Page 2: Table Of Contents
ABLE OF ONTENTS You have chosen the finest grill for your outdoor cooking pleasure. Please take time to read this entire manual before assembling your premium Broilmaster Important Information ... 3 PC Hardware Package ... 4 DC Hardware Package ... 5 Cart Exploded View ... -
Page 3: Grill Location
Broilmaster Premium Gas Grills are designed for outdoor use ONLY. This cart is are designed for use with Broilmaster grills and must not be used with any other grill or for any other purpose. Never install or operate your grill in any building, garage, or other enclosed area. -
Page 4: Pc Hardware Package
PC H ARDWARE ACKAGE B062998 KNOB Page 4 B100999-1-0906... -
Page 5: Dc Hardware Package
DC H ARDWARE ACKAGE B072220 SCREW 1/4-20 X 3/4 PH TRUSS HEAD BOS B100116 1/4-20 X ½ HEX HEAD BOS B062998 KNOB B100137 SCREW #10-24 X 3/8 PH TRUSS HEAD BOS B072181 1/4-20 WING NUT BOS B100999-1-0906 Page 5... -
Page 6: Cart Exploded View
XPLODED EMOVE PROTECTIVE COATING AND VERIFY THAT ALL PARTS LISTED ON THE EXPLODED VIEW OF THIS MANUAL HAVE BEEN INCLUDED BEFORE BEGINNING ASSEMBLY AUTION SE CAUTION WHEN HANDLING PARTS AS THEY MAY CONTAIN SHARP EDGES ORK GLOVES ARE RECOMMENDED TO PREVENT INJURY OOLS EQUIRED HILLIPS... -
Page 7: Cart Parts List
ARTS All repair part orders should be placed through your local Broilmaster in your area, contact Broilmaster Customer Service at 800-851-3153 • www.broilmaster.com. To ensure prompt and accurate service, please provide the following information when placing a repair part order: Model Number, Part Name, Part Number, and Quantity of parts needed. -
Page 8: Cart Assembly
SSEMBLY Attention: Peel protective film from all parts before assembly. Caution: Be careful when handling parts, as they may contain sharp edges. Work gloves are recom- mended to prevent injury. In each illustration parts are identified with "Key" num- bers. Key numbers appear in parenthesis after a part name is mentioned for the first time in the instructions and are labeled on the illustrations. - Page 9 Using four 1/4-20 x 3/4 screws, fasten the grill to the cart. Figure 4. Note: To ease assembly you may wish to install the ig- niter as shown in your Broilmaster attaching the grill to the cart. IGURE Install one 1/4-20 x 1/2 hex head BOS into drip pan drawer assembly (2) and tighten knob (1).
-
Page 10: Fixed Base Assembly
IXED NSTALLATION Attention: Peel protective film from all parts before assembly. Caution: Be careful when handling parts, as they may contain sharp edges. Work gloves are recom- mended to prevent injury. In each illustration parts are identified with "Key" num- bers. - Page 11 IGURE Using four 1/4-20 x 3/4 screws, fasten the grill to the cart. Figure 12. Note: To ease assembly you may wish to install the igniter as shown in your Broilmaster attaching the grill to the cart. IGURE B100999-1-0906 NSTRUCTIONS Install one 1/4-20 x 1/2 hex head BOS into drip pan drawer assembly (2) and tighten knob (1).
- Page 12 Place the drip pan in the drip pan drawer and slide onto drip pan bracket. Figure 15. IGURE ETAIN . B100999-0-0906 Page 12 NSTRUCTIONS BROILMASTER A Division of Empire Comfort Systems, Inc. 918 Freeburg Ave. Belleville, Illinois 62220 Phone: 1-800-851-3153 FAX: 1-800-443-8648 .broilmaster.com ISIT OUR WEB SITE AT WWW ’...
