Summary of Contents for Imaging Source DMK
- Page 1 Technical Details Assembly Instruction: DMK/DFK/DBK Cameras, TLH CS-f and TBL Lenses...
- Page 2 The spacer ring and lens cap (middle and right) are no longer needed. We do recommend keeping these items, however, in case the camera needs to be stored at a later date. Assembly Instructions for DMK/DFK/DBK Cameras, TLH CS-f and TBL Lenses...
- Page 3 The adapter TLH CS-f has two parts: hex nut (left) and lock washer (right). The parts are set at an angle in this photo to show better detail. • View of camera with hex nut mounted to camera housing. Assembly Instructions for DMK/DFK/DBK Cameras, TLH CS-f and TBL Lenses...
- Page 4 • Lens mounted to lock washer. Assembly Instructions for DMK/DFK/DBK Cameras, TLH CS-f and TBL Lenses...
- Page 5 During the adjustment and mounting of the rings and nuts, dust from the abrasion of the threads can appear causing flecks in the image. In this event, the pieces must be disassem- bled, cleaned and assembled once again. Assembly Instructions for DMK/DFK/DBK Cameras, TLH CS-f and TBL Lenses...
-
Page 6: Assembly Instruction
All product and company names in this document may be trademarks and tradenames of their respective owners and are hereby acknowledged. The Imaging Source Europe GmbH cannot and does not take any responsibility or liability for any information contained in this document. The source code presented in this document is exclusively Headquarters: The Imaging Source Europe GmbH used for didactic purposes.
