© 2000. All rights reserved.
Black Box Corporation.
Black Box Corporation • 1000 Park Drive • Lawrence, PA 15055-1018 • Tech Support: 724-746-5500 • www.blackbox.com • e-mail: info@blackbox.com
NET-ADVISOR, NET-ADVISOR-RS,VERI-NET,
N E
T - A
D V
I S O
R
L o
g
T r a
f f ic
S c
r o ll
E n
t e r
L E
D
A u
d io
S e
t u p
O N

Key Features

Instant test results.
Compact size.
Tests active links—no
need to isolate a link
from the LAN.
Net-Advisor and Net-
Advisor-RS provide
24-hour traffic logging.
Net-Advisor-RS has an
RS-232 interface and
includes cable and
software for down-
loading of measure-
ments to a host
computer.
6/14/2000
#23616
VERI-NET+,AND VERI-NET PRO
About Net-Advisor/Net-Advisor-RS
I
nstantly detect and display
network activity without a direct
electrical connection to the cable.
This tester features a sensor that
reads data signals through all
UTP, STP, or coax cables.
Just place the cable in the
cable portal and close the jaws.
Ultra-sensitive, high-frequency
magnetics read the low-level
fields generated by each data bit
transmitted through the cable.
Results are shown on the
graphical LED display. And
audible and visual signals trigger
when traffic levels exceed user-
defined threshold conditions.
Troubleshooting doesn't get faster
or easier than this!
The Net-Advisor verifies
connectivity, measures network
loading, and logs traffic levels for
up to 24 hours.
Besides all those features, the
Net-Advisor-RS has an RS-232
serial port for continuous down-
loading of traffic measurements to
a host computer. Use that
information to analyze use and
performance baselining.
And it's convenient for
troubleshooting in the field. The
tester weighs about as much as a
TV remote, is compact enough to
fit in a shirt pocket, and runs on
two AA batteries.
For information about Veri-Net
and Veri-Net+, see Figure 2 and
the description on page 2.
