- Page 1 INSTRUCTION MANUAL MODEL: HUR120I BUILT UNDER LARDER FRIDGE To request a service call our helpline on 01759 487830 Or visit www.appliancesupport.co.uk www.haden.com...
-
Page 2: Table Of Contents
Children shall not play with the appliance. www.haden.com... - Page 3 WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. www.haden.com...
- Page 4 Replacing the illuminating lamps WARNING—The illuminating lamps must not be replaced by the user! If the illuminating lamps is damaged, contact the customer helpline for assistance. This warning is only for refrigerators that contain illuminating lamps. www.haden.com...
- Page 5 - Thoroughly ventilate the room in which the appliance is situated. It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a short circuit, fire, and/or electric shock. www.haden.com...
- Page 6 Do not place hot items near the plastic components of this appliance. Do not place food products directly against the air outlet on the rear wall. Store pre-packed frozen food in accordance with the frozen food manufacture’s instructions. www.haden.com...
- Page 7 Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket. Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic solvents or abrasive cleansers. Do use a plastic scraper instead of a sharp objects to remove frost from the appliance. www.haden.com...
-
Page 8: Installation
This product must be serviced by an authorized Service Center, and only genuine spare parts must be used. 1) If the appliance is Frost Free. 2) If the appliance contains freezer compartment. Note: Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. www.haden.com... - Page 9 Appliance must not be exposed to rain. Sufficient air must be allowed to circulate in the lower rear section of appliance, as poor air circulation can affect performance. Built-in appliance should be positioned away from heat sources such as stoves, fires or heaters. www.haden.com...
- Page 10 INSTALLATION INSTRUCTIONS Before installing, carefuully read the instruction in order to avoid a certain number of problems. This is Dimensions of mounting slot. www.haden.com...
- Page 11 (as supplied) to the left side, if the installationon site requires. Warning! When reversing the door, the appliance must not be connected to the mains. Ensure that the plug is removed from the mains socket. Tools you will need (not provided): Phillips Head Screwdriver Slotted Screwdriver Wrench (8mm) www.haden.com...
- Page 12 Open the hinges away from the door. With the hinge open undo the screws holding it to the cabinet. Be careful with the hinge, use a long shafted screwdriver if you have one. www.haden.com...
- Page 13 4. Replace the upper hinge cover (left and right). Replace the lower screw hole cover for the cabinet. Replace the screw hole cover for the door. www.haden.com...
-
Page 14: Appliance Overview
APPLIANCE OVERVIEW 1. Controller part 2. Freezer room 3. Storage shelf 4. Crisper box cover 5. Crisper box 6. Upper door rack 7. Movable door rack 8. Lower door rack 9. Egg tray 10. Ice tray www.haden.com... - Page 15 Temperatures inside each compartment may vary from the temperatures displayed on the panel depending on how much food you store and where you place it. High or low room temperature may also affect the temperature inside the appliance. www.haden.com...
- Page 16 Super freeze automaticacally switches off after 52 hours. When super freeze functnction is on, you can switch off super freeze function by pressing the middle part of button and the freezer temperature setting will revert back to the previous setting. www.haden.com...
- Page 17 3 times per minute for 10 minutes. Closing the door cancels the door alarm and buzzer. Press “ALARM” button to stop alarm, the buzzing and icon will turn off. To save energy, please avoid keeping the door open for a long time when using refrigerator. www.haden.com...
-
Page 18: Using Your Appliance
Remove the door rack Install the door rack Crisper Box For storing fruit & vegetables. Caution: never close the door when the crisper box is pulled out, this may damage the box. www.haden.com... - Page 19 There are shelves in refrigerator chamber, and they can be taken out to be cleaned. Please push the shelf inside when replacing it. Freezer compartment For freezing fresh food and storing frozen and deep-frozen food for long periods of time. Ice-cube tray For making ice and storing ice-cubes. www.haden.com...
-
Page 20: Cleaning & Care
You should clean the appliance interior regularly. It will be easier to clean when food stocks are low. Wipe the inside of the fridge freezer with a weak solution of backing soda and water, and then rinse with warm water using a wrung-out sponge or cloth. www.haden.com... - Page 21 Replacing the LED light Warning: The LED light must be replaced by a competent person. If the LED light is damaged, follow the steps below: 1. Unplug your appliance. 2. Remove light cover by rising up and pulling out the LED light. www.haden.com...
- Page 22 Place food properly so that air can circulate freely around it. Hints for refrigeration For Meat: wrap in cling wrap and place on the glass shelf above the vegetable drawer. Always follow food storage times and use by dates suggested by manufacturers. www.haden.com...
- Page 23 Hints for the storage of frozen food Ensure that frozen food has been stored correctly by the food retailer Once defrosted, food will deteriorate rapidly and should not be re-frozen. Do not exceed the storage period indicated by the food manufacturer. www.haden.com...
-
Page 24: Troubleshooting
DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: - Take off the doors. - Leave the shelves in place so that children may not easily climb inside. www.haden.com... - Page 25 Air movement noise from the small fan motor in the freezer compartment or other compart- ments. Gurgling sound similar to water boiling. Popping noise during automatic defrosting. Clicking noise before the compres- sor starts. Clicking noise when you get the water. www.haden.com...
- Page 26 A layer of frost in the compartment Check that the air outlets are not blocked by food and ensure food is placed within the appliance to allow sufficient ventilation. Ensure that door is fully closed. To re- move the frost, please refer to the Cleaning and Care chapter. www.haden.com...
- Page 27 Close and reopen the door to reactivate the lights. Hear water bubbling in the This is normal. The bubbling refrigerator comes from the refrigerant cool- ant liquid circulating through the refrigerator. www.haden.com...
-
Page 28: Specifications
• to aviod increasing landfill WEEE product should be disposed of by handing it over at a desginated collection point. For more information about where to drop off your waste product for recycling please contact you loacal authority. www.haden.com... -
Page 29: Warranty
Customer misuse, modifications or adjustments. • Products with unreadable or removed serial numbers. Haden disclaims any liability for incidental or consequential loss or damages. In the event of a problem: • Please refer to the troubleshooting tips section within your user guide for help and guidance.
