Zafferani Glas VELOX MASTER 4M/22 Manual

Automatic straight line edger
Hide thumbs

Advertisement

Quick Links

Download this manual
VELOX MASTER 4M/22
ZAFFERANI GLAS S.R.L – ITALY
1
MAS4ing001.doc06/04/09

Advertisement

loading
Need help?

Need help?

Do you have a question about the VELOX MASTER 4M/22 and is the answer not in the manual?

Questions and answers

Related Manuals for Zafferani Glas VELOX MASTER 4M/22

Summary of Contents for Zafferani Glas VELOX MASTER 4M/22

  • Page 1 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY MAS4ing001.doc06/04/09...
  • Page 2 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY VELOX MASTER 4M/22 AUTOMATIC STRAIGHT LINE EDGER  GUARANTEE PAG.3  WARNINGS PAG.3  ACCESSORIES AND TECHNICAL CHARACTERISTICS PAG.4  INSTALLATION AND ELECTRICAL CONNECTIONS PAG.5  ADJUSTMENT OF THE MACHINE PAG.5  ADJUSTMENT OF SPEED-TRACK PAG.7...
  • Page 3 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY * QUANTITY OF SPARE PARTS NECESSARY MAS4ing001.doc06/04/09...
  • Page 4 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY GUARANTEE The Company guarantees that the machine has been tested in all its parts in a satisfactory way. The Guarantee is valid for a period of 6 months and it is limeted to the good quality of the machine, of its components and to the absence of faults in its construction.

  • Page 5: Parts And Accessories

    VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY PARTS AND ACCESSORIES The machine is delivered complete with: - plans and drawings for electrical parts - n°1 pilot lamp - n°2 fuses 4A - n°3 fuses 10A (GL) - n°4 window knob - n°1 spanner mm.

  • Page 6: Installation And Electric Connections

    VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY INSTALLATION AND ELECTRIC CONNECTIONS After having chosen the place of installation in your factory, bearing in the mind the necessary space for operations, position the machine making sure of its level. If the machine is to be positioned near to a wall allow enough space behind for the periodical necessary maintenance.
  • Page 7 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY During this operation check if the ammeters mark the right absorbtion. The handle- wheels (3) to centrate the wheels give an approximate direction so that after the first glass you machine adjust them in the right way. The same is for the handle-wheels (4).
  • Page 8 ZAFFERANI GLAS S.R.L – ITALY ADJUSTMENT OF TRACK-SPEED Your VELOX MASTER 4M/22 is equipped with an inverter system which allows to adjust the speed of the track turning the potentiometer on the electric board. This adjustment has to be done according to the thickness of the glass you are working as...
  • Page 9 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY ADVICE ON USE AND MAINTENANCE In this chapter are the most important operation to do in order to use your VELOX MASTER 4M/22 in the best way: 1) It is very important that the water tank (43), where is the pump (13), is changed every day in order to have water always clean.
  • Page 10 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY 6) Sometime it is a good rule to check thatthe track gears (30), (31), (32) are lubrificated with grease in a right way. 7) It is a good rule to install the wheels payng attention to the cleaning of the shaft of the motor and the wheels in order to make them turn well centred.

  • Page 11: Spare Parts

    VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY SPARE PARTS 1 - AMMETERS 2 - EMERGENCY STOP BUTTON 3 - HANDLE FOR CENTERING THE WHHELS 4 - HANDLE FOR TILTING THE WHEELS 5 - HANDLE FOR RISING THE WHEELS 6 - STOP BUTTON POLISHING WHEELS...
  • Page 12 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY MAS4ing001.doc06/04/09...
  • Page 13 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY MAS4ing001.doc06/04/09...
  • Page 14 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY MAS4ing001.doc06/04/09...
  • Page 15 VELOX MASTER 4M/22 ZAFFERANI GLAS S.R.L – ITALY SECTIONS OF THE WHEELS TYPE GRINDING THIKNESS D.WHEEL ROUND FLAT POLISH ROUND 3_12 200X20X90 ROUND 13_22 200X30X90 FLAT+ARRISES 3_12 200X20X90 FLAT+ARRISES 13_22 200X40X90 45° 6_12 Here below are the different kind of glass section you can work using wheels you can find on the market.
