Erc Component (Output) Connector Layout; Erc Sensor (Input) Connector Layout - Manitowoc Multiplex Beermaster 75A04 Technician's Handbook

ERC Component (Output) Connector Layout

L
L/N
EARTH

ERC Sensor (Input) Connector Layout

12
HPCO
HPCO SWITCH
COM
+5V DC
OUTPUT
146
AGITATIOR
C R
PLUG THIS PIN
11 10
CO2 TS
WATER
COM
+5V DC
OUTPUT
SUCTION TEMP
DISCHARGE TEMP
WATER BATH TEMP
CARB A CARB B CIRC A
9 8 7 6 5
TD TW TB TA
CIRC B TEMP
Part Number STH13 9/10
CIRC
B
4 3 2 1
WL ICE CA A CA B
HIGH PROBE
LOW PROBE
GND
HIGH PROBE
LOW PROBE
GND
LEVEL PROBE
CIRC A TEMP
HIGH PROBE
LOW PROBE
GND
