- Page 1 GV-312T Touch Series GEVA Vision System Installation Manual 405-00046-00 September 9, 2014 Revision 1.1...
- Page 2 All copyrights in this manual, and the hardware and software described in it, are the exclusive property of Teledyne DALSA Incorporated and its licensors. Claim of copyright does not imply waiver of Teledyne DALSA Incorporated or its licensors other rights in the work. See the following Notice of Proprietary Rights.
- Page 3 Certifications Declaration of Conformity Supplier Teledyne DALSA Industrial Products Inc. 700 Technology Park Drive Billerica MA 01821 This product is in compliance with the directives of the European Union. It has passed the CE test for environmental specifications when shielded cables are used for external wiring.
- Page 4 Warranty Teledyne DALSA warrants the GV-312T against defects in materials and workmanship for a period of Twelve (12) months from the date of delivery. Teledyne DALSA and its representatives expressly disclaim any and all other warranties. Your sole remedy shall be repair or replacement of this product and associated optional components, provided that the defective product is returned within the warranty period.
-
Page 5: Table Of Contents
Table Of Contents GV 312T Introduction ……………………....... Introduction System Components ……………………....... Product Support ……………………....... Installation ……………………....... Installation Panel Mount ……………………....... VESA Mount ……………………....... GigE Cameras ……………………....... Typical Configuration ……………………....... using the PL-USB Typical Configuration ……………………....... not using the PL-USB Getting Started ……………………....... -
Page 6: Introduction
Introduction GV 312T is a low cost vision system with an integrated touch panel interface for configuring and monitoring automated camera inspections on the factory floor. The product is equipped with hardware interfaces and application software to support the following: •... -
Page 7: System Components
This manual will assist you with the installation and setup of your GV 312Tproduct and the embedded software. It describes what the product supports and how to connect the external interfaces. If your questions are not answered in this reference, please contact your local Teledyne DALSA representative. - Page 8 Installation Review user interface controls, connections and mounting holes Front View Reset button – front accessible USB port 12” Touch LCD display (refer to appendix A for touch screen calibration) Press control function keys as follows:...
- Page 9 Installation Bottom View Power Input – 24 VDC. Four RS-232 ports DVI port for optional 2 display Two Gigabit Ethernet ports. Default IP settings are as follows (these can optionally be changed through the Windows network “adapter change settings” interface): Marking Default IP Connection...
- Page 10 Installation Mount the Unit (Panel Mount) Locate the panel mounting clips included with the product. Put the clamps into the holes located on the sides of the product as shown:...
- Page 11 Installation Attach the rubber gasket included in the mounting kit around the inside back lip of the panel. Place the GV 312T into the correct-sized cutout on a control panel or frame and tightly screw the panel-mounting clamps around the edges to secure the product.
- Page 12 Installation Mount the Unit (VESA mount) Some applications may require mounting the GV 312T to a VESA compatible ARM. This requires an optional mounting bracket (A-VESA-T) that should be purchased with the unit. Take the bracket assembly and attach it to the back and sides of the product as shown below. Make sure not to cover the door of the CFAST flash drive.
-
Page 13: Gige Cameras
GigE Cameras The GV 312T supports Teledyne DALSA Genie cameras for image acquisition. These include the Genie series and the Genie TS series. The Spyder GigE line scan series is not recommended for this product. The Genie family, including the TS series, offers a range of sensor resolution from 640x480 up to 4096x3072 pixels. -
Page 14: Typical Configuration
Typical Configuration using the PL-USB module GV 312T Camera Network LAN2 Setup/Operator HMI (iNspect Express shown) Switch PL-USB I/O Connections NOTES: Power connections not shown Use A-CAB-GE-X for camera Ethernet connections Use A-CAB-GEVA-FX for I/O connections between camera and PL-USB... -
Page 15: Typical Configuration
Typical Configuration without the PL-USB module GV 312T Camera Network LAN2 Setup/Operator HMI (Sherlock shown) Switch I/O Connections NOTES: Power connections not shown Use A-CAB-GE-X for camera Ethernet connections Use A-CAB-GTP-FX cables for camera power... -
Page 16: Getting Started
GV 312T. For reference, the following table lists the location and association of core programs and data directories that are referenced in this manual: iNspect Express Program Files and Directories Camera Selector C:\Program Files\Teledyne Dalsa\iNspect Express for VA\CameraSelector.exe iNspect Express C:\Program Files\Teledyne Dalsa\iNspect Express for VA\Express.bat iNspect Express Solution Files... -
Page 17: The License Manager
Start->All Programs->Teledyne DALSA->iNspect Express for VA->License Manager OR Start->All Programs->Teledyne DALSA->Sherlock->License Manager If the license does not reflect what you purchased, consult your Teledyne DALSA sales representative. The license is field upgradable by entering a new string in the box... -
Page 18: Inspect Express Setup
iNspect Express Setup Follow these steps to configure the system to run iNspect Express: 1. Connect cameras as shown in the hardware installation 2. Verify a valid license is installed (run License Manager) 3. Open the Camera and Language Selector Program (from shortcut) and configure preferences;... - Page 19 The Camera and Language Selector This program is a front-end configuration tool for iNspect Express. Launch from the icon on the GV 312T desktop. Select the language, camera type (always GigE for GV 312T) and custom features for your application. These features are peculiar to the iNspect Express software and are detailed in the software users manual.
-
Page 20: Camera Selector
The iDiscover Utility The iDiscover utility is provided for discovering Genie cameras connected to the GV 312T camera port. Use the iDiscover interface to change the camera IP settings to match the IP setting of the camera port. A shortcut to the iDiscover program is available on the GV 312T desktop. -
Page 21: Sherlock Setup
Sherlock Setup Follow these steps to configure the system to run Sherlock: 1. Connect cameras as shown in the hardware installation 2. Verify a valid license is installed (run License Manager) 3. Run the iDiscover program to detect and configure cameras connected to the system (icon shortcut on the desktop) 4. - Page 22 The Sapera CamExpert Utility Genie cameras store their configuration settings (I/O, shutter speed, white balance) in memory (EEPROM). iNspect Express overides these settings according to the solution file, whereas Sherlock loads them from the camera or a stored configuration file during program initialization.
- Page 23 The Sapera Acquisition Wizard The Sapera Acquisition Wizard detects all available Genie Cameras, and creates a file “SaperaLTDrv.ini” that identifies them in Sherlock. You can enable or disable camera ports, and select camera configuration files using this utility. NOTE: If a configuration file does not match the number of cameras, the Sapera LT and Genie drivers will not load and Sherlock will not run saved programs.
- Page 24 Changing the Camera Order The cameras will be seen in Sherlock in the same order as they appear in the Sapera Acquisition Wizard. If the order is not to your liking, there are two ways you can correct this. 1.Exit the wizard, disconnect the cameras, and reconnect them in the order you desire. Use the SHOW Status Dialog Box (located in the windows tray at the bottom of your display) to monitor when the cameras are recognized.
-
Page 25: Enhanced Write Filter
Windows Enhanced Write Filter GV 312T uses the Windows 7 Embedded operating system. This O/S supports an Enhanced Write Filter (EWF) that provides the ability to write-protect a run-time image. By redirecting all write requests to an overlay disk or RAM partition, EWF allows the run-time image to maintain the appearance of a writeable run-time image. -
Page 26: Specifications
Specifications General Specifications of the GV 312T Specification Definition Platform Processor Dual Core Atom N2600 @ 1.6GHz Windows7 Embedded (32-bit) Memory Storage 32GB Solid State CFAST Program 2GB DDR3 non-expandable Communications Ethernet 2 x Gigabit direct Serial 4 x RS-232 5 x USB 2.0 (1 front and 4 bottom) Supported through PL-USB module LED status... - Page 27 GV 312T Mechanical Dimensions Units in mm...
-
Page 28: Touch Screen
Appendix A Touch Screen Calibration The GV 312T touch screen has been calibrated at the factory prior to shipping, but you may need to recalibrate to suite your needs. There is an application called “PenMount Control Panel” under “Program files”. Execute this application: In the “Device”... - Page 29 Appendix A The application will display a crosshair on a white screen. Use your finger or stylus to touch the red center and hold down until the screen shows the message - “Lift off to proceed”. A 2nd crosshair follows immediately. Do the process again. After the 5 red point calibration is complete, the program will jump out automatically, or you may press ESC key to quit it during calibration process.
