9. ASSEMBLY

Open the box and remove the unit and all parts inside.
IMPORTANT
• Remove the packaging completely from the device.
• Unwind the power cord completely.
• Be careful not to damage the power cord.
1. (Fig. 1) Turn the tower fan upside down so you can see the support for the
pedestal.
2. (Fig. 2) Pass the power cord through the base.
3. (Fig. 3) Connect the two parts of the stand together.
4. (Fig. 4) Push the pedestal into the recessed holes provided and secure it firmly
to the fan unit using the screws provided.
Fig. 1
Fig. 3
30 Relaxxnow
Fig. 2
Fig. 4
