- Page 1 MIR5000-M3P Quick guide for installation and use UM036EN01...
-
Page 2: Table Of Contents
UM036EN01 MIR5000-M3P. Quick guide for installation and use TABLE OF CONTENTS INTRODUCTION ......................1 INSTALLATION OF MIR5000 RECEPTION SYSTEM ..............2 INSTALLATION DIAGRAM ..................2 RECEIVER –INTERFACE CABLE ASSEMBLY ..............3 MSB PALANGRE AND MIR5000 DRIVERS INSTALLATION ............4 PC MINIMUM REQUIREMENTS ..................4 SOFTWARE AND DRIVERS INSTALLATION .............. - Page 3 UM036EN01 MIR5000-M3P. Quick guide for installation and use LONGLINE CONFIGURATION ..................20 ACCESS AND CONFIGURATION ................. 20 LONGLINE DISPLAYED ON THE CHART ................ 23...
-
Page 4: Introduction
MIR5000 buoy reception system with M3P and M3P-T models. The new longline location system designed by Marine Instruments includes transmitters (M3P and M3P-T buoys) which will send positions of several points of the lines configured, the buoy reception system via radio (MIR5000) and MSB Palangre software, which displays the data received by MIR5000. -
Page 5: Installation Of Mir5000 Reception System
UM036EN01 MIR5000-M3P. Quick guide for installation and use 2 INSTALLATION OF MIR5000 RECEPTION SYSTEM 2.1 INSTALLATION DIAGRAM WARNING: MIR5000 must be supplied with the 220V transformer provided with the device. Supply at 24 V is not allowed. OUTDOORS INDOORS Page 2 / 23... -
Page 6: Receiver -Interface Cable Assembly
UM036EN01 MIR5000-M3P. Quick guide for installation and use RECEIVER –INTERFACE CABLE ASSEMBLY Connecting the device to the vessel ground is necessary for a correct system operation. Page 3 / 23... -
Page 7: Msb Palangre And Mir5000 Drivers Installation
UM036EN01 MIR5000-M3P. Quick guide for installation and use 3 MSB PALANGRE AND MIR5000 DRIVERS INSTALLATION 3.1 PC MINIMUM REQUIREMENTS Minimum requirements Recommended Operating System XP SP3 or later XP SP3 or later Processor 1.5 GHz 2 GHz or later Memory... -
Page 8: Windows Configuration
UM036EN01 MIR5000-M3P. Quick guide for installation and use 3.3 WINDOWS CONFIGURATION NEVER TURN OFF HARD DISKS NOR DISPLAY: Control Panel All control panel items Power Options In your computer power plan, Change plan settings Turn off the Display: NEVER; Put the computer to sleep: NEVER;... - Page 9 UM036EN01 MIR5000-M3P. Quick guide for installation and use Page 6 / 23...
- Page 10 UM036EN01 MIR5000-M3P. Quick guide for installation and use WHEN MSB-PALANGRE IS FINALLY INSTALLED: Right click on MSB-Palangre Properties Compatibility tab Run this program as an administrator. Page 7 / 23...
-
Page 11: Starting The System
UM036EN01 MIR5000-M3P. Quick guide for installation and use 4 STARTING THE SYSTEM 4.1 SWITCHING ON Switch MIR5000 on: Check the device has been successfully installed. Restarting is recommended. Page 8 / 23... -
Page 12: Detección De Puertos En Msb Palangre
UM036EN01 MIR5000-M3P. Quick guide for installation and use 4.1 DETECCIÓN DE PUERTOS EN MSB PALANGRE Run MSB-Palangre, double-clicking on in Windows Desktop and create a new set. When a new fishing journey starts, it is recommended creating a new set, so MSB Palangre will save all the data of the trip. - Page 13 UM036EN01 MIR5000-M3P. Quick guide for installation and use To detect the ports, click on Settings and, in the “General” tab, select MIR5000. Next, click on Detect. The GPS will take several seconds in being fixed. Page 10 / 23...
-
Page 14: Checking Settings Parameters
UM036EN01 MIR5000-M3P. Quick guide for installation and use 4.2 CHECKING SETTINGS PARAMETERS In Settings: Page 11 / 23... -
Page 15: Entering Buoy Data
UM036EN01 MIR5000-M3P. Quick guide for installation and use 5 ENTERING BUOY DATA Depending on the buoy model, its data can be entered automatically (M3P or later) or they must be entered by hand (M2P, MBP or older). For further information, consult User Manual UM023. - Page 16 UM036EN01 MIR5000-M3P. Quick guide for installation and use Select the buoys transmission interval: EVERY buoy must transmit with the same transmission interval (every 5, 10 or 15 minutes). If a buoy transmits with a different interval, it has to be programmed.
-
Page 17: Automatic Buoy Identification
UM036EN01 MIR5000-M3P. Quick guide for installation and use 5.1.1 AUTOMATIC BUOY IDENTIFICATION ONLY M3P BUOYS OR NEWER CAN BE IDENTIFIED AUTOMATICALLY BY MSB PALANGRE. Automatic buoy identification. Click on this button and start buoy. Page 14 / 23... - Page 18 UM036EN01 MIR5000-M3P. Quick guide for installation and use Buoy data will be entered automatically. This process will last just a few minutes: Page 15 / 23...
- Page 19 UM036EN01 MIR5000-M3P. Quick guide for installation and use IN CASE THE WINDOW IS ALREADY FULL, OVERWRITE CONFIRMATION WILL BE REQUIRED. TO USE THE NEW BUOY, IT MUST BE REPROGRAMMED WITH OTHER DATA. IF YOU ARE TRYING TO ENTER AN ALREADY EXISTING BUOY DATA IN ITS WINDOW, A NOTICE WILL BE DISPLAYED AND THE OPERATION WILL BE DISCARDED.
-
Page 20: How To Delete Buoys
UM036EN01 MIR5000-M3P. Quick guide for installation and use 5.1.2 HOW TO DELETE BUOYS To remove a buoy, select it and then click on . A message of confirmation will be displayed: Click on Remove Select buoy Buoy data will be deleted. - Page 21 UM036EN01 MIR5000-M3P. Quick guide for installation and use Two buoys CANNOT transmit in the same window. In this case one of the buoys must be reprogrammed. Before deploying the buoy, check that at least one position has been received in the software and that the buoy is displayed on the chart.
-
Page 22: Buoy Reception Check
UM036EN01 MIR5000-M3P. Quick guide for installation and use 6 BUOY RECEPTION CHECK Ayuda To fix the Main Panel Previous buoy Second hand Next buoy Buoy not received The buoy takes about 15 minutes in sending its firts position. Then, it will be displayed on the chart. - Page 23 UM036EN01 MIR5000-M3P. Quick guide for installation and use 7 LONGLINE CONFIGURATION 7.1 ACCESS AND CONFIGURATION After having entered the buoys in MSB Palangre, you can configure the longlines according to the actual order the buoys are deployed, so that the line will be correctly displayed.
- Page 24 UM036EN01 MIR5000-M3P. Quick guide for installation and use remove longline. Confirmation is required. This percentage applied to the distance between buoys and it determines when Palangre warns of line breaks. To add buoys to the longline. Enabled to have the To change the longline displayed.
- Page 25 UM036EN01 MIR5000-M3P. Quick guide for installation and use CONFIGURED LONGLINES Page 22 / 23...
- Page 26 UM036EN01 MIR5000-M3P. Quick guide for installation and use 7.2 LONGLINE DISPLAYED ON THE CHART Page 23 / 23...
- Page 27 UM036EN01 MIR5000-M3P. Quick guide for installation and use This product guarantee conditions are available in Marine Instruments website. Rúa dos Padróns nº 4 (Vial 3) Parque Empresarial Porto do Molle 36350 Nigrán (Pontevedra-Spain) Tel: +34 986 366 360 Fax: +34 986 383 007 marineinstruments@marineinstruments.es...
