SAVC75X2
Dual Screen Adapter for 49" - 75" Panels *
Dimensions
Supplied Parts and Hardware
A. Frame with attached back plates
B. TV mount arms
1pc
4pcs
C. M8x65mm hex bolt
D. M8 nut
E. M8 washer
F . M8x20mm bolt
G. M6x14mm bolt
4pcs
4pcs
8pcs
8pcs
8pcs
* For 75" dual screen the maximum vesa pattern is 600 x 400
