REMOTE CONTROL FUNCTIONS
1. Power: Standby button.
2. MODE: Used to switch the BT, FM, AUX, USB, SD
3. MUTE: Mute button
4. REC: Recording, press once to start recording,
press again to play the current recording.
5. VOL + : Main volume increase
: Next song/Next channel
6.
: Previous song/Previous channel
7.
: Play/Stop Auto-search by press and hold
8.
the FM button, press and hold the BT button to
turn on TWS
9. VOL - : Main volume decrease
10. REPEAT: Single repeat/repeat all
11. EQ: Choose from EQ1, EQ2, EQ3, EQ4...
12. Choose song number directly/channel directly.
UNIT DESCRIPTION
1. Display screen
2. REPEAT: Single repeat/repeat all
3. MIC.PRI: Mic priority
4. MODE: Mode Switch for BT， FM， AUX， USB， SD
: Previous song/channel
5.
/PLAY/TWS: play/stop, Auto- search by press and hold the
6.
FM button, press and hold the BT button to turn on TWS
7. : Next song/next channel
8. CHARGE: Charge light
9. 13.5V IN: DC 13.5V charging port
10. M/GT.VOL: Mic volume knob
11. ECHO: Echo e ect for mic
12. TREBLE: Adjust the treble e ect knob
13. BASS: Adjust the bass e ect knob
14. VOLUME: Main volume knob
15. AUX: Aux input
16. Micro SD port
17. USB: USB port
18. MIC/GT. IN: Mic/guitar input
19. POWER ON/OFF
20. LED power On/O : LED power On/O
21. DC12V INPUT: DC 12V external power supply
4
www.PyleUSA.com
What's in the Box:
•
PA Speaker System
•
Remote Control
GETTING STARTED
1. Ensure the Portable PA Speaker is turned o . Ensure all volume controls are turned
all the way down. Next, connect one side of the included power cable to the
Portable PA Speaker's power inlet and the other to a grounded power outlet.
2. Ensure that the power supply complies with the power requirements listed on the
identi cation sticker located on the bottom of your product. Turn on the power to
the Portable PA Speaker using the power switch.
3. Slowly turn up the function keys until the desired level is reached.
WIRELESS BT CONNECTION
Switch the Portable PA Speaker to MODE, then switch to BT (BT MODE) pairing
mode and connect to a new BT device using BT Network Name: 'PYLE USA' .
Warning
1 To prevent the risk of re or electric shock, do not expose this appliance to rain or
moisture. To prevent electric shock do not remove the cover. No user serviceable
2 3 4 5 6 7
parts inside. Refer servicing to quali ed service personnel.
9
8
10
Safety
11
Prior to connecting mains, ensure that the supply voltage is correct and the mains
12
lead is in good condition. Avoid ingress of water or particles into the enclosure.
13
Placement
14
15
Keep the unit out of direct sunlight and away from heat sources.
16
17
Place the unit in an upright position during use and storage.
18
Keep the unit away from moisture or dusty environments.
19
20
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls.
21
To avoid damage, do not use solvents to clean this equipment.
•
Power Adapter
•
Wireless microphone
