Web: www.xtooltech.com
Programmable Universal
Tire Pressure Sensor
Attention: Before using the Xtool TS100 tire pressure sensor,
you must use Xtool tire pressure programming device to
program first, we suggest finishing programming before
installing tires. When driving the vehicle which is equipped
with this type of tire pressure sensor, we suggest maintaining
vehicle driving speed≤240km/h.
Metal Cycle Valve
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Xtool TS100
Summary of Contents for Xtool TS100
- Page 1 Programmable Universal Tire Pressure Sensor Metal Cycle Valve Attention: Before using the Xtool TS100 tire pressure sensor, you must use Xtool tire pressure programming device to program first, we suggest finishing programming before installing tires. When driving the vehicle which is equipped with this type of tire pressure sensor, we suggest maintaining vehicle driving speed≤240km/h.
- Page 2 In order to guarantee optimum performance, please do not install cycle valve and parts which are not belong to Xtool on Xtool TS100 tire pressure sensor. After finishing installation, please test vehicle TPMS according to original vehicle manufacturer’s user guide steps to confirm correct installation.
-
Page 3: Warranty Repair
Warranty repair Shenzhen Xtooltech Co., Ltd（Hereinafter referred to as Intelligent “Company") promise to all this product original retail buyers, since the day of delivery and under two years or under 40000 km, if in the case of normal use, this product or any parts is confirmed to exist material or the flaw of craft resulting in device breakdown, the company will repair or replace (new products or new parts) free of charge accordingly via proof of purchase. - Page 4 Every time tire repair or disassembling, TS100 tire pressure sensor disassembling or replacement, must use our parts to replace rubber washer, washer, nut and valve core, make sure sealing well. If it is external damage, must replace TS100 tire pressure sensor. Correct TS100 tire pressure sensor nut torque: 4Nm.
- Page 5 Please use TS100 tire pressure sensor correctly according to this instruction, otherwise it may be result in TS100 damage or personal injury, and make the warranty repair invalid. Loosen tire Take down valve cap and valve core, deflate the tire.
- Page 6 Attention: In the whole removal process must abide by this beginning location. Remove TS100 tire pressure sensor Remove the valve cap, nut, washer from cycle valve rod, then remove TS100 tire pressure sensor module...
- Page 7 Attention: Make sure the parts are connected firmly. Step2. Remove the valve cap nut and washer from cycle valve. Step3. Valve rod across the valve opening, let TS100 tire pressure sensor located in rim interior, assemble washer nut on valve rod fist at last.
- Page 8 Step 3 Step 4 Install tire Put tire on the rim, make sure the valve is facing the separation head at 180 ° angle on the rim. Attention: Should abide by change tire machine manufacturer instruction to install tire on rim.
- Page 9 Web: www.xtooltech.com Programmable Universal Tire Pressure Sensor Attention: Before using Xtool TS100 tire pressure sensor must use Xtool tire pressure device to program, suggest finishing programming before tire mounting. When driving the vehicle which is equipped with this type of tire pressure sensor, we suggest maintaining vehicle...
- Page 10 Please do not install TPMS tire pressure sensor into the broken tire which has been programmed. In order to guarantee optimum performance, please do not install cycle valve and parts which are not belong to Xtool on Xtool TS100 tire pressure sensor. After finishing installation, please test vehicle TPMS according to original...
- Page 11 Warranty repair Shenzhen Xtooltech Co., Ltd（Hereinafter referred to as Intelligent “Company") promise to all this product original retail buyers, since the day of delivery and under two years or under 40000 km, if in the case of normal use, this product or any parts is confirmed to exist material or the flaw of craft resulting in device breakdown, the company will repair or replace (new products or new parts) free of charge accordingly via proof of purchase.
- Page 12 Every time tire repair or disassembling, TS100 tire pressure sensor disassembling or replacement, must use our parts to replace rubber washer, washer, nut and valve core, make sure sealing well. If it is external damage, must replace TS100 tire pressure sensor. Correct TS100 tire pressure sensor nut torque: 4Nm.
- Page 13 Please use TS100 tire pressure sensor correctly according to this instruction, otherwise it may be result in TS100 damage or personal injury, and make the warranty repair invalid. Loosen tire Remove bonnet and core, and deflate the tire.
- Page 14 Unload tire Clamp the tire on tire changer, and it is relative to tire separated plug in to adjust cycle valve at 1 o’clock. Insert tire tool and lift tire bead on installation plug to unload tire bead. Attention: In the whole removal process must abide by this beginning location.
- Page 15 Install TS100 tire pressure sensor and cycle valve Step 1. Tighten the screws to connect the cycle valve and sensor subject firmly. Paint grease or lubricating oil on rubber valve rod.
- Page 16 Step 2 Step 3 Install tire Put the tire on the rim, make sure cycle valve via 180°face to separated plug. Install the tire on the rim. Attention: Should use change tire machine manufacturer instruction to install tire on rim.
