The Superb Series
The Superb Series
The Superb Series
The Superb Series
The Superb Series
GRILL SHOWN WITH OPTIONAL SCG-36 CART
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
supplier or your fire department.
FOR YOUR SAFETY
1. Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING: If not installed, operated and
maintained in accordance with the manu-
facturer's instructions, this product could
expose you to substances in fuel or from fuel
combustion which can cause death or seri-
ous illness.
R-3848

INSTALLATION INSTRUCTIONS

OWNER'S MANUAL
COOKING APPLIANCE
S'il y a une odeur de gaz:
1. Coupez l'admission de gaz de l'appareil.
2. Éteindre toute flamme nue.
3. Ouvrir le couvercle.
4. Si l'odeur persiste, appeler immédiatement
votre compagnie de gaz ou votre département
des incendies.
1. Ne pas entreposer ni utiliser de l'essence ni
d'autres vapeurs ou liquides inflammables
dans le voisinage de l'appareil, ni de tout
autre appareil.
2. Une bouteille de propane que n'est pas
recordée en vue de son utilisation, ne doit pas
être entreposée dans le voisinage de cet
appareil ou de tout autre appareil.
AVERTISSEMENT: Si l'installation, l'usage
et l'entretien de ce produit ne sont pas faits
selon les instructions du fabricant, ce produit
peut vous exposer à des matières contenues
dans le carburant ou provenant de la
combustion du carburant lesquelles peuvent
causer la mort ou de sérieuses maladies.
AND
OUTDOOR
SSG-36-1
EFFECTIVE DATE
APRIL, 2003
AVERTISSEMENT
AVERTISSEMENT
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSG-36 and is the answer not in the manual?

Questions and answers

Summary of Contents for Broil King SSG-36

  • Page 1: Installation Instructions

    R-3848 INSTALLATION INSTRUCTIONS OWNER'S MANUAL OUTDOOR COOKING APPLIANCE SSG-36-1 EFFECTIVE DATE APRIL, 2003 AVERTISSEMENT S'il y a une odeur de gaz: 1. Coupez l'admission de gaz de l'appareil. 2. Éteindre toute flamme nue.
  • Page 2: Important Warnings

    For Outdoor Use Only. If Stored Indoors, Detach and Leave Cylinder Outdoors. • Read instructions before lighting. • Open lid during lighting. • If ignition does not immediately take place, turn the burner valve handles to OFF, wait 5 minutes, and repeat the lighting procedure. •...
  • Page 3: Specifications

    OVERFILL PROTECTION DEVICE (OPD) ON 20 LB. PROPANE CYLINDER Attention: Consumer be advised, this gas grill must be connected to an LP gas cylinder incorporating an OPD. The OPD will help reduce the potential for the overfilling of the propane cylinder, thus reducing the possibility of hydrostatic relief valve dis- charges.
  • Page 4 2. The owner shall retain this instruction manual for future reference. 3. Installer must have owner fill out and mail warranty card supplied with appliance. 4. Installer should show owner how to start and operate gas grill. LOCATION REQUIREMENTS Location (Figure 2 and Figure 3)
  • Page 5 1 - 5" thermometer for front lid 1 - 2 1/4" thermometer for steamer lid 1 inlet adaptor (LP gas grill only) 1 hose assembly with LP regulator (LP gas grill only) 1 Natural gas regulator (Natural gas grill only) 1 rotisserie rod...
  • Page 6 Install the regulator into the tank and check the hose and regulator connections for leakage with a soap and water solution before operating your Superb gas grill. Be sure there is gas in the tank. When lighting your grill always keep your face and body as far away from the grill as possible.
  • Page 7 Grill Plates (Figure 7) An exclusive feature of your Superb gas grill are the stainless steel grill plates designed to deflect the grease from falling into the burners thereby reducing flare-ups and extending the life of the burners. The perfora- tions in the stainless steel evens out the heat and creates a hot surface for the meat drippings to fall on to.
  • Page 8 Hot. Top Burners Your Superb gas grill is equipped with (5) grill burners, each rated at 12,000 BTUH and has (5) spark ignitors for easy lighting. Provided for use with your side burner rated at 30,000 BTUH is a stainless steel lid which doubles as work surface when the burner is not in use.
  • Page 9 Rotisserie (Figure 8) The (2) rotisserie burners, each rated at 12,000 BTUH, are an infrared type which provide intense searing radiant heat. This intense heat is perfect for searing in the natural juices and nutrients found in quality cuts of meats. When lit, the rotisserie burners will reach cooking temperatures in about 3 minutes.
  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE Stainless Steel The Superb gas grill is made from stainless steel. There are many different stainless steel cleaners available. Always use the mildest cleaning meth- ods first, scrubbing in the directions of the grain. To touch up noticeable scratches in the stainless steel, sand lightly with dry 100 grit emery paper or scotch bright pad in the direction of the grain.
  • Page 11 The brackets are located at each end (2 brackets) and between (1 bracket) the rotisserie burners. 8. At the center of the gas grill, grasp the end of rotisserie burner, pull forward and slide the opposite end of the rotisserie burner from the orifice fitting.
  • Page 12: Troubleshooting

    10. Attach four (4) collector boxes to bottom of inner liner with four (4) 10-16 x 1/2" Phillips stainless steel screws from Step 5. If your Superb gas grill does not function properly, use the following checklist before contacting your dealer for service. Grill won't light when the rotary ignitor is turned.
  • Page 13 PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide. Index Part Number Description SSG-140 STEAMER LID ASSEMBLY SSG-126 HANDLE - STEAMER LID R-4005 SHOULDER SCREW (STEAMER) (2 REQ’D) R-3987 THERMOMETER - STEAMER SSG-040 STEAMER BODY R-4010...
  • Page 14 Page 14 R-3848...
