- Page 1 INSTALLATIONSANLEITUNG INSTALLATION INSTRUCTION V.1|2021 protos 115 / 230 www.photinus.at...
- Page 2 1 Inbusschlüssel / Allen Wrench 4 / 5 / 6 mm 1 Torx 20 Schraubendreher / torx 20 screwdriver 1 Gabelschlüssel / Open Wrench - SW 13 1 Ratschensatz / Nut runner - SW13 / SW 19 www.photinus.at | Installation protos | 2021...
- Page 3 PHOTOVOLTAIK MODUL / PHOTOVOLTAIC MODULE NEIGUNGSEINSTELLUNG ANGLE ADJUSTMENT 15° www.photinus.at | Installation protos | 2021...
- Page 4 LICHTGEHÄUSE / LIGHT HOUSING www.photinus.at | Installation protos | 2021...
- Page 5 AKKU UND LICHTMAST / BATTERY AND POLE Akku / Battery Akku / Battery www.photinus.at | Installation protos | 2021...
- Page 6 AKKU UND LICHTMAST / BATTERY AND POLE www.photinus.at | Installation protos | 2021...
- Page 7 AKKU / BATTERY AUFFÜLLUNG KIES/SPLIT / GRAVEL /SAND DRAINAGE (GRAVEL / KIES GROB) BETON/PVC ROHR • protos115 Ø 25cm • protos230 Ø 30cm CONCRETE/PVC PIPE • protos115 25 cm Ø • protos230 30 cm Ø www.photinus.at | Installation protos | 2021...
- Page 8 MONTAGEMÖGLICHKEIT 2 - SCHRAUBFUNDAMENT MOUNTING POSSIBILITY 2 - GROUND SCREW FOUNDATION KRINNER Screw Foundation Art. 26160: KSF E140x1600-E76-100 for protos 115 Art. 25500: KSF E140x2100-E76-100 for protos 230 an protos duo MAST DURCHMESSER 90/133 mm POLE DIAMETER 90/133 mm AKKU /...
