireless Push-to-Talk transmitter.
The PRYMEBLU BT-PTT2-HY works with HYTERA
two-way radios with internal Bluetooth capability
PRYMEBLU BT-PTT2-HY
Model No.: BT-PTT2-HY
Made in Taiwan
FCC ID N2E-BT-PTT2
PRYME® and PRYME BLU® are trademarks owned by PRYME Radio Products,
Brea CA. All other product or service names are the property of their respective owners.
© 2016 PRYME Radio Products, Brea CA. All Rights Reserved

Quick Start

1. Charge the PRYMEBLU BT-PTT2-HY
2. Pair a wireless Bluetooth headset with the HYTERA two-way radio
3. Pair the PRYMEBLU BT-PTT2-HY with the HYTERA two-way radio
4. Test and Use.
OPTIONAL CHARGER
Universal Wall Charger with USB Port
P-CHA-BT-USB $12
STEP ONE: Charging the PRYMEBLU BT-PTT2-HY
The PRYMEBLU BT-PTT2-HY has an internal Lithium Ion rechargeable battery pack which must be
charged prior to operation, and must be recharged regularly. A fully charged battery should provide
more than 12 hours of operation before needing to be recharged.
To charge the PRYMEBLU BT-PTT2-HY:
* Ensure the PRYMEBLU BT-PTT2-HY is turned off, using the button located on the side of the
device.
* Plug the USB charge port on the bottom of the BT-PTT2-HY into any powered USB connector.
You will rst need to remove the protective rubber dust cover. (To prevent dust and moisture from
damaging your BT-PTT2-HY, always ensure this cover is in place when you are not charging the
device.)
* When charging, the LED on the BT-PTT2-HY will show a solid blue light. When the device is
done charging, the LED light will turn off.
* The PRYMEBLU BT-PTT2-HY takes approximately 4.5 hours to charge. Actual charge time
will vary depending on several factors including the battery's charge state, condition, and age.
Charging Cautions:
- Use only a POWERED USB port for charging. Non-powered ports (such as on a USB hub)
will NOT work.
- Do not use a wall charger that appears to be damaged. (Example: frayed wires,
melted plastic, etc.)
- Do not tamper with or modify the PRYMEBLU BT-PTT2-HY or charger.
- Always turn the power switch to the Off position when charging the PRYMEBLU BT-PTT2-HY.
4
