- Page 1 Washer-Dryer User Manual BWD7541W Document Number : 2820529346_EN/ 19-03-21.(9:19)
- Page 2 • Read user manual. Dear Customer, • Packaging materials of the Thank you for choosing a Beko product. We product are manufactured hope that you get the best results from your from recyclable materials in product which has been manufactured with accordance with regulations.
- Page 3 1 Important instructions for safety and environment This section contains safety instructions PRECAUTION! that will help protect from risk of personal injury or property damage. • The appliance must not be installed Failure to follow these instructions behind a lockable door, a sliding shall invalidate any warranty.
- Page 4 WARNING! CAUTION! • The appliance must not be • The water supply and draining supplied through an external hoses must be securely fastened switching device, such as a timer, and remain undamaged. Otherwise, or connected to a circuit that is there is the risk of water leakage.
- Page 5 INFORMATION DANGER! • If a non-self-resetting thermal cut-out • Laundry stained with Liquid is required in order to comply with cooking oil, acetone, alcohol, the standard then the instructions for petrol, kerosene, spot removers, appliances incorporating a non-self- turpentine, waxes and wax resetting thermal cutout that is reset removers must be washed in hot by disconnection of the supply mains...
- Page 6 CAUTION! DANGER! • Do not stop the machine before • If you use washing ball, detergent drying programme is completed. scale, laundry clothing cages and If you have to stop the machine, balls in your machine, they can remove all laundry and lay them in a melt during drying.
- Page 7 1.2 Intended use PRECAUTION! • Check all clothes before loading them INFORMATION into the machine and ensure that they • This product has been designed for do not have objects such as lighters, domestic use. It is not suitable for coins, metal pieces, needles in the commercial use and it must not be pockets or inside.
- Page 8 1.3 Children's safety Help protect the environment and natural resources by recycling used products. For children’s safety, cut the power cable CAUTION! and break the locking mechanism of the loading door so that it will be non-functional • Children below the age of 3 must be before disposing of the product.
- Page 9 2.2 Package contents Power cable Water discharge hose Transit bolts Mains water inlet hose Liquid detergent container (*) User manual Plastic plug group INFORMATION • Figures in this manual are schematic and may not match the product exactly. (*) This may be supplied with the machine depending on the model of your product. 9 / EN Washer-Dryer / User Manual...
- Page 10 2.3 Technical specifications Supplier name or trademark Beko Model name BWD7541W Maximum spin speed (rpm) 1400 Built-in Rated capacity - Washing (kg) of Dry clothes/laundry Rated capacity - Drying (kg) of Dry clothes/laundry Height (cm) Width (cm) Depth (cm) Single Water inlet / Double Water inlet •...
- Page 11 • Do not place the product close to the 3 Installation edge if the floor contains steps. Do not also place the product on a platform. To make the product ready for use, review the • Do not place the product on the power cable. information in the user manual and make sure •...
- Page 12 CAUTION! 1 Use a tool to • Models with a single water inlet should loosen all bolts until not be connected to the hot water they rotate freely. tap. In such a case the laundry will get damaged or the product will switch to protection mode and will not operate.
- Page 13 3.5 Connecting to the drain 3.6 Adjusting the feet • Attach the end of the drain hose directly to waste water drain, sink or bathtub. CAUTION! • Your house will be flooded if the hose comes out of its housing during water discharge.
- Page 14 • If the current value of the fuse or breaker 4 Preparation in the house is less than 16 Amps, have a qualified electrician install a 16 Amp fuse. 4.1 Sorting the laundry • The voltage specified in the “Technical * Sort laundry according to type of specifications”...
- Page 15 To prepare the product for washing INFORMATION laundry, perform first operation in Drum Cleaning programme. If this programme • Laundry that are subjected to materials is not available on your machine, apply such as flour, lime dust, milk powder, the method described in section 6.2. etc.
- Page 16 • Do not select a programme with prewash if • The loading door is locked while a programme you are using a detergent bag or dispensing is running. The door lock will open ball. Place the detergent bag or the immediately after the washing programme has dispensing ball directly among the laundry ended.
- Page 17 4.7.5 Using softeners 4.7.7 Using gel and tablet detergent Pour the softener into the softener • If the gel detergent thickness is fluidal and compartment of the detergent drawer. your machine does not contain a special • Do not exceed the (>max<) level marking liquid detergent container, put the gel in the softener compartment.
- Page 18 4.7.10 Using limescale remover • Do not use bleach and detergent by mixing them. • When required, use limescale • Use just a little amount (approximately removers manufactured specifically 50 ml) of bleach and rinse the clothes for washing machines only. very well as it causes skin irritation.
- Page 19 4.9 Tips for correct drying Programmes Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear Washes and dries Washes and dries respectively! Stainless clothes that has Sheet, bedding, baby respectively! Sheet, Sheet, bedding, baby clothes, been worn for a short time clothes, t-shirts, sweatshirts, bedding, baby clothes, t-shirts, sweatshirts, durable...
- Page 20 5.3 Preparing the Machine 5 Operating the product 1. Check if the hoses are connected tightly. 5.1 Control panel 2. Plug in your machine. 3. Turn the tap on completely. 4. Place the laundry in the machine. 5. Add detergent and fabric softener. 5.4 Selecting a washing programme 1.
-
Page 21: Cottons
• Cottons • Wool / Hand Wash You can wash your durable cotton laundry Use this programme to wash your woolen (sheets, bedlinen, towels, bathrobes, underwear clothes. Select the appropriate temperature etc.) in this programme. When you press the complying with the tag of your clothes. Your quick wash function key, programme duration laundry will be washed with very delicate becomes notably shorter but effective washing is... -
Page 22: Down Wear
• Daily-Quick / Quick 14’ Use this programme to wash your lightly soiled INFORMATION cotton clothes in a short time. The programme duration can be reduced down to 14 minutes • You can dry your laundry without any when the quick wash function is selected. When interruption right after the washing the quick wash function is selected, maximum programme (it is possible to perform... -
Page 23: Mix
• Mix You can use this programme to wash cottons and INFORMATION synthetics together without the need to sort them. • You can dry your laundry without any interruption right after the washing INFORMATION programme (it is possible to perform automatic or scheduled drying after •... - Page 24 Press the Temperature Adjustment key to change the temperature. INFORMATION • Spin Speed Adjustment button works INFORMATION only backwards. For example, if the display shows 800 rpm but you want • Temperature Adjustment button works only to select 1000 rpm, you will need to backwards.
- Page 25 INFORMATION INFORMATION • Only for dying programmes, press the • If you are going to dry laundry that Auxiliary Function Selection button comprises only towels and bathrobes, to set the suitable drying option. the maximum amount of laundry that can be loaded is 4 kg. 5.8 Drying programmes •...
-
Page 26: Table Of Contents
Data required for performance tests shall be provided upon request.Requests can be e-mailed to the following address: • info.australialaundry@beko.com Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact information. - Page 27 • : Selectable. * : Automatically selected, cannot be cancelled. ** : Energy Label programme ***: If the maximum spin speed of the machine is lower, you can select values up to the maximum spin speed value. *****: These programmes can be used with the HomeWhiz application. - : See the programme description for maximum load.
- Page 28 5.11 Auxiliary function selection INFORMATION Select the desired auxiliary functions before starting the programme. When a programme is selected, • If the selected wetness level (Iron Dry, lights of the auxiliary functions that can be selected Cupboard Dry, Cupboard Extra Dry) together with that programme will turn on.
- Page 29 • Remote Control • Anti-Crease+ If you press and hold the spin selection button You can use this auxiliary function button to connect your product to smart devices. for 3 seconds, this function will be selected and the programme follow-up light of the For detailed information, see HomeWhiz and the Remote Control Function.
- Page 30 • Bluetooth 5.12.3 Extra Dry You can use the Bluetooth connection function Drying continues until the drying level to pair your machine with your smart device. reaches the Cupboard Extra Dry step. This way, you can use your smart device to get information about your machine and control it.
- Page 31 5.14 End Time 5.15 Starting the programme With the End Time function, start of 1. Press the Start/Pause button the programme can be delayed up to to start the programme. 24 hours. After pressing the End Time 2. The flashing light of the Start/Pause button, the programme's estimated end button will remain on, indicating that time will be displayed.
- Page 32 If the water level in the machine is not suitable when you press the Start/Pause button, the panel will warn you that the door is closed. 5.17.2 Switching the machine to pause mode • Turn off and unplug the appliance. •...
- Page 33 5.18 Cancelling the programme 5.21 HomeWhiz and the Remote Control Function HomeWhiz allows you to use your smart device to control your washing machine and get information about it. Thanks to the HomeWhiz application, you can use your smart device to carry out some procedures you can also do on the machine.
- Page 34 5.21.1 HomeWhiz Setup INFORMATION Your product and the HomeWhiz app must be connected for the app to run. To • If you cannot complete the setup establish this connection, please follow successfully in 5 minutes, the washing the steps below for setup both on your machine will switch off automatically.
- Page 35 • Follow the steps in the HomeWhiz Setup (5.21.1 HomeWhiz Setup) to complete the setup. WARNING! When Remote Control is enabled, you can • Since the HomeWhiz and Remote Control only manage and switch off the machine functions of your product work through and follow status on the washing machine.
- Page 36 6 Maintenance and cleaning INFORMATION Service life of product extends and frequently • Repeat Drum Cleaning process in experienced problems will be reduced every 2 months or whenever there’s if it is cleaned at regular intervals. excessive lint build up on the rubber 6.1 Cleaning the detergent drawer gasket and drum, that could adversely affect washing &...
- Page 37 There is a filter at the end of each water intake valve at the rear of the machine and CAUTION! also at the end of each water intake hose • Temperature of the water inside the where they are connected to the tap. These machine may rise up to 90 ºC.
- Page 38 7 Troubleshooting Machine directly discharges the water it takes in. • The drain hose might be at an inappropriate height. >>> Programmes won’t start after the loading door has Connect the water drain hose as described in the user manual. been closed.
- Page 39 Programme time does not countdown. (*) Colour of the clothes faded. (**) • The laundry in the machine might be unbalanced. >>> The • Machine might have been overloaded. >>> Do not overload automatic unbalanced load detection system might have been the machine.
- Page 40 There is detergent left on the laundry. Machine does not start or programme cannot be started. • Power cable is not connected. >>> Make sure the power • Machine might have been overloaded. >>> Do not overload the machine. cable is connected. •...
