Royal Vendors GIIv2 Installation

R
SUBJECT: Installation of Electronic Refrigeration Control
MODELS: GIIv2, GIII, Merlin III Conversions & Merlin IV Venders
KIT NUMBER
095160
012162

Reason for Fix:

This kit is to be used to convert venders (that currently use a thermostat) to the Electronic Refrigeration Control System.
This System may be necessary to enable the use of other optional kits.

Kit Contents:

Kit # 095160 (GII With a GIIv2 Board & GIII with Manual Cold Control)
Qty. Description
2 Sems Screw
1 Relay
1 Refrigeration Control Relay Harness (Door Side)
1 Refrigeration Control Relay Harness (Cabinet Side)
2 Self Drilling Screws
1 Temperature Sensor
1 Harness, Regulator Board
1 Relay Regulator Board
Kit # 012,162,014 (Merlin III & Merlin IV)
Qty. Description
2 Sems Screw
1 Relay
1 Refrigeration Control Relay Harness (Door Side)
1 Refrigeration Control Relay Harness (Cabinet Side)
2 Self Drilling Screws
1 Temperature Sensor

Instructions:

1. Unplug Vender.
2. Remove Can Chute from vender. Loosen screws securing the Wire Cover Plate that is located in the lower, left
side of the tank area. (This part covers the wiring and refrigeration tubing that goes between the tank area and
the bottom of the cabinet via the "Hat Section".) Remove the clips that hold the Evaporator Cover to the
Evaporator Fan Shroud Assembly and place the Evaporator Cover to the Side.
3. Optional: Remove the Thermostat from it's mounting position by disconnecting the two terminals, removing the
two screws and backing the capillary out of it's housing as you remove the thermostat. The thermostat will not be
needed and thus can be removed.
ANY QUESTIONS??? CONTACT ROYAL VENDORS' CUSTOMER SERVICE DEPARTMENT
F0019003.FRM
All manuals and user guides at all-guides.com
SERVICE BULLETIN #
201 INDUSTRIAL BOULEVARD • KEARNEYSVILLE, WV 25430
Phone: (304) 728-7056 • Fax: (304) 725-6579 • Toll Free: (800) 931-9214
KIT DESCRIPTION
Electronic Refrigeration Control Kit, GIIv2 / GIII
Electronic Refrigeration Control Kit, Merlin III Conversions & Merlin IV
CALL TOLL FREE (800) 931-9214
ISSUE DATE: 6/5/95
00143
The following areas of this vender contain voltage, which can cause serious
injury or even death. The main power cord, supplying 110 VAC to the evapo-
rator, EMI filter, and refrigeration system. The power line from the EMI filter to
the ballast and transformer. The ballast can produce upwards of 600 volts.
Remove power from vender before working in any of these areas.
REV. B REV. DATE: 2/27/98
PAGE: 1 of 4
DATE: 6-19-02
REVISION: 03
Part Number
901011
836065
141904
141905
902001
822030
210502
836081
Part Number
901011
836065
141904
141905
902001
822030
PAGE 1 OF 4
