- Page 1 BRIGHT CANISTER & LIGHT SET...
-
Page 2: Table Of Contents
6. ASSEMBLY ..............................13 7. CONTROLLING ............................14 8. MOUNTING ..............................15 9. CONNECTING ............................. 15 10. CARE AND MAINTENANCE ........................16 11. CERTIFICATION AND DISPOSAL ........................ 16 ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 2 of 17... -
Page 3: Introduction
All SCUBA FORCE battery tanks and lamp sets are made from highest quality materials using only the latest computer-aided design and manufacturing techniques to ensure their highest performance and reliability. -
Page 4: Warning, Caution And Remarks
In case of any uncertainties concerning this manual, or in case you do not get sufficient answers from your diving center or diving instructor, please do not hesitate to contact us. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 4 of 17... -
Page 5: Scope Of Delivery
3. Lamp head with goodman handle and E/O cord 4. Spare O-rings (1 set) 5. Battery tank incl. battery (we also refer to the body made from Delrin as canister) 6. Protection case ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 5 of 17... -
Page 6: Scope Of Delivery - Canister Set
2. Charging cable with US adapter 3. Spare O-rings (1 set) 4. Battery tank incl. battery (we also refer to the body made from Delrin as canister) 5. Protection case ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 6 of 17... -
Page 7: Technical Specification
75 % ca. 279 Minutes 50 % ca. 419 Minutes Battery Lithium Ions 3S7P Dimming 100 / 75 / 50 % Controlling Piezzo Switch Voltage 10,8 V ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 7 of 17... -
Page 8: Lamp Head
830 Minutes CREE XHP70 Lumen 4000 Beam angle 8 ° Measurments 35 x 25 x 8 cm 4.3 Protection Case Measurments 35 x 25 x 8 cm ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 8 of 17... -
Page 9: Charging Of The Battery
Please, only use the provided charger to charge the battery. The use of unsuitable chargers can irreparably damage the battery. Damage caused by incorrect charging is not covered by the warranty. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 9 of 17... - Page 10 Red belongs to red. The charging plug and charging cable at the charger are red and belong on the side of the battery, also highlighted in red. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 10 of 17...
-
Page 11: General Notes On The Handling Of Lithium-Ion Batteries
IMPORTANT: Lithium-ion batteries, like other rechargeable batteries, must not be short- circuited. Short-circuiting (even with metal jewelry or tools) can cause fire or burning due to the high equalizing currents. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 11 of 17... -
Page 12: Safety Instructions For Lithium-Ion Batteries
(toxic gases, etc.) must also be observed here as well as the methods used to extinguish such fires. Combustion products include hydrogen fluoride, carbon monoxide and carbon dioxide. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 12 of 17... -
Page 13: Assembly
It is essential to prevent dirt and other contaminants from getting onto the O-rings. Regular greasing with silicone grease is also important. If you are unsure, ask your retailer to show you how to do this properly. ©2019 SCUBA FORCE | Doc. No. 01-2021 Rev. 1 26.07.2021 Page 13 of 17... -
Page 14: Controlling
BRIGHT CANISTER AND LIGHT SET INSTRUCTION MANUAL 7. Controlling The BRIGHT battery tank is controlled by a piezzo switch, which reacts to the softest contact. The use is very simple. 1. One short press - lamp / battery tank turn on at 100%. -
Page 15: Mounting
The battery tank can be secured against slipping with a regular belt buckle. 9. Connecting The battery tank can be connected to the X-Heat system or the BRIGHT lamp head through the E/O cords. E/O Cords are electrical cables that can be plugged in under water. The battery tank must be switched off during the plugging process. -
Page 16: Care And Maintenance
After the dive you should thoroughly rinse and clean the battery tank and, if necessary, the lamp head with fresh water. The BRIGHT is designed for low maintenance. Only the two O- rings in the battery tank require regular attention and a certain amount of care (clean / grease). - Page 17 Please be environmentally conscious when disposing of your battery. By law, you are obliged to return batteries and accumulators. You can return the battery to your SCUBA FORCE dealer or to us. The battery can also be returned free of charge to municipal collection points.
