PACLITE Equipment IMPACT430DE Operator's Manual

Reversible plate compactor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2011
IMPACT430DE
Operator's Manual
Reversible Plate Compactor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMPACT430DE and is the answer not in the manual?

Questions and answers

Related Manuals for PACLITE Equipment IMPACT430DE

Summary of Contents for PACLITE Equipment IMPACT430DE

  • Page 1 2011 IMPACT430DE Operator’s Manual Reversible Plate Compactor...
  • Page 3 EC DECLARATION OF CONFORMITY / DECLARATION CE DE CONFORMITE / DECLARACIÓN DE CONFORMIDAD CE / DECLARAÇÃO CE DE CONFORMIDADE We, Uni-corp Europe, 33 Avenue Pierre Brossolette,94048 Créteil Cedex,France, hereby certify that if the product described within this certificate is bought from an authorised Hoppt dealer within the EEA, it conforms to the following directives: Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/EC (as amended by 92/31/EEC &...

  • Page 4: Table Of Contents

    Foreword This manual has been written to help you operate your Reversible Plate Compactor safely. It is intended primarily for dealers and operators of Paclite Reversible Plate Compactors. It is recommended that you keep this manual or a copy of it with the machine so that it is readily available for reference.

  • Page 5: Safety Information

    Reversible Compactor (2011 Version) Safety Information For your own personal protection and for the safety of those around you, please read and ensure you fully understand the following safety information. It is the responsibility of the operator to ensure that he/she fully understands how to operate this equipment safely. If you are unsure about the safe and correct use of the Reversible Plate Compactor, consult your supervisor or Paclite.
  • Page 6 injury or property damage, and possibly death. If such unpredictable and unrecognisable risks become apparent, the machine must be stopped immediately, and operator or his supervisor must take appropriate measure to eliminate such risks. It is sometimes necessary that the manufacturer must be informed of such an event for future counter measuring.

  • Page 7: Environment

    Reversible Compactor (2011 Version) Dust The compaction process can produce dust, which may be hazardous to your health. Always wear a mask that is suited to the type of dust being produced. Environment In order to protect the environment please Component Material recycle...

  • Page 8: Pre-Start Checks

    Pre-Start Checks The following Pre-start-up inspection must be performed before the start of each work session or after every four hours of use, whichever is first. Please refer to the service & maintenance section for detailed guidance. If any fault is discovered, the Plate Compactor must not be used until the fault is rectified.

  • Page 9: Operation

    Reversible Compactor (2011 Version) Before Starting Gasoline Engine Check the oil in the engine crankcase. Be sure to maintain the proper level per the engine manufacturer specifications. If the oil is dirty and in need of changing, follow the Engine User Manual instructions. Check the fuel supply.
  • Page 10 Regarding Speed and Direction The plate compactor has a hydraulic system which enables a gradual increase in speed. The direction of travel is determined by the control on the guide pole. Application This Reversible Plate Compactor is designed for compacting loose, granular soils, gravel, paving stones and asphalt.

  • Page 11: Service And Maintenance

    Reversible Compactor (2011 Version) Service and Maintenance Parts Maintenance Interval Check filter, clean or replace if necessary. Air filter Check oil level (only for models with bathed in oil filter.) Fuel tank Check tank lid fortight fit, replace if necessary. Daily.

  • Page 12: Transportation And Storage

    Hydraulic system Move centre pole into vertical position. Open filler bore. Check oil level, top up if necessary. Top up with hydraulic oil T68. Close filler bore. Transportation and Storage Extreme Care must be taken when transporting, loading or undloading this machine.

  • Page 13: Trouble Shooting

    Reversible Compactor (2011 Version) Trouble Shooting PROBLEMS POSSIBLE CAUSES COUNTERMEASURES Place the handle in vertical position. Add hydraulic oil until Oil lack in the hydraulic The machine does not go forward the level indicated in the pump. pump placed on the or goes forward slowly.

  • Page 14: Technical Data

    Technical Data MODEL IMPACT430DE OPERATING WEIGHT - kg (lb) 400 (880) SHIPPING WEIGHT(INCLUDING 410(902) PACKAGING)- kg (lb) WORKING WIDTH - mm (in) 690(27.1) VIBRATION FREQUENCY - Hz (V.P.M.) 70(70) CENTRIFUGAL FORCE - KN COMPACTED AREA - m²/h (ft²/h) 820(8826) COMPACTION DEPTH (70~85) (2.75~3.35)

  • Page 15: Warranty

    Warranty Your new Paclite Reversible Compactor is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The Paclite warranty covers defects in design, materials and workmanship. The following are not covered under the Paclite warranty: 1.
  • Page 16 Notes...
  • Page 17 Reversible Compactor (2011 Version) Notes...
  • Page 18 Notes...
  • Page 20 Uni-corp Europe S.A.R.L. Paclite Equipment ZAC DES PETITS CARREAUX 12 avenue des Coquelicots 94380 Bonneuil sur Marne +33 (0) 1 49 56 02 82 +33 (0) 1 43 99 19 50 sales@paclite-equip.com Paclite-equip.com 2011...
