- Page 1 LVDS-to-Analog HD Converter Model 3101 Hardware Manual Ver. 1.0.0 | June 2020 SENSORAY | p. 503.684.8005 | email:info@SENSORAY.com | www.SENSORAY.com 7313 SW Tech Center Drive | Portland, OR 97203...
-
Page 2: Table Of Contents
Table of Contents Contents Limited warranty ....................... 3 Introduction ......................4 Block diagram ......................5 Connectors ....................... 6 J1, power ......................6 J2, HD-TVI output ....................6 J3, UART ....................... 6 Configuration switches ....................7 SW1, LED control ....................7 SW2, UART control .................... -
Page 3: Limited Warranty
Sensoray specifications for two years from the date of shipment to purchaser. Sensoray will, at its option, repair or replace equipment that proves to be defective during the warranty period. This warranty includes parts and labor. -
Page 4: Introduction
HD (HD-TVI). It is manufactured in the form of a printed circuit board that can be mounted directly on top of the camera. The 3101 incorporates power and RS-232 connectors and connects to the camera with a 30-wire microcoaxial cable (sold separately). -
Page 5: Block Diagram
Block diagram... -
Page 6: Connectors
Connectors J1, power Molex 5023520210. Mating part: Molex 5023510200. Crimping contacts: Molex 0561618081. Signal ground + 12V DC J2, HD-TVI output Molex 0734151631. Recommended adapter cable: Samtec MCX-to-BNC socket assembly RF179-72RP1-74BJ3-0100 (75 Ohm). J3, UART Molex 0530470310. Mating part: Molex 0510210300. Crimping contacts: Molex 0500798000. -
Page 7: Configuration Switches
Configuration switches A set of 4 DIP switches allows configuring some operating modes of the 3101. SW1, LED control ON (default) – on-board LEDs are on. OFF – on-board LEDs are off. SW2, UART control OFF (default) – camera’s UART connected to the on-board microcontroller for RS-232 channeling over coaxial cable. -
Page 8: Mechanical
Mechanical Mounting holes are provided for intallation directly on the following cameras: • Sony FCB-EV7520A, • KT&C ATC-HZ7810. -
Page 9: Accessories
Accessories A 30 conductor microcoaxial cable (KEL connectors) is available from Sensoray (http://www.sensoray.com/products/3101.htm). -
Page 10: Specifications
720p60/50, 1080p30/25 (LVDS) Video output HD-TVI Special features RS-232 channeling Requires a Sensoray device on the receiving end (models 2231, 4023, or other with model 3101 serial communications support) RS-232 configuration 9600-8-1-none-none Electrical, mechanical and environmental Dimensions approximately 50x35 mm... -
Page 11: Revision History
Revision history Version Notes 1.0.0, June 2020 Initial release.
