CORONA RP6D1 Setup And Installation Manual

Thank you for purchasing the RP6D1 receiver – a small and light dual conversion 6 CH synthesized receiver! With high performance using
the latest receiver technology.
Why Why a a a Synthesized Synthesized R R R ece Synthesized
Why
Synthesized receivers get rid of the inconvenience of using a crystal. Receivers with a crystal still use the technology of the 1970's where
the user has to change the crystal to switch to a different frequency. Users are either stuck to one frequency or have to bring more
(expensive) crystals to the flying field. In addition, every time the crystal is changed there is a chance of damaging the receiver.
With a synthesized receiver, all you need to do is push the button to switch to any channel you are transmitting at.
With Corona's technology in developing and manufacturing of R/C products, the RP6D1 6CH Dual conversion receiver becomes the
smallest in the world. But do not only focus on its small size. Its high performance will also surprise you!
RP6D D D 1 1 1 ' ' ' s s s Features RP6 RP6 Features Features
1. You can switch the frequency freely with the RP6D1 6CH dual conversion synthesized receiver.
2. The 'one button' function makes it extremely easy to change frequency.
3. Despite the small size, the receiving range reaches as far as 1 mile!
4. The dual ceramic IF filters ensure ultra narrow selectivity, and can reject adjacent channel interference effectively.
5. The RP6D1 can identify the shift polarity of the transmitter (FUTABA, JR) automatically.
6. DSP technology filters noise intelligently and eliminates glitches effectively.
7. Failsafe function to put servos in a predetermined position in case of lost signal reception.
Specifica a a tions Specific tions
Specific tions
Size
Weight
Sensitivity
Selectivity
Nr. of channels
RF technology
Analog filtering
Digital filtering
Modulation
Shift polarity
Case
Operating Voltage
Operating Current
Setting up the receiver
Setting up Setting up the the receiver receiver
The setup procedure has 3 functions:
Mode I I I Mode
Mode - lock the receiver to the transmitter frequency
Mode II II II Mode Mode - disable failsafe
Mode Mode Mode III III III - enable failsafe
R R R e e e c c c e e e i i i v v v er er er RP6D1
ecei i i v v v er er er? ? ? ece
1.9"x0.8"x0.4" (48.5x20.8x12mm)
0.30oz (8.6g)(with shrink wrap)
better than 2.0μV
±8kHz at 65dB down
6
Dual tuned RF circuitry
Dual 4 pole ceramic filter
DSP filtering with mild algorithm
FM/PPM
Positive or Negative (auto detect)
Shrink wrap
4.8V~6.0VDC
26mA.
RP6D1
RP6D1
