SERVICE MANUAL
Digital Camera
1. SPECFICATION .................................... .................... 2
3. OUTLINE OF CIRCUIT DESCRIPTION .................... 5
4. DISASSEMBLY ........................................................ 13
5. ELECTRICAL ADJUSTMENT .................................. 15
REGISTRATION ...................................................... 20
7. TROUBLESHOOTING GUIDE ................................. 21
8. EXPLODED VIEW ................................................... 23
CABINET AND CHASSIS PARTS ........................... 27
ELECTRICAL PARTS .............................................. 28
ACCESSORIES PART ............................................ 29
CIRCUIT DIAGRAMS &
PRINTED WIRING BOARDS ................................... 30
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part
designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
-1 -

Advertisement

Table of Contents
loading

Summary of Contents for LG X-SHOT LDC-A310

  • Page 1: Table Of Contents

    SERVICE MANUAL Digital Camera 1. SPECFICATION ............2 2. LOCATION OF CUSTOMER CONTROLS ....4 3. OUTLINE OF CIRCUIT DESCRIPTION ....5 4. DISASSEMBLY ............13 5. ELECTRICAL ADJUSTMENT ........15 6. USB STORAGE INFORMATION REGISTRATION ............20 7. TROUBLESHOOTING GUIDE ......... 21 8.
  • Page 2: Specfication

    1. SPECFICATION -2 -...
  • Page 3 -3 -...
  • Page 4: Location Of Customer Controls

    2. LOCATION OF CUSTOMER CONTROLS • Front • Rear -4 -...
  • Page 5: Outline Of Circuit Description

    3. OUTLINE OF CIRCUIT DESCRIPTION 3-1. CP1 CIRCUIT DESCRIPTION 1. IC Configuration IC903 (ICX432JQ) CCD imager IC904 (CXD3440EN) V driver IC905 H driver, CDS, PGA and A/D converter (HD49335NP01) 2. IC903 (CCD imager) [Structure] Interline type CCD image sensor Image size Diagonal 6.67 mm (1/2.7 type) Pixels in total 2140 (H) x 1560 (V)
  • Page 6 3. IC904 (V Driver) 5. Lens drive block V driver is necessary in order to generate the clocks (vertical 5-1. Iris drive transfer clock, horizontal transfer clock and electronic shutter When the drive signals (IIN+ and IIN–) which are output from clock) which driver the CCD.
  • Page 7 . Circuit Description 7. Outline of Operation 6-1. Digital clamp When the shutter opens, the reset signals (ASIC and CPU) The optical black section of the CCD extracts averaged val- and the serial signals (“take a picture” commands) from the ues from the subsequent data to make the black level of the 8-bit microprocessor are input and operation starts.
  • Page 8 3-2. CP1 POWER CIRCUIT DESCRIPTION 1. Outline 3. Analog System Power Output This is the main power circuit, and is comprised of the follow- 15.0 V (A), -7.6 V (A) and 3.05 V (A) are output. Feedback for ing blocks. the 15.0 V (A) is provided to the switching controller (Pin (40) Switching power controller (IC501) of IC501) so that PWM control can be carried out.
  • Page 9 3-3. CP1 STROBE CIRCUIT DESCRIPTION 1. Charging Circuit 2. Light Emission Circuit When UNREG power is supplied to the charge circuit and the When RDY and TRIG signals are input from the ASIC expan- CHG signal from microprocessor becomes High (3.3 V), the sion port, the stroboscope emits light.
  • Page 10 3-4. SYA CIRCUIT DESCRIPTION 1. Configuration and Functions For the overall configuration of the SYA block, refer to the block diagram. The SYA block centers around a 8-bit microprocessor (IC301), and controls camera system condition (mode). The 8-bit microprocessor handles the following functions. 1.
  • Page 11 -11 -...
  • Page 12 -12 -...
  • Page 13: Disassembly

    4. DISASSEMBLY -13 -...
  • Page 14 -14 -...
  • Page 15: Electrical Adjustment

    5. ELECTRICAL ADJUSTMENT -15 -...
  • Page 16 -16 -...
  • Page 17 -17 -...
  • Page 18 -18 -...
  • Page 19 -19 -...
  • Page 20: Usb Storage Information Registration

    6. USB STORAGE INFORMATION REGISTRATION -20 -...
  • Page 21 POWER LOSS INOPERTIVE TAKING INOPERATIVE PUSH SHUTTER PUSH THE BUTTON POWER SW IC301-45 (SCAN IC301-28, 29 CHECK S6001, CHECK S6002, (SCAN IN 0, 1) CN601, CN301, IN 3) PULSE CN601, CN301 PULSE INPUT D3011 INPUT IC302-7 3.6 V CN301-5, 6 CHECK CHECK IC955, (LENS 3.6V)
  • Page 22 MEMO -22 -...
  • Page 23: Exploded View

    8. EXPLODED VIEW 317 316 257 258...
  • Page 24 MEMO MEMO...
  • Page 25: Cabinet And Chassis Parts

    ❏ PART LIST NOTE: Warning Parts that are shaded are critical With respect to risk of fire or electrical shock. Cabinet & Main CHASSIS PARTS NSP : Non SVC Parts RUN DATE : 20-FEB-2004 LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS ASSEMBLY SECTION 6871R-8484B PWB(PCB) ASSEMBLY,TOTAL...
  • Page 26: Electrical Parts

    PACKING PARTS RUN DATE : 20-FEB-2004 LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS 3835RC0022D INSTRUCTION ASSEMBLY CCD LCD-A310 DIGI-CAMERA_RUS 3890R-C068G BOX,MASTER LDC-A310 AA3RLL MOSCOW 1 ELECTRICAL PARTS LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS C541 6140RZB007O Capacitor 120UA 300V, COIL, OSCILLATOR LDC-A310 SANYO 404 094 2702 12 JK501 6140RZB007N Socket,DC, COIL, OSCILLATOR...
  • Page 27 ❏ ACCESSORIES SECTION ACCESSORY PARTS RUN DATE : 20-FEB-2004 LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS 6140RZB007P Cable,DSC,Video, COIL, OSCILLATOR LDC-A310 SANYO645 056 9401 DSC 6140RZB007Q Cable,DSC USB, COIL, OSCILLATOR LDC-A310 SANYO 645 059 6148 US 6140RZB007R Handstrap, COIL, OSCILLATOR LDC-A310 SANYO 636 069 5337 ST 6140RZB007T SD Card,16MB, COIL, OSCILLATOR LDC-A310 SANYO 645 061 3357 ME...
  • Page 28 CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS TABLE OF CONTENTS OVERALL WIRING & BLOCK DIAGRAMS Page OVERALL WIRING ............................33 OVERALL CIRCUIT ............................35 CAMERA CIRCUIT ............................36 LENS CIRCUIT ..............................37 ASIC CIRCUIT ..............................38 SYSTEM CONTROL CIRCUIT ......................... 39 FLASH CIRCUIT ...............................
  • Page 29 -31 -...
  • Page 30 MEMO -32 -...
  • Page 31: Overall Wiring & Block Diagrams

    ❏ OVERALL WIRING & BLOCK DIAGRAMS • OVERALL WIRING...
  • Page 32: Overall Circuit

    • OVERALL CIRCUIT • CAMERA CIRCUIT...
  • Page 33: Lens Circuit

    • LENS CIRCUIT • ASIC CIRCUIT...
  • Page 34: System Control Circuit

    • SYSTEM CONTROL CIRCUIT...
  • Page 37: Cp1 Board (Dma) Main, Lcd Driver & Lens

    CP1 BOARD (DMA) MAIN, LCD DRIVER & LENS [UPPER-LEFT] DMA(MAIN C1030 C1044 0.1;B 0.1;B C1032 D1-64400/SX714-U 0.1;B C1048 C1034 0.1;B 0.1;B VOLTAGE: VIEW MODE, LCD ON H=1.25 C1061 C1901 0.1;B 10;B VDD3 C1039 0.1;B C1065 0.1;B TO PWA 3.25 VDD3 VDD3 VDD1.8 VDD1.8...
  • Page 38 CP1 BOARD (DMA) MAIN, LCD DRIVER & LENS [UPPER-RIGHT] DMA(LCD) L1705 DMA(MAIN) 47;M VDD3 Q1701 12A01SS-TL 1AV4J11SR330G CN171 D1-64400/SX714-U R1714 100K;1/16J C1701 VOLTAGE: VIEW MODE, LCD ON LCDON2 Q1702 D1701 TO SYA DTC144EM MA2SD19 L1701 10;M 15.0 L15V +15V(L) 3.25 LCDCP LCDGRES VDD3...
  • Page 39 CP1 BOARD (DMA) MAIN, LCD DRIVER & LENS [LOWER-LEFT] CCD1 CCD0 R1033 VDD3 0;1/16Z USBD+ SA10 SA10 USBD- SA11 R1905 SA11 10K;1/16J SA12 SA12 VDD3 C1040 SA13 PLL_VDD SA13 0.1;B TO CAA PLL_GND VDD3 SUBGT PLLEN MRST SUBGT PLLEN SA14 ZCAS XSUB VDD1...
  • Page 40 CP1 BOARD (DMA) MAIN, LCD DRIVER & LENS [LOWER-RIGHT] LB8649FN-TBM R9507 MRST C9502 Z_SENS2_K SA14 MRST 10K;1/16D 0.033;B QLB8649FN---P ZCAS VDD3 ZCAS ZTEST ZOOM- ZOOM- ZTEST MGND ZRAS ZRAS PLLEN ZOOM+ ZOOM+ ZRCS PLLEN SGND ZRCE CKRE CLKSEL1 CKRE Z_SENS1_E CLKSEL1 CKRAM 3.25...
  • Page 41: Cp1 Board (Caa) Ccd Driver

    CP1 BOARD (CAA) CCD DRIVER L9001 LB2016T101K +15.0V(A) -7.6V(A) +3.05V(A) TO PWA IC904 CXD3440EN-1 QCXD3440EN-1P C9004 0.1;B 3.04 C9010 MODEL 3.25 -7.5 TO DMA XSUB XSUB 3.26 XSG1 XSG3 2.78 C9006 0.1;B 0.33 -7.53 3.26 XSG3A XSG1A 3.26 XSG3B XSG1B 0.33 C9005 0.1;B...
  • Page 42: Cp1 Board (Sya) System Control

    CP1 BOARD (SYA) SYSTEM CONTROL ALWAYS3.2V DPS1550L40N R3028 R3025 15.0 +15VB 0;1/16Z 120;1/16J TO PWA D3004 SML-512UW-T86 LENS3.6V LENS3.6V UNREG UNREG SCAN SCAN SCAN SCAN R3022 TO DMA & PWA R3026 22K;1/16J SCAN REC(VF) 820;1/16J OUT0 PLAY Q3005 R3027 2SD1819A SCAN WIDE OUT1...
  • Page 43: Cp1 Board (Pwa) Flash & Power

    CP1 BOARD (PWA) FLASH & POWER FLASH REFLECTOR 1AV4L17B0220G T5401 D5403 D5402 W1400 PINK CRG02 F1P8 290V T5402 1AV4L17B0160N P1-64400/SX714-U C5410 W1600 GRAY 0.047;350H R5414 1608 1K;1/16J C5411 C5403 R5406 0.068;B 150;1/16J 0.01;630H Q5407 3216 3LN01S R5408 D5405 CR05BS-8 180;1/16J W1500 BLACK Q5405...
  • Page 44 CP1 BOARD (PWA) FLASH & POWER [LEFT]...
  • Page 45 CP1 BOARD (PWA) FLASH & POWER [RIGHT]...
  • Page 46: Tb1 Board Switch

    PRINTED WIRING BOARDS (P.W.B.) TB1 BOARD SWITCH CP1 P.W.B. (SIDE A) CP1 P.W.B. (SIDE B) X3001 S6002 1AV4S10B5330G S6001 S6001 S6001 S6001 S6001 S6001 SKRNPBE010 SKRNPBE010 SKRNPBE010 SKRNPBE010 SKRNPBE010 SKRNPBE010 1AV4J11SJ060G CN601 30 32 17 20 SCANIN3B SCANOUT3 SCANIN1B R3015 SCANIN0B BACKUP TO CP1(SYA)
