Summary of Contents for Summit to Sea GRAND DIVE PRO

  • Page 1 GRAND DIVE PRO...
  • Page 2 PARTS ON THE CHAMBER FRONT 2 Blue Air Port to Release connect a Valves cooler...
  • Page 3 PARTS ON THE CHAMBER REAR OF CHAMBER External Gauge Port to connect a cooler 2 Fill Valves Red knob to release air Internal 2 Auxiliary Valves if using an Gauge oxygen concentrator...
  • Page 4 SET UP • Lay the deflated chamber out of the floor with the open flap facing to the front. • Connect compressors • Close both zippers • Inflate chamber • Build frame around the inflated chamber and connect velcro straps •...
  • Page 5 INFLATING At first, follow these instructions to inflate and deflate the chamber without any person inside the chamber. WARNING Never take a treatment alone. Always have someone outside the chamber to assist you.
  • Page 6 SET UP First connect the compressors to the back of the chamber. You will notice that at the end of each compressor hose is a quick connect. Simply click it onto the white fill valve.
  • Page 7 SET UP Check to make sure the red relief valve is shut by lining up the dots.
  • Page 8 SET UP There are two zippers that circle the entire end of the chamber. These zippers are dual-triggered and can be opened and closed from inside or outside the chamber.
  • Page 9 SET UP Dock It is important that the inside zipper is totally closed into the dock.
  • Page 10 SET UP Be sure that the zipper pull is tucked under the red arrow and pulled closed all the way...
  • Page 11 SET UP Pictured is the right and wrong way to close the inside zipper.
  • Page 12 SET UP • You will now need to close both zippers to inflate the chamber. • Once the zippers are completely closed, plug the compressors into the electrical wall outlet. • Make sure the red knob is completely closed. • The chamber will inflate.
  • Page 13 BUILDING THE FRAME Notice the labeled parts of the frame on the left and how they connect to the completed frame.
  • Page 14 BUILDING THE FRAME Make the rectangle on the floor...
  • Page 15 BUILDING THE FRAME When the chamber is to shape add the velcro wedges to the bottom to stabilize the chamber.
  • Page 16 BUILDING THE FRAME You should have a large rectangle surrounding the chamber on the floor.
  • Page 17 BUILDING THE FRAME Add Part C short poles to each corner of the frame...
  • Page 18 BUILDING THE FRAME Take both sets of Part B and screw the together to make the arches...
  • Page 19 BUILDING THE FRAME Add the arches to each end of the frame. You will notice there are 4 small holes on each arch piece. The holes need to be facing to the center of the chamber.
  • Page 20 BUILDING THE FRAME Wrap the velcro straps around the frame arches...
  • Page 21 BUILDING THE FRAME Place Part D poles into the small holes on the arches - Part B. There are 4 poles to connect the arches.
  • Page 22 BUILDING THE FRAME Next wrap each velcro loop around the frame poles and arches...
  • Page 23 BUILDING THE FRAME You will notice that there are velcro attachments along each side of the chamber and along the top of the chamber. Wrap each velcro attachment around the pole.
  • Page 24 BUILDING THE FRAME Do not connect the velcro near the bottom of the chamber...
  • Page 25 BUILDING THE FRAME Side view Top view...
  • Page 26 DEFLATING Turn the dump valve so that the Once the gauge reads zero air is released. you can unzip the zippers.
  • Page 27 DEFLATING Pull the inner zipper pull tab Pull the outer zipper pull tab...
  • Page 28 INSERTING THE MAT After you deflate the chamber you will want to place the tri-fold mat inside the chamber.
  • Page 29 INFLATING Make sure both the inside and the outside zippers are completely closed each time the chamber is in use. Failure to do this may result in damage to the chamber.
  • Page 30 INFLATING If the relief valve does not release air when it is at full pressure, stop your treatment and call your distributor. The compressor must remain on for the entire treatment period to ensure the circulation and exchange of fresh air, which provides a safe and comfortable treatment.

  • Page 31: During Treatment

    DURING TREATMENT As the chamber begins to inflate, you may notice added pressure on the ears. This feeling indicates the need to equalize the pressure. The pressure feeling is similar to that of landing in an airplane. This pressure is relieved through the Eustachian tube. There are several methods for relieving this pressure.
  • Page 32 DURING TREATMENT The first, is the Valsavla maneuver. Pinch your nose, close your mouth and try gently blowing out your nose. Repeat every time you begin to feel that pressure Yawning or opening your mouth wide will also help. Lastly, chewing gum may help relieve this pressure. If the above suggestions do not resolve the ear pressure, open the red relief knob until the feeling of pressure is gone.
  • Page 33 DURING TREATMENT WHAT TO WEAR You may wear any type of clothing in the chamber; however, comfortable and soft clothing is typically used. Do not wear shoes inside the chamber.
  • Page 34 DURING TREATMENT WHAT TO BRING INTO THE CHAMBER Feel free to bring food, drinks, books and personal computers, DVD players or any other form of entertainment into the chamber. It may also be helpful to have your cell phone with you. We ask that you refrain from bringing in sharp objects such as forks or knives.
  • Page 35 REMINDERS REMEMBER THESE IMPORTANT STEPS Be sure both zippers are completely closed. Do not open the zipper until the gauge reads zero. The compressors must be running during the whole time of treatment. The relief valve must be releasing air when the chamber is at full pressure.
  • Page 36 Summit to Sea also believes that we have the best customer service of any hyperbaric chamber company on the market. We will always try our best to be available and give you prompt service.
  • Page 37 CHAMBER CARE ZIPPERS The outside zipper requires no maintenance. Periodically, wipe the outside open zipper with a damp cloth.
  • Page 38 CHAMBER CARE On occasion the inside airtight zipper requires Tzip silicone lubricant.The chamber comes with this Tzip silicone to lubricate the docks where the zipper triggers are secured. It is necessary to keep this dock lubricated. Squeeze a small amount of the silicone onto your finger and spread it out on the dock.
  • Page 39 CHAMBER CARE CLEANING THE CHAMBER There is no maintenance needed other than cleaning with a non-petroleum based household cleaner. FITTINGS & HOSES Regularly check the fittings and hoses for cracks or damage. If you see any damage, call your distributor for a replacement part.
  • Page 40 CHAMBER CARE COMPRESSOR & FILTER There is an intake fabric filter on the compressor that has the curved plastic cover. Instructions for cleaning the filter are on the cover. The recommendation on the compressor cover is to replace the filter once per year based on 24 hour per day usage.
  • Page 41 CHAMBER CARE Resetting the Safety Switch If your compressor is jarred during shipment or operation in your home the shut off switch may be triggered. If this happens follow these instructions to reset the safety switch. First, make sure the compressor is unplugged. You will need to remove the cover by unscrewing the four screws at the base of your compressor.
  • Page 42 CHAMBER CARE Resetting the Safety Switch First you will need to remove the compressor cover by loosening the 4 screws with a pair of pilers and then using a Philips screwdriver to remove the screws.
  • Page 43 CHAMBER CARE Resetting the Safety Switch If the safety switch has been tripped you will see this little red button. Move the white switch to the center of the compartment.
  • Page 44 CHAMBER CARE Resetting the Safety Switch Next, be very careful to line up the cover with the screw holes in the base of the compressor. Tighten the screws with a Philips screwdriver. Then plug your compressors into the electric outlet.
  • Page 45 CHAMBER CARE White Compressor Filter There is a filter right under the top plate of the compressor. Clean with water every 6 months. You will want to replace the filter every year. You can order these filters on www.summit-to-sea.com/accessories...
  • Page 46 CHAMBER CARE The .001 Micron Filter Follow these instructions to replace this filter You will want to replace the filter every 6 months. You can order these filters on www.summit-to-sea.com/accessories Push the black bulb up Unscrew the silver Put the black bulb Lay the compressor on its side and give it a quarter filter piece.
  • Page 47 CHAMBER CARE STORAGE Prior to storing the chamber, ensure that it has been cleaned inside and out by using a non-petroleum based household cleaner. Carefully fold the chamber ensuring all gauges and fittings are protected with bubble wrap or a similar material. Place the chamber in the carry case and store in a dry area between 40 and 80 degrees.

  • Page 48: Warranty

    Shipping to and from Summit to Sea is the customer's responsibility. Summit to Sea has always and will continue to cover all components on our chambers — including zipper, windows, seams, valves, hoses... in other words, if it came from Summit to Sea we will stand behind our product.

  • Page 49: Extended Warranty

    EXTENDED WARRANTY Extended warranties are available for purchase anytime within the two year warranty period. The extended warranties also cover all components on the chamber — including zipper, windows, seams, valves, hoses, etc. Contact your distributor. 1 Year Extended warranty $950 2 Year Extended warranty $1,050 3 Year Extended warranty $1,150...

  • Page 50: Important To Read

    IMPORTANT TO READ Important Safety Considerations You should NOT use this chamber without guidance and instruction from your health care provider. Do NOT use the chamber if you have the following conditions: Common colds or flu-like symptoms Recent alcohol consumption Blocked ear canals Blocked sinuses Otic barotraumas...
  • Page 51 IMPORTANT TO READ CAUTIONS CAUTION: Federal law requires this device for sale by or on the order of a physician. CAUTION: Do not inflate the chamber with only pure oxygen; use the compressor provided. It is designed to work safely with the chamber. CAUTION: Inspect all seams and fittings prior to use to ensure they are secure.
  • Page 52 IMPORTANT TO READ WARNING: In the unlikely event that there is a rapid decompression, the individual inside the chamber must EXHALE. Please make sure that each individual receiving treatment understands this precaution. WARNING: Do not replace the compressor with any other model. The chamber is designed to work specifically with the compressor provided.
  • Page 53 IMPORTANT TO READ Pressure Regulation Valves (Relief Valves) Summit to Sea Chambers utilizes redundant pressure regulation valves. These are factory programmed to ensure a steady, constant pressure. During treatment, there will be a steady flow of fresh air through the chamber. For proper operation, the air compressor is to be running throughout the entire treatment.
  • Page 54 IMPORTANT TO READ Compressor- Ultra quiet compressors provide patented sound suppression which permits a restful and relaxing dive experience. These highly compact compressors are designed for continuous operation providing you with a longlasting solution to hyperbaric pressurization needs. This compressor is small and compact making it easy to transport. With its small carbon footprint, this compressor will easily integrate into your environment.
  • Page 55 IMPORTANT TO READ Valves-The Grand Dive has three pressure release valves to ensure a safe and comfortable operation. This redundancy assures your safety. The Shallow and the Dive have two release valves. Windows-The window has a five layer, one firm acrylic layer between four vinyl layers to ensure a long lasting, permanent seal.
  • Page 56 IMPORTANT TO READ USE CARE to avoid the use of any sharp objects that may penetrate the walls of the chamber. WARNING: Never take a treatment alone. Always have someone outside the chamber to assist you. CLEAN the inside of the chamber with a soft, damp microfiber cloth provided after each use.
  • Page 57 IMPORTANT TO READ Be sure to swallow often during the pressurization process. If you cannot clear your ears, have the individual helping you temporarily stop the compressor until the pressure in your ears releases. Once the chamber is at full pressure, you will hear the “hissing” of the exhaust valves. This is important as it will prevent CO2 build up.
  • Page 58 IMPORTANT TO READ FDA 510K CLEARANCE Portable Mild Hyperbaric Chambers are Class II Medical Devices. They meet the FDA 510(k) Specifications. The chamber has been cleared by the FDA for the treatment of Acute High Altitude Sickness. FDA WARNING Increasing the percentages of oxygen content in the air delivery is considered the same as administering a drug under FDA regulations.
  • Page 59 SUMMIT TO SEA To order additional: filters zipper lubricant zipper cleaner www.summit-to-sea.com/accessories...
  • Page 60 SUMMIT TO SEA PO Box 339 Mound, MN 55364 Phone 1.877.PSI.DIVE (1.877.774.3483) Fax 1.877.420.7622 www.summit-to-sea.com © 2011 Summit to Sea, LLC...
