Summary of Contents for Mobileye EyeNET
- Page 1 Mobileye 8 Connect EyeNET User Manual v0.3...
- Page 2 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM Table of Contents TABLE OF CONTENTS 1. INTRODUCTION 2. EYENET COMPONENTS OVERVIEW 2.1 E NET C OMPONENTS VERVIEW 3. MOBILEYE 8 CONNECTION DESCRIPTION 3.1 E...
- Page 3 Mobileye 8 Connect service port uses a RGMII interface (Reduced Gigabit Media- Independent Interface) for faster & reliable data transfer rate. The Ethernet port of the EyeNET provides a universal and very common connection method for the end-user. The EyeNET Support up to 1Gbit/s transfer rate 2.
- Page 4 RGMI port communication Ethernet port communication Reset switch Octopus The Mobileye 8 service port Male connector (P2) is used for connection with the Mobileye EyeNet cable female connector labeled “xxx” (J5). Wire Name Wire Color Connector Connect to EyeNet cable...
-
Page 5: Connection Scheme
Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 4. Connection Scheme Page 5 of 12 EyeNET User Manual v0.3... -
Page 6: Technical Specification
Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 5. Technical Specification Property Description EyeNET short cable length 12cm Ethernet cable length 1 Meter Ethernet cable type CAT5 / CAT6 Bit rate 1Gbps Dimensions (W*L*H) 60.5mm X 91mm X 27mm... - Page 7 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 6. Technical Specification Please follow the below steps to configure the Ethernet adapter (either the build-in LAN port or USB to LAN adapter) 1. Click Start, and in the search field, type View network connections 2.
- Page 8 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 3. In the window "Local Area Connections Properties" uncheck all the [Check Box] except: Client for Microsoft Network and Internet Protocol Version 4 4. When completing step 4 above, press on the Configure button 5.
- Page 9 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 6. in the Advanced Tab Search for the following parameters and change them accordingly to the following settings: 6.1 Speed Duplex – and change the Value to 1.0 Gbps Full Duplex 6.2 search Wake on Magic Packet - and change the Value to Disabled...
- Page 10 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 6.3 search Receive Buffers - and change the Value to 2048 6.4 search Transmit Buffers - and change the Value to 2048 Page 10 of 12...
- Page 11 Mobileye 8 Connect | February 2021 MOBILEYE, AN INTEL COMPANY EyeNET User Manual 0.3 WWW.MOBILEYE.COM 6.5 search Wake on pattern match - and change the Value to Disabled 7. go to Power Management Tab and Uncheck the Allow the computer to turn off this device to save power 8.
-
Page 12: Troubleshooting
In some cases when using of a USB to CAN adapter result a video delay in the calibration step, please connect Mobileye EyeNET directly to the build-in LAN port (if exist). If not, try to change USB port. If the problem consists, try to replace the adapter.
