- Page 1 SENSORAY CO., INC. PC/104+ MPEG Video/Audio Grabber Model 314 Rev.A May 8, 2006 © Sensoray 2006 7313 SW Tech Center Dr. Tigard, OR 97223 Phone 503.684.8005 • Fax 503.684.8164 www.sensoray.com 1 1 1 1...
-
Page 2: Table Of Contents
PCI slot # select and interrupt routing DIP switch, SW2....... 10 Device Driver and SDK ..................11 Windows ....................11 Linux ......................11 Specifications ...................... 12 APPENDIX A: TESTED 314 FEATURES............... 13 APPENDIX B: PLAYER COMPATIBILITY AND INTEROPERABILITY ....... 14 2 2 2 2... -
Page 3: Limited Warranty
Sensoray will pay the shipping costs of returning to the owner parts that are covered by warranty. A restocking charge of 25% of the product purchase price will be charged for returning a product to stock. -
Page 4: Special Handling Instructions
Special handling instructions The circuit board contains CMOS circuitry that is sensitive to Electrostatic Discharge (ESD). Special care should be taken in handling, transporting, and installing circuit board to prevent ESD damage to the board. In particular: Do not remove the circuit board from its protective anti-static bag until you are ready to •... -
Page 5: Introduction
Introduction Model 314 is a PC/104+ MPEG video and/or audio grabber. It captures video and/or audio from a standard NTSC/PAL analog video source optional with stereo or monochrome audio source into one of following compressed MPEG streams: MPEG1, MPEG2, MPEG4, H.263, or MJPEG. It also supports capturing raw frames from NTSC/PAL video source. -
Page 6: Reference
Reference Connectors 6 6 6 6... -
Page 7: Pc/104+ Bus Connector, Con2
PC/104+ Bus Connector, CON2. Signal Signal Signal Signal Ground +5 V VIO* +5 V Ground C/BE0# Ground Ground Ground AD11 VIO* AD10 M66EN* AD14 AD13 Ground AD12 C/BE1# AD15 SERR# Ground SB0* Ground PERR# SDONE* STOP# LOCK* Ground TRDY# Ground DEVSEL# FRAME# Ground... -
Page 8: Pc/104 Bus Connector Ab, Con1
PC/104 Bus Connector AB, CON1. Signal Signal Ground * RSTDRV +5 V IRQ9 -5 V DRQ2 -12 V +12 V IOCHRDY SA19 SA18 IOW# SA17 IOR# SA16 DACK3# SA15 DRQ3 SA14 SA13 SA12 REFRESH# SA11 SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2# BALE... -
Page 9: Pc/104 Bus Connector Cd, Con3
PC/104 Bus Connector CD, CON3. Signal Signal Ground * Ground * SBHE# MEMCS16# LA23 IOCS16# LA22 IRQ10 LA21 IRQ11 LA20 IRQ12 LA19 IRQ15 LA18 IRQ14 LA17 MEMR# MEMW# DACK5# DRQ5 DACK6# SD10 DRQ6 SD11 DACK7# SD12 DRQ7 SD13 +5 V SD14 SD15 Ground *... -
Page 10: Led
PCI slot # select and interrupt routing DIP switch, SW2. The DIP switch, SW2, is used for selecting PCI slot number and interrupt routing for the Model 314. Refer to the following tables to choose a right/preferred setting for Model 314 in a (your) PC/104+ stack: SW2-2 (SelB) -
Page 11: Device Driver And Sdk
Device driver and SDK including demo application program are available for both Windows and Linux. Windows Sensoray Co. provides 314 WDM driver and DirectX filter for Windows platform. All are packaged in S314-Win-SDK (coming soon). Linux Linux SDK package, s314-lnx-sdk, provides device drive, A/V capturing & streaming service library, and A/V capturing &... -
Page 12: Specifications
Specifications Dimension 96mm x 105mm x 23mm Weight 78 g Power +5V, 500mA PC/104+ Video inputs 4 multiplexed input channels: 2 S-Video or 4 Composite, 75 Ohms Video formats NTSC and PAL Video Encoding formats MPEG1, MPEG2 (MP@ML), MPEG4 (SP@L3 + B-frame support), H.263, and MJPEG (Motion JPEG) Resolution Up to Full-D1:... -
Page 13: Appendix A: Tested 314 Features
Appendix A: Tested 314 Features... -
Page 14: Appendix B: Player Compatibility And Interoperability
Appendix B: Player Compatibility and Interoperability...
