Deva037 USB Encoder Interface User's Manual
V1.2
ENCODER INTERFACES
Deva037 USB Encoder Interface User's Manual
CONTENTS:
•
Overview
•
Installation and Configuration
•
Software Installation
•
USB Incremental Encoder Interface
Deva Electronic Controls Limited | 52 Woodside Business Park | Birkenhead | Wirral | CH41 1EL
Phone:
+44 (0)151 647 3222
hardware•
| Fax:
+44 (0)151 647 4511
For additional downloadable Support
Documentation, please visit
www.deva.co.uk/support-downloads
Or contact us at
| Email:
| Website:
sales@deva.co.uk
SUPPORT:
support@deva.co.uk
www.deva.co.uk
Advertisement
Table of Contents
Related Manuals for DEVA Deva037
Summary of Contents for DEVA Deva037
- Page 1 • USB Incremental Encoder Interface hardware• Or contact us at support@deva.co.uk Deva Electronic Controls Limited | 52 Woodside Business Park | Birkenhead | Wirral | CH41 1EL Phone: | Fax: | Email: | Website: +44 (0)151 647 3222 +44 (0)151 647 4511 sales@deva.co.uk...
- Page 2 © Deva Electronic Controls Ltd 2020 All information within this document is given in good faith by Deva Electronic Controls Ltd. Deva Electronic Controls Ltd shall not be liable for any loss or damage, howsoever arising, that may be attributed to errors within, or omissions from, this document, nor for the use of, or application of, the information provided herein.
-
Page 3: Table Of Contents
Deva037 USB Encoder Interface User’s Manual Contents Glossary/Definition of Terms ..................iii Overview ..................1 About this Manual ..................1 Deva Encoder Range Features ................. 1 Deva037 Features ..................1 1.3.1 Facilities ..........................2 Software Support ................... 2 1.4.1 Windows10/ Windows8/ Windows7/ WindowsXP 32/64............2 1.4.2... - Page 4 Deva037 USB Encoder Interface User’s Manual Contents 4.2.2 Marker input ........................15 4.2.3 Zero input .......................... 16 4.2.4 Touch Probe Interface ......................16 4.2.5 Optical Edge Detector Input ....................16 Page ii...
-
Page 5: Glossary/Definition Of Terms
Deva037 USB Encoder Interface User’s Manual Preliminary Pages Glossary/Definition of Terms Abbreviation/Acronym Definition Dynamic Link Library Digital Readout FIFO First In First Out Peripheral Component Interconnect PCIe Peripheral Component Interconnect express Transistor-Transistor Logic Universal Serial Bus Virtual Instrument Windows Driver Model... -
Page 7: Overview
SDK Programming Guide. Deva Encoder Range Features The Deva037 and Deva001 range of 3 and 4 axis Incremental and Absolute Encoder Interfaces are designed to enable simultaneous reading of 3 or 4 encoders per card, using a PC based system. Thus, with four 4-axis cards installed, up to 16 encoders can be supported by one system (Deva001 only). -
Page 8: Facilities
Digital Readout A Digital Readout (DRO) displays all the common facilities of the Deva037. This enables users to quickly verify that the Deva037 is installed correctly and to make checks of the system without having to write their own software. -
Page 9: Accessories
Deva037 USB Encoder Interface User’s Manual Overview «Hder_Sect_Title_1» Accessories The Deva037 Incremental Encoder Interface has three high density 15-way 'D' type connectors, one 9-way ‘D’ type connector and is supplied with matching shells. Page 3... -
Page 11: Hardware Installation
Hardware Installation System requirements The Deva037 requires a PC computer with a minimum of one spare USB port and Windows10/ Windows8/ Windows7/ WindowsXP 32/64 operating system. Both 32 and 64-bit operating systems are fully supported. Limited Linux support is available but is not covered herein. -
Page 13: Software Installation
‘Install Driver’ or ‘Update Driver’, again depending on OS. Ensure the Deva supplied USB stick is connected via a USB socket on the PC and select the ‘Install Driver’ or ‘Update Driver’ button. When prompted, browse to the USB stick and locate the folder ‘X:\Gold CD Relxx’... -
Page 14: Devacmmctrl Drivers And Software
The installation may then be tested using the supplied DRO program, which can be found on the USB stick at ‘X:\Gold CD Relxx\PC interface products\Deva037\Issue x.x\Windows\utils\Win xx’ (‘X’ and ‘xx’ will vary according to the PC setup and Deva software release). Open the DRO program and a display similar to Figure 3.1 will be seen. - Page 15 Deva037 USB Encoder Interface User’s Manual Software Installation Ensure the Deva supplied USB stick is plugged into a USB socket on the PC and select the ‘Install Driver’ or ‘Update Driver’ button. When prompted, browse to the USB stick and locate the folder ‘X:\Deva CMM Control Relxx’...
- Page 16 This will result in a basic configuration being setup with default values such as number of axes and axis types; the Deva Config Editor can then be used to customize the configuration as part of the machine installation. For more information see the Deva Config Editor manual.
- Page 17 Deva037 USB Encoder Interface User’s Manual Software Installation Figure 3.6 DevaCMM Control Panel Display ‘at rest’ Manually move the encoder (or press the probe if a probe has been connected). The reading should change to indicate displacement as shown in Figure 3.7. In the case of the example shown, the X axis position has changed to 543.575 and the ‘At Target’...
- Page 18 Deva037 USB Encoder Interface User’s Manual Software Installation Manual Figure 3.7 DevaCMM Control Panel Display after encoder displacement Page 12...
-
Page 19: Usb Incremental Encoder Interface Hardware
Deva037 USB Encoder Interface User’s Manual USB Incremental Encoder Interface Hardware USB Incremental Encoder Interface Hardware Connection details The layout of the Deva037 is shown in Figure 4.1. Power input and switch Enc. Enc. Probe Enc. Optical Figure 4.1 Deva037 Connectors 4.1.1... -
Page 20: Input Signal Descriptions
Deva037 USB Encoder Interface User’s Manual USB Incremental Encoder Interface Hardware 4.1.2 Input signal descriptions The Ai & nAi, Bi & nBi inputs are differential pairs for connection to the A-phase and B-phase quadrature outputs of an incremental encoder. The Mi & nMi inputs are differential inputs for the channel marker signal. This function will latch the counter reading for the relevant channel, allowing an accurate reading of the position of a moving encoder to be made at a specific instant. -
Page 21: Usb Connection
Functional description The Deva037 is designed to interface up to three incremental encoders or linear scales to the USB bus. The functions are programmed via Deva’s proprietary interface Enclib and/or, where the device is to be used in a CMM application, a utility such as DevaCMMCtrl. - Page 22 4.2.4 Touch Probe Interface The Deva037 incorporates a touch probe input. This input provides the correct signal conditioning to allow a volt-free contact type touch probe to be used. The probe function works like the marker function but latches all three axis counters simultaneously. Unlike the marker function it operates asynchronously and hence does not require that the A and B signals be at a logic one level.
- Page 24 For additional downloadable Support Documentation, please visit www.deva.co.uk/support-downloads Or contact us at support@deva.co.uk Deva Electronic Controls Limited | 52 Woodside Business Park | Birkenhead | Wirral | CH41 1EL Phone: | Fax: | Email: | Website: +44 (0)151 647 3222 +44 (0)151 647 4511 sales@deva.co.uk...
