- Page 1 U S P U S P A Product of A L L P U R P O S E V I N Y L S T O R A G E S H E D S US POLYMERS INC Foundation Kit Instructions for Assembly Size 4’...
- Page 2 . Assemble the channel (F04C) & (F05C) together using 4 screws. Make 2 sets. Parts List F05C Note: Check all parts prior to installation. CODE DESCRIPTION F01C FOUNDATION ‘U’ CHANNEL F02C FOUNDATION ‘U’ CHANNEL ‘U’ CHANNEL FOUNDATION ‘L’ ANGLE F04C FOUNDATION ‘U’...
- Page 3 . Fix the L-angle (F03) to the channel at all the four corners to make a perfect frame. See Fig. . Fix the channel (F01C) into the main frame as shown. See Fig. Make sure while assembling, the Note channel position should be as shown.
- Page 4 . Assemble the U-Channel bases on top of the foundation as shown in Figure. F05C F01C F04C . After completing the assembly of shed place exterior grade CDX 3/4” (19mm) plywood inside the foundation. See fig. OR 7b . After completing the assembly of the base U-channel fill the concrete upto the foundation top surface.
