L4670EA(EN).fm Page 1 Tuesday, May 15, 2007 5:36 PM
LCD TV/DVD
LDD-A2006 LDD-B2006 LDD-C2006 LDD-D2006
Owner's Manual

Table of Contents

Precautions ........................................................................................................................................................2
Operating Controls and Functions .....................................................................................................................4
Setting up...........................................................................................................................................................6
Set up for Use ....................................................................................................................................................8
Operations .......................................................................................................................................................10
About the Discs................................................................................................................................................13
Playing a Disc ..................................................................................................................................................14
DVD Setup .......................................................................................................................................................23
Language Code ...............................................................................................................................................26
Troubleshooting Guide ....................................................................................................................................27
Maintenance ....................................................................................................................................................29
Specifications...................................................................................................................................................30
Pin Connection ................................................................................................................................................31
Declaration of Conformity .................................................................................................................. Back cover
Supplied Accessories
• Remote control
• Two R6 (AA) batteries
• Owner's Manual
• Quick Setup Guide (Only for LDD-B2006)
Help Phone Number in the UK (only for LDD-B2006):
Printed in EU
Model/Serial Number
This appliance has a serial number located on the rear panel.
Please note down the serial number and retain the
information for your records.
Model number:
Serial number:
0870 383 3010
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDD-A2006 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUNAI LDD-A2006

Summary of Contents for FUNAI LDD-A2006

  • Page 1: Table Of Contents

    L4670EA(EN).fm Page 1 Tuesday, May 15, 2007 5:36 PM LCD TV/DVD LDD-A2006 LDD-B2006 LDD-C2006 LDD-D2006 Owner’s Manual Table of Contents Precautions ................................2 Operating Controls and Functions ........................4 Setting up................................6 TV OPERATION Set up for Use ..............................8 Operations ...............................10 DVD OPERATION About the Discs..............................13...

  • Page 2: Precautions

    L4670EA(EN).fm Page 2 Tuesday, May 15, 2007 5:36 PM Precautions Dew Warning WARNING: Moisture condensation may occur inside the unit when it is TO REDUCE THE RISK OF FIRE OR ELECTRIC moved from a cold place to a warm place, or after heating a SHOCK, DO NOT EXPOSE THIS APPLIANCE cold room or under conditions of high humidity.
  • Page 3 L4670EA(EN).fm Page 3 Tuesday, May 15, 2007 5:36 PM • x1.3 and x0.8 Rapid Play with Voice Connection to Power (Only for U.K.) Playback in slightly faster/ slower speed while keeping the Before Switching on make sure that the voltage of your sound quality as in the normal playback.

  • Page 4: Operating Controls And Functions

    L4670EA(EN).fm Page 4 Tuesday, May 15, 2007 5:36 PM Operating Controls and Functions REMOTE CONTROL CONTROL PANEL INPUT STANDBY-ON DISPLAY SELECT SLEEP − VOL. + − PROG. + SETUP STOP PLAY EJECT SELECT STANDBY-ON MODE PICTURE 28 27 35 6 24 15 SOUND SETUP...
  • Page 5 L4670EA(EN).fm Page 5 Tuesday, May 15, 2007 5:36 PM Installing the Batteries Switching TV / DVD Mode 1) Open the battery compartment cover. • To switch TV mode to DVD mode, press PLAY , insert a 2) Insert “R6” penlight batteries into battery compartment disc or press EJECT on the unit.

  • Page 6: Setting Up

    L4670EA(EN).fm Page 6 Tuesday, May 15, 2007 5:36 PM Setting up Unpacking Connecting The stand of this unit is folded when you purchased. Place this Connecting the Cable unit face-down on a flat surface covered with the soft cloth. Bend the stand slowly to forward until it clicks. VHF/UHF MIXER RF cable...
  • Page 7 L4670EA(EN).fm Page 7 Tuesday, May 15, 2007 5:36 PM Connecting AV terminals • If output is MPEG encoded audio, connect to a MPEG When you watch a programme recorded on an another source, decoder, and set “MPEG” to “BITSTREAM” in the use the AUDIO/VIDEO input jacks on the back of the unit.

  • Page 8: Tv Operation

    L4670EA(EN).fm Page 8 Tuesday, May 15, 2007 5:36 PM TV OPERATION Set up for Use • Unless stated, all operations described are based on remote control Manual Channel Presetting use. Some operations can be carried out using the buttons on the control panel.
  • Page 9 L4670EA(EN).fm Page 9 Tuesday, May 15, 2007 5:36 PM Decoder Allocation Channel Reprogramming You can move a channel allocated to a position to another while Some TV channels transmit encoded TV signals which can only be keeping the total number of the positions the same. When you move viewed with a purchased or hired decoder.

  • Page 10: Operations

    • You can only select channels 1–99. press COLOR SYSTEM , TV screen will change as follows. 3) Adjust the volume to the desired listening level using (LDD-A2006/LDD-B2006/LDD-D2006) VOL. +/- +/- (vol.) on the control panel or on the remote for tuner input (TV): control.
  • Page 11 L4670EA(EN).fm Page 11 Tuesday, May 15, 2007 5:36 PM Picture Adjustment The picture can be adjusted according to your personal preferences. These settings are automatically stored after exiting the picture menu. 1) Press PICTURE , then press Cursor to select the K / L desired control “BRIGHTNESS”, “CONTRAST”, “COLOUR”, “SHARPNESS”...
  • Page 12 L4670EA(EN).fm Page 12 Tuesday, May 15, 2007 5:36 PM...

  • Page 13: Dvd Operation About The Discs

    L4670EA(EN).fm Page 13 Tuesday, May 15, 2007 5:36 PM DVD OPERATION About the Discs Playable Discs *3: Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc’s producers. The following discs can be played back on this unit. *4: Only the discs recorded in the video format and finalised can be played back.

  • Page 14: Playing A Disc

    L4670EA(EN).fm Page 14 Tuesday, May 15, 2007 5:36 PM Playing a Disc Basic Playback • It may take a time to deliver the picture or the sound. This is not a malfunction. DVD-V JPEG DivX ® • PLAY EJECT Press on the control panel or Getting started insert a disc to switch TV mode to DVD mode.
  • Page 15 L4670EA(EN).fm Page 15 Tuesday, May 15, 2007 5:36 PM About the PBC Function of Video CD • DivX files are accompanied by icon. ® • A maximum of 255 folders can be recognised. • A maximum of 999 files can be recognised. PBC stands for Play Back Control, you can play interactive •...
  • Page 16 L4670EA(EN).fm Page 16 Tuesday, May 15, 2007 5:36 PM DivX ® Subtitle Kodak Picture CD The subtitle created by the user can be displayed during DivX The unit can also run JPEG files stored on Kodak Picture ® playback. CDs. The Picture CD is a service to convert photographs taken by a conventional film camera into digital data and write 1) After select the DivX file, the SUBTITLE LIST will...
  • Page 17 L4670EA(EN).fm Page 17 Tuesday, May 15, 2007 5:36 PM Adjustment of Picture Size x1.3 and x0.8 Rapid Play with Voice DVD-V JPEG The overall picture cannot be displayed and the edge of the Available only on discs recorded in the Dolby Digital format, picture can be cut out.
  • Page 18 L4670EA(EN).fm Page 18 Tuesday, May 15, 2007 5:36 PM Note: • Slow Reverse is not available on Video CDs and discs Subtitle Language with DivX files. ® DVD-V DivX ® • On DVDs, set “STILL MODE” to “FIELD” in the DISPLAY menu if pictures in the slow motion This unit allows you to change languages for subtitle during playback mode are blurred.
  • Page 19 L4670EA(EN).fm Page 19 Tuesday, May 15, 2007 5:36 PM Virtual Surround Using SKIP H G SKIP During playback, press to move to the next track. DVD-V Press it repeatedly to skip subsequent tracks. Press SKIP to go back to the beginning of the current You can enjoy stereophonic virtual surround effects on your track.
  • Page 20 L4670EA(EN).fm Page 20 Tuesday, May 15, 2007 5:36 PM Time Search Note: • Repeat Chapter / Title is not available with some scenes. DVD-V DivX ® • Repeat playback does not function during A-B Repeat playback. 1) During playback, press MODE repeatedly until SEARCH •...
  • Page 21 L4670EA(EN).fm Page 21 Tuesday, May 15, 2007 5:36 PM Programmed Playback Random Playback JPEG JPEG You may determine the order in which tracks will be played. This function shuffles the playing order of tracks instead of playback in the original sequence. 1) In Stop mode, press MODE repeatedly until PROGRAM...
  • Page 22 L4670EA(EN).fm Page 22 Tuesday, May 15, 2007 5:36 PM On-Screen Information •For JPEG, current track number/ total track will be displayed. You can check the information about the current playback by •For discs with DivX files, current track number/ total ®...

  • Page 23: Dvd Setup

    L4670EA(EN).fm Page 23 Tuesday, May 15, 2007 5:36 PM DVD Setup In Setup menu, QUICK mode, CUSTOM mode and INITIALIZE mode (refer to pages 23-25) are available. QUICK mode consists of the setting menus often needed, and you can make all settings required in CUSTOM mode. You can make the settings QUICK of the items with mark in QUICK mode.
  • Page 24 L4670EA(EN).fm Page 24 Tuesday, May 15, 2007 5:36 PM Audio Setting Parental Control Choose the appropriate audio settings for your equipment. It Parental Control prevents viewing of DVDs that exceed your only affects during the playback of DVDs. rating limit. The password is required to change the “PARENTAL LEVEL”.
  • Page 25 L4670EA(EN).fm Page 25 Tuesday, May 15, 2007 5:36 PM Others Setting To Reset All the Settings of the Setup Screen You can change the other functions. This function allows you to return all selections of Setup (except for “PARENTAL”) to their default settings. 1) In Stop mode, press SETUP twice.

  • Page 26: Language Code

    L4670EA(EN).fm Page 26 Tuesday, May 15, 2007 5:36 PM Language Code Language Code Language Code Language Code Language Code Frisian 5271 Malay 5965 Somali 6561 Abkhazian 4748 Galician 5358 Malayalam 5958 Spanish [SPA] 5165 Afar 4747 Georgian 5747 Maltese 5966 Sundanese 6567 Afrikaans...

  • Page 27: Troubleshooting Guide

    L4670EA(EN).fm Page 27 Tuesday, May 15, 2007 5:36 PM Troubleshooting Guide If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit, consulting the following checklist. WARNING: Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.
  • Page 28 L4670EA(EN).fm Page 28 Tuesday, May 15, 2007 5:36 PM Problem Solution • Try a new channel, if OK, then possible station trouble. • Check if the AC power cord is properly connected. • Is TV’s STANDBY-ON on? No picture or sound •...

  • Page 29: Maintenance

    L4670EA(EN).fm Page 29 Tuesday, May 15, 2007 5:36 PM Maintenance Servicing Cleaning the Disc Lens • Please refer to relevant topics on the “Troubleshooting • If the player still does not perform properly when it is Guide” on page 27 before returning the product. operated while referring to the relevant sections and to •...

  • Page 30: Specifications

    General Specifications Other Specifications Remote control: Digital encoded infrared light Television system: system LDD-A2006: PAL B/G TV standard Power requirements: AC220-240 V, 50 Hz LDD-B2006: PAL I TV standard Power consumption (Maximum): 60 W LDD-C2006: SECAM L/L’ TV standard, LCD: 20"...

  • Page 31: Pin Connection

    L4670EA(EN).fm Page 31 Tuesday, May 15, 2007 5:36 PM Pin Connection Contacts, signal levels and impedances Contact Connection Contact Connection Audio Output (Right): 2.0 Vrms/1 kΩ RGB, Ground (Red) Audio Output (Left): 2.0 Vrms/1 kΩ RGB Switching Control, Ground RGB Input (Red): 0.7 Vp-p/75 Ω Audio, Ground RGB Switching Control RGB, Ground (Blue)

  • Page 32: Declaration Of Conformity

    EN 55013: 2001 + A1: 2003, EN 55020: 2002 + A1: 2003, EN 61000-3-2: 2000 EN 61000-3-3: 1995 + A1: 2001 EN 60065: 2002 EN 60825-1 Ed. 1. 2: 2001 EN 60825-1: 1994 + A1: 1996 + A2: 2001 1EMN22027A L4670EA/L4671BB/L4673RD/L4680EA/L4681BB/L4683RD**** © 2006-2007 FUNAI EUROPE GMBH. All rights reserved.
