Contents
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Use Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Inspection and Maintenance Procedures . . . . . . . . . . . . . . . . . . . 4
Beam Clamps and Machinery Frame . . . . . . . . . . . . . . . . . . 4
Blocks and Wire Rope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide Rollers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Drum Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Visit the Titan Hoist web page at jrclancy.com for more information.
Note: Please read and understand these instructions before using or setting up.
Note: Review all of the Installation Drawings and Reference Drawings.
Note: If you need additional information, contact JR Clancy using the information below.
©Wenger Corporation 2019
JR Clancy Incorporated, 7041 Interstate Island Road, Syracuse, New York 13209
Printed in USA 2019-09
Questions? Call..... Worldwide: +1-315-451-3440 • jrclancy.com
Maintenance Manual
Motor and Gear Reducer . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Secondary Load Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Manually Releasing the Hoist Brakes . . . . . . . . . . . . . . . . . . 10
Controls Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Circuit Protection and Controls Electronics . . . . . . . . . . . . . . 11
Limit Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warning Signs and Operational Instructions . . . . . . . . . . . . . 15
Decommisioning and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Titan Hoist Maintenance and Inspection Log . . . . . . . . . . . . . . . . 16
