Lucent Technologies VR Series Product Manual

Lucent Technologies VR Series Product Manual

Enhanced batteries
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enhanced VR Series Batteries
KS-23619
Product Manual
Select Code 157-622-011
Comcode 107817074
Issue 5
December 1998
© 1998 Lucent Technologies

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Lucent Technologies VR Series

Summary of Contents for Lucent Technologies VR Series

  • Page 1 Enhanced VR Series Batteries KS-23619 Product Manual Select Code 157-622-011 Comcode 107817074 Issue 5 December 1998 © 1998 Lucent Technologies...
  • Page 3 Comcode 107817074 Issue 5 December 1998 Lucent Technologies Enhanced VR Series Batteries Notice: Every effort was made to ensure that the information in this document was complete and accurate at the time of printing. However, information is subject to change.

  • Page 5: Table Of Contents

    Lucent Technologies Enhanced VR Series Batteries Table of Contents 1 Introduction Enhanced VR Batteries 1 - 1 Customer Training 1 - 3 Customer Service 1 - 3 Technical Support 1 - 3 Product Repair and Return 1 - 3 Warranty Service...
  • Page 6 Lucent Technologies Enhanced VR Series Batteries Storage Time 5 - 1 6 Installation Introduction 6 - 1 Installation Tools, Materials, and Test Equipment 6 - 1 Product Manual 6 - 1 Unpacking and Handling 6 - 2 Safe Handling 6 - 2...
  • Page 7 Lucent Technologies Enhanced VR Series Batteries 9 Discharge and Power Data Constant Current Discharge Data 9 - 1 Constant Power Discharge Data 9 - 7 High Discharge Rate Performance 9 - 13 10 Installation and Maintenance Record 11 Material Safety Data Sheet...
  • Page 9 Lucent Technologies Enhanced VR Series Batteries List of Figures Figure 1-1: Enhanced VR Batteries (Shown with Metal Sleeve) 1 - 2 Figure 6-1: Enhanced VR Battery Handle 6 - 2 Figure 7-1: Temperature Correction Chart 7 - 6 Figure 8-1: Replacing a Battery Module...
  • Page 10 Lucent Technologies Enhanced VR Series Batteries Figure 9-12: Constant Power Discharge Data to 1.84 Volts 9 - 10 Figure 9-13: Constant Power Discharge Data to 1.86 Volts 9 - 11 Figure 9-14: Constant Power Discharge Data to 1.88 Volts 9 - 11 Figure 9-15: Constant Power Discharge Data to 1.90 Volts...
  • Page 11 Lucent Technologies Enhanced VR Series Batteries List of Tables Table 2-A: Enhanced VR Battery Specifications 2 - 3 Table 3-A: Enhanced VR Battery Modules 3 - 2 Table 6-A: Initial Charging 6 - 7 Table 7-A: Recommended String Float Voltages...

  • Page 13: Introduction

    Lucent Technologies’ Enhanced VR Series Batteries batteries, which are available in both 2- and 4-volt models. The Enhanced VR Series battery is a stationary, valve-regulated, rechargeable, lead-acid battery designed by Bell Laboratories, an acknowledged leader in technology, research, and design of power systems.

  • Page 14: Figure 1-1: Enhanced Vr Batteries (Shown With Metal Sleeve)

    Lucent Technologies Enhanced VR Series Batteries L u c e n t 2 Volt, 375 Ah Battery (Model 2VR375E) L u c e n t 2 Volt, 250 Ah Battery (Model 2VR250E) 4 Volt, 125 Ah Battery (Model 4VR125EL) L u c...

  • Page 15: Customer Training

    For other customers worldwide, contact your local field support center or your sales representative to discuss your specific needs. Product Repair Repair and return service is provided for Lucent Technologies customers around the world. For customers in the United States, and Return...
  • Page 16 Lucent Technologies Enhanced VR Series Batteries conformance issues prior to customer ownership, contact your local customer service. 1 - 4 Introduction Issue 5 December 1998...

  • Page 17: Product Description

    Overview A 2-volt 125Ah cell is the building block used to construct the Enhanced VR Series family of batteries. These modules may be mounted in a variety of ways to meet individual customer needs. The valve-regulated design and construction of the Enhanced VR Series batteries prevents electrolyte leakage and minimizes water loss and maintenance throughout the design life.

  • Page 18: Features

    Lucent Technologies Enhanced VR Series Batteries for Emergency Lighting and Power Equipment, and UL1989, Standard for Standby Batteries. Features • Bell Laboratories’ patented lead/tin alloy post, leakproof post seal, and valve-regulated design require minimal maintenance. • An Enhanced VR battery consists of compact, modular cells that permit up to 750Ah of 48V battery reserve (at a 10-hour rate) to be installed in a single VR battery stand.

  • Page 19: Table 2-A: Enhanced Vr Battery Specifications

    Lucent Technologies Enhanced VR Series Batteries Table 2-A: Enhanced VR Battery Specifications Width Height Depth Weight Float Model** in. (mm) in. (mm) in. (mm) lb. (kg) Rating Voltage* 3.54 9.36 16.78 53-55 2VR250E 2.25 - 2.27 (89.9) (237.7) (426.2) (24-25) 3.54...

  • Page 21: Ordering Information

    J85504C-1 VR battery stand to create 24- and 48-volt stand-alone strings. • Installed in a four-shelf battery stand, these batteries are used as an integral part of the Lucent Technologies Evolutionary Control System (ECS) J85500D-2 and J85500D-3 battery plants. •...

  • Page 22: Battery Modules

    The comcode is a 9-digit number used in ordering the Modules product. The “KS” numbers and their associated list numbers refer to the Lucent Technologies documents that specify the design and manufacture of each model. Table 3-A: Enhanced VR Battery Modules...

  • Page 23: Safety And Environmental

    Lucent Technologies Enhanced VR Series Batteries Safety and Environmental Safety Symbols DANGER HIGH VOLTAGE... FLUSH EYES SHIELD SHIELD IMMEDIATELY RISK OF SHOCK. EYES. EYES. WITH SULFURIC DO NOT TOUCH WATER. ACID UNINSULATED EXPLOSIVE SPARKS CAN CAUSE TERMINALS OR GASES GASES...
  • Page 24 (spill clean-up and disposal), and special precautions. The following items can be ordered from Lucent Technologies. These items should be available to anyone working around batteries. The local, state, or federal codes for certain installations may require some of these items to be installed and/or kept at the installation site.

  • Page 25: Electrical Hazard

    Lucent Technologies Enhanced VR Series Batteries Electrical Hazard WARNING ELECTRICAL HAZARD In addition to proper job training and safety procedures, the following are some basic precautions that should always be followed when working with or around batteries (including equipment connected to batteries): •...

  • Page 26: Battery Gases

    Lucent Technologies Enhanced VR Series Batteries A single battery is typically at low voltage; however, batteries connected together in a system can pose a shock hazard in addition to an energy hazard. When interconnection of the batteries creates a hazardous voltage supply, post appropriate warnings in the end systems or installations.
  • Page 27 Lucent Technologies Enhanced VR Series Batteries • Before performing any work operation, follow proper ESD protection procedures to discharge the static electricity from your body. • Never tamper with or block the vent caps of batteries. Damaged or clogged vent caps may result in an explosion due to excessive internal pressure.

  • Page 28: First Aid

    Lucent Technologies Enhanced VR Series Batteries To direct attention to the possible source of danger from battery gases, post one or more warning signs, lettered in large characters, in a conspicuous location near the batteries. First Aid Refer to the MSDS in Section 11 for first aid procedures.

  • Page 29: Battery Storage

    Lucent Technologies Enhanced VR Series Batteries Battery Storage State of New The Enhanced VR battery is shipped in the charged state. The open circuit voltage for a fully charged battery is approximately Battery 2.15V/cell. Storage • Store batteries in an upright position in a dry and cool environment without exposure to direct sunlight.

  • Page 31: Installation

    Lucent Technologies Enhanced VR Series Batteries Installation Introduction This section describes the procedures for installing the Enhanced VR Series batteries. Please review the safety precautions in Section 4 before handling the batteries. Installation The following tools, materials, and test equipment are...

  • Page 32: Unpacking And Handling

    Lucent Technologies Enhanced VR Series Batteries at 1-800-THE-1PWR (1-800-843-1797). Specify Select Code 157-622-011. Unpacking and Use appropriate material handling equipment to ensure personnel safety and equipment protection while installing the Handling batteries. Move crated batteries to a convenient predetermined area where the appropriate unpacking and handling equipment and tools are available.
  • Page 33 Lucent Technologies Enhanced VR Series Batteries 1. Examine the shipping container and record any signs of external damage. 2. Search for any indications of acid spillage during shipment. Record any indications of acid spillage on the bill of lading before signing.

  • Page 34: Battery String Location

    Lucent Technologies Enhanced VR Series Batteries will not require cleaning and recoating. Clean the contact surface areas of exposed copper post terminals with a dry non-abrasive cloth and recoat only if they appear dirty. 7. If the case is dirty when removed from the shipping container, clean the case with a cloth dampened with water before installing it in the battery stand.

  • Page 35: Mixing Batteries In A String

    Note String To insure maximum battery performance, do not mix Enhanced VR Series batteries and non-VR batteries in a string. As batteries age, their characteristics change. As a general practice it is not recommended to mix new batteries with older batteries in a string.

  • Page 36: Initial Charging

    Lucent Technologies Enhanced VR Series Batteries Initial Charging To ensure full charge and adequate initial performance, store and maintain batteries according to instructions in Section 5, Battery Storage, and use the guidelines in this section to charge the batteries at the time of installation.

  • Page 37: Table 6-A: Initial Charging

    Lucent Technologies Enhanced VR Series Batteries Table 6-A: Initial Charging Battery Condition Action All batteries have similar date codes and storage histories and none are Make voltage and polarity checks as described more than 6* months old or they later in this section and connect string(s) to plant.

  • Page 38: Placing A Battery String Into Service

    Lucent Technologies Enhanced VR Series Batteries Placing a Batteries should be in service within 48 hours of initial charge. If a battery is left on open circuit for more than 48 hours after the Battery String initial charge, treat it as if it had never received an initial charge.
  • Page 39 Lucent Technologies Enhanced VR Series Batteries volts because the chargers are turned off. If a larger differential exists, the string should be charged at the plant voltage (or the plant voltage lowered) until the voltage differential is less than 0.05 volts. This should prevent arcing during the final connection.

  • Page 41: Operation

    Lucent Technologies Enhanced VR Series Batteries Operation Lead-acid This section provides general information and guidelines for estimating the hydrogen gassing rates of lead-acid batteries on Battery charge. It is beyond the scope of this document to provide the Gassing Rate detailed methods or the engineering design required to maintain safe levels of hydrogen in battery enclosures.

  • Page 42: Service Life

    Lucent Technologies Enhanced VR Series Batteries produced by flooded lead-acid batteries under similar charging currents, and are designed to achieve greater than 95% recombination efficiency at normal float charge and temperature. However, charging at voltages greater than the nominal float voltage, charging at elevated temperatures,...

  • Page 43: Battery String Float Voltage

    Lucent Technologies Enhanced VR Series Batteries with either a step or a slope compensation device. For systems without such a device, it is recommended that the float voltage be reduced by 3mV/°C/module for the 2VR250E or 2VR375E and 6mV/°C/module for 4VR125E or 4VR125EL for temperatures above 25°C (77°F).

  • Page 44: Charging Voltage Ripple

    Both the amplitude and frequency of the ripple affect the degree of battery degradation. As a guideline, the charging voltage ripple for the Enhanced VR Series battery should not exceed 10mV peak to peak per cell or last longer in duration than 8mSec.

  • Page 45: Capacity

    Lucent Technologies Enhanced VR Series Batteries The Warranty Period outlined in Section 12 is based on the battery temperature, not the ambient temperature. Maintain a low battery temperature by adjusting the ambient environment temperature and/or air ventilation. (See Section 6, “Environmental Requirements.”)

  • Page 46: Temperature Correction For Capacity

    Lucent Technologies Enhanced VR Series Batteries 67°F (19.4° C). Therefore, the temperature-corrected capacity is 97.5% + 2.5% = 100% (full capacity). Note When the ambient temperature is above 25°C (77°F), subtract the correction factor and vice versa. Corrected capacity = Measured Capacity * [1 - 0.0025 (Temp°F - 77°F)]...

  • Page 47: Discharge Capacity Test

    Lucent Technologies Enhanced VR Series Batteries Discharge Since the Enhanced VR batteries are long-life batteries, this test Capacity Test is not required as a routine maintenance procedure. However, a discharge test is the best way to determine if sufficient reserve power is available.

  • Page 48: Recharge After Discharge

    The recharge should begin as soon as possible after the discharge. Boost Charge Boost charging the Enhanced VR Series batteries is not recommended without the concurrence of Lucent Technologies. Call 1-800-225-7822 for technical assistance. During a boost charge, water loss due to electrolysis is greatly increased.

  • Page 49: Maintenance

    Enhanced VR batteries. “Paragraph Reference” refers to the procedures for performing the routines that follow the table. (The procedures and intervals are the same for all models of the Enhanced VR Series battery.) Table 8-A: Maintenance Routines Required...

  • Page 50: Maintenance Routines

    Lucent Technologies Enhanced VR Series Batteries Maintenance When performing any maintenance activities, it is essential to follow all safety procedures outlined in Section 4. Routines Warning An explosion could occur when sparks are created near the battery string. Use insulated tools and discharge all static electricity from your body before performing any work.

  • Page 51: Measuring Battery Temperatures

    Lucent Technologies Enhanced VR Series Batteries batteries have been on continuous, uninterrupted float operation for at least one month. Measuring Make temperature measurements using calibrated equipment, Battery such as an infrared-based or thermocouple-based measuring Temperatures device. Make all measurements on the negative terminal of the selected batteries.

  • Page 52: Flame Arrestor Vent Feature

    Replacement Note To insure maximum battery performance, do not mix Lucent Technologies Enhanced VR Series batteries with other types of batteries. As batteries age, their characteristics change. As a general practice it is not recommended to mix new batteries with older batteries in a string.

  • Page 53: Figure 8-1: Replacing A Battery Module

    Lucent Technologies Enhanced VR Series Batteries 1 2 V A U T Figure 8-1: Replacing a Battery Module Issue 5 December 1998 Maintenance 8 - 5...
  • Page 55 Lucent Technologies Enhanced VR Series Batteries Discharge and Power Data Constant Tables 9-A to 9-C and Figures 9-1 to 9-8 display constant current discharge data at 25°C (77°F) for Lucent Technologies Current Enhanced VR batteries. The numbers in the tables represent the Discharge Data discharge current for a particular reserve time to the corresponding end cell voltage.

  • Page 56: Table 9-A: 2Vr375E Constant Current Discharge Data

    Lucent Technologies Enhanced VR Series Batteries Table 9-A: 2VR375E Constant Current Discharge Data Hours End Volts per Battery Reserve @ 1.75 1.80 1.82 1.84 1.86 1.88 1.90 1.92 77° F 161.8 150.6 144.7 137.9 131.4 129.1 119.6 109.0 84.1 82.8 81.7...

  • Page 57: Figure 9-1: Constant Current Discharge Data To 1.75 Volts

    12.1 11.7 11.3 Constant Current Discharge Data to 1.75 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-1: Constant Current Discharge Data to 1.75 Volts Issue 5 December 1998 Discharge and Power Data 9 - 3...

  • Page 58: Figure 9-2: Constant Current Discharge Data To 1.80 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Current Discharge Data to 1.80 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-2: Constant Current Discharge Data to 1.80 Volts Constant Current Discharge Data to 1.82 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-3: Constant Current Discharge Data to 1.82 Volts...

  • Page 59: Figure 9-4: Constant Current Discharge Data To 1.84 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Current Discharge Data to 1.84 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-4: Constant Current Discharge Data to 1.84 Volts Constant Current Discharge Data to 1.86 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-5: Constant Current Discharge Data to 1.86 Volts...

  • Page 60: Figure 9-6: Constant Current Discharge Data To 1.88 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Current Discharge Data to 1.88 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-6: Constant Current Discharge Data to 1.88 Volts Constant Current Discharge Data to 1.90 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-7: Constant Current Discharge Data to 1.90 Volts...

  • Page 61: Figure 9-8: Constant Current Discharge Data To 1.92 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Current Discharge Data to 1.92 Volt per Battery End-Point for Lucent Technologies Enhanced VR Series Battery Figure 9-8: Constant Current Discharge Data to 1.92 Volts Constant Tables 9-D through 9-F and Figures 9-9 through 9-16 show the...

  • Page 62: Table 9-E: 4Vr125El Constant Power Discharge Data

    Lucent Technologies Enhanced VR Series Batteries Table 9-E: 4VR125EL Constant Power Discharge Data Hours End Volts per Battery Reserve @ 1.75 1.80 1.82 1.84 1.86 1.88 1.90 1.92 77° F 122.8 120.8 113.8 107.8 66.5 65.5 64.3 63.1 61.5 58.8 43.7...

  • Page 63: Figure 9-9: Constant Power Discharge Data To 1.75 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Power Discharge Data to 1.75 Volt End-Point for Lucent Technologies Enhanced VR Series Batteries 1000 2VR375E 2VR250E 4VR125E/4VR125EL Hours Reserve Figure 9-9: Constant Power Discharge Data to 1.75 Volts Constant Power Discharge Data to 1.80 Volt End-Point for...

  • Page 64: Figure 9-11: Constant Power Discharge Data To 1.82 Volts

    Lucent Technologies Enhanced VR Series Batteries Constant Power Discharge Data to 1.82 Volt End-Point for Lucent Technologies Enhanced VR Series Batteries 1000 2VR375E 2VR250E 4VR125E/4VR125EL Hours Reserve Figure 9-11: Constant Power Discharge Data to 1.82 Volts Constant Power Discharge Data to 1.84 Volt End-Point for...
  • Page 65 Lucent Technologies Enhanced VR Series Batteries Constant Power Discharge Data to 1.86 Volt End-Point for Lucent Technologies Enhanced VR Series Batteries 1000 2VR375E 2VR250E 4VR125E/4VR125EL Hours Reserve Figure 9-13: Constant Power Discharge Data to 1.86 Volts Constant Power Discharge Data to 1.88 Volt End-Point for...
  • Page 66 Lucent Technologies Enhanced VR Series Batteries Constant Power Discharge Data to 1.90 Volt End-Point for Lucent Technologies Enhanced VR Series Batteries 1000 2VR375E 2VR250E 4VR125E/4VR125EL Hours Reserve Figure 9-15: Constant Power Discharge Data to 1.90 Volts Constant Power Discharge Data to 1.92 Volt End-Point for...

  • Page 67: Table 9-G: High Discharge Rate Performance

    Lucent Technologies Enhanced VR Series Batteries High The Enhanced VR battery is also appropriate for applications requiring high discharge rate performance. Table Discharge Rate 9-G lists 1-minute and 5-minute rates to 1.75 volts per battery at Performance 77° F. These data have been adjusted for intercell and/or interior connector losses, but not for connections between the battery and the load.
  • Page 69 Lucent Technologies Enhanced VR Series Batteries Installation and Maintenance Record The form in this section should be reproduced and used as the Installation and Maintenance Record for batteries. Note Failure to adhere to the maintenance schedules and routines described in the Maintenance section of this product manual will void the product warranty and may result in reduced performance of your batteries.
  • Page 70 Installation and Maintenance Record (Page 1) Company Name: Site Address: Battery Type: String Voltage: Voltage across charge and discharge buses: Voltage Difference: If the voltage difference between the string and the charge/discharge buses is less than 0.05V, the system is ready. Make individual battery voltage measurements and record in the table below.
  • Page 71 Installation and Maintenance Record (Page 2) Company Name: Site Address: Battery Type: Temperature Measurements on Selected Batteries Measurement Date Battery Initials Number String Float Current Measurements Measurement Date Battery Initials Number Battery Capacity Measurements Battery Start Voltage End Voltage Test Current Percent Test Date Test Start Time...
  • Page 72 Lucent Technologies Enhanced VR Series Batteries 10 - 4 Installation and Maintenance Record Issue 5 December 1998...
  • Page 73 Lucent Technologies Enhanced VR Series Batteries Material Safety Data Sheet This section contains the Material Safety Data Sheet for the Enhanced VR batteries. Issue 5 December 1998 Material Safety Data Sheet 11 - 1...
  • Page 74 Lucent Technologies Enhanced VR Series Batteries 11 - 2 Material Safety Data Sheet Issue 5 December 1998...
  • Page 75 Lucent Technologies Enhanced VR Series Batteries Issue 5 December 1998 Material Safety Data Sheet 11 - 3...
  • Page 76 Lucent Technologies Enhanced VR Series Batteries 11 - 4 Material Safety Data Sheet Issue 5 December 1998...
  • Page 77 Lucent Technologies Enhanced VR Series Batteries Issue 5 December 1998 Material Safety Data Sheet 11 - 5...

  • Page 79: Table 12-A: New Battery Warranty Periods And

    Lucent Technologies Enhanced VR Series Batteries Product Warranty Enhanced VR Batteries Product Warranty: A. Seller warrants to customer that: 1. As of the date title to product sold (Product) passes, Seller will have the right to sell, transfer, and assign such product, and the title conveyed by Seller shall be good;...
  • Page 80 Lucent Technologies Enhanced VR Series Batteries Temperature and maintenance records shall be maintained by Customer in accordance with Seller's published instructions in the Maintenance section of this manual. Failure to do so may void the warranty. • End of life is defined as 80% of rated capacity (see Operation section for Discharge Capacity Test).
  • Page 81 Lucent Technologies Enhanced VR Series Batteries Customer. Products returned for replacement will be accepted by Seller only in accordance with its instructions for such returns. The transportation expense and risk of loss associated with returning such Product to Seller shall be borne by Customer.
