- Page 1 Mounting illustrations Parts 4 - 7 User and Installation instructions Stathe Road, Burrowbridge, Somerset, TA7 0RY Tel: 01823 690 290 Email: info@nvagroup.co.uk Web: www.nationalventilation.co.uk...
- Page 2 (3x) (3x) (3x) (3x)
- Page 3 Parts 1. Wall frame with cover. With integrated sealing gaskets. 2. Motor unit with bayonet mount and removable impeller. Easy to clean. 3. Multi-mode selector. 4. Adjustable cover. 5. Presence sensor. Motion (IR) and light. 6. Self-adjusting humidity control. Thermostat 7. Self-calibrating motor guarantees correct flow.
- Page 4 Viktigt! Important! Read these instructions carefully before use. Läs noga igenom denna anvisning innan användning. The fan is designed for permanent installation and must be installed by a qualified electri cian. Fläkten är anpassad för fast installation och ska installeras av behörig elektriker. Under standard EN 60335, the following must be observed. Enligt standarden EN 60335 skall följande beaktas. Denna apparat kan användas av personer This appliance is to be used by persons from eight years upwards and by persons with reduced från 8 år och uppåt och av personer med nedsatt fysisk eller mental förmåga, eller brist på...
- Page 5 Installation See pictures on page 2, each instruction is relative to the alphanumeric naming system 4. Electrical connection on images NOTE! May only be carried out by qualified electrician. During any electrical work on the fan, the voltage supply 1. Preparations The motor unit has a bayonet mount that facilitates must be disconnected.
- Page 6 Description of operating modes Modes Continuous basic ventilation (basic airflow) Intellisense i7 has seven selectable operating modes. The fan The fan operates at a constant low speed, 40 m /h, is set to Mode 1 at the factory, which means that it will creating a useful basic ventilation.
- Page 7 Care and maintenance Warranty To maintain its function and capacity, the fan must be Intellisense i7 has a 5 year warranty against fabrication / ma- cleaned at least twice a year, or more often if necessary. terial defects. Warranty claims on this product are accepted No solvents may be used on the fan. The fan must not be in accordance with the applicable terms of sale, provided submerged in or flushed with water.
- Page 8 Tel: 01823 690 290 Email: info@nvagroup.co.uk Web: www.nationalventilation.co.uk EU Authorised Representative: National Ventilation Bedrijvenweg 17 7442 CX Nijverdal Nederland authorisedrep@nationalventilation.nl © Copyright National Ventilation We reserve the right for printing errors and reserve the right to material and design changes.
